Citroen C5 Specs, Engines & Dimensions (2004–2008) — First Generation Restyling

The restyled first-generation Citroen C5 arrived as a comfortable mid-size family car, offered in Liftback and Estate 5-door bodies, with a practical spread of diesel and gasoline versions suited to long-distance driving.

← All Citroen models

Citroen C5 Engines and Transmissions

Citroen C5 engine options span economical diesels and smoother gasoline units. The 1.6 MT and 2.0 MT pair diesel efficiency with a manual gearbox for lower running costs, while the 3.0 AT gasoline version favours relaxed automatic cruising. All these examples drive the front wheels.

Liftback — Citroen C5 Engines and Transmissions

Liftback Citroen C5 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Diesel	1560 cm³	109 hp	80 kW	240 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	136 hp	100 kW	320 N⋅m	Manual	FWD
2.2 MT	Diesel	2179 cm³	170 hp	130 kW	400 N⋅m	Manual	FWD
2.2 AT	Diesel	2179 cm³	170 hp	130 kW	400 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1749 cm³	115 hp	85 kW	160 N⋅m	Manual	FWD
1.8 MT	Gasoline	1749 cm³	125 hp	92 kW	170 N⋅m	Manual	FWD
2.0 MT	Gasoline	1997 cm³	140 hp	103 kW	200 N⋅m	Manual	FWD
2.0 AT	Diesel	1997 cm³	136 hp	100 kW	320 N⋅m	Automatic	FWD
2.2 AT	Diesel	2179 cm³	133 hp	98 kW	314 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1997 cm³	145 hp	106 kW	200 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2946 cm³	207 hp	152 kW	285 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1997 cm³	140 hp	103 kW	200 N⋅m	Automatic	FWD

Estate 5-door — Citroen C5 Engines and Transmissions

Estate 5-door Citroen C5 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Diesel	1560 cm³	109 hp	80 kW	240 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	136 hp	100 kW	320 N⋅m	Manual	FWD
2.2 AT	Diesel	2179 cm³	133 hp	98 kW	314 N⋅m	Automatic	FWD
2.2 MT	Diesel	2179 cm³	170 hp	130 kW	400 N⋅m	Manual	FWD
2.2 AT	Diesel	2179 cm³	170 hp	130 kW	400 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1749 cm³	116 hp	85 kW	160 N⋅m	Manual	FWD
1.8 MT	Gasoline	1749 cm³	125 hp	92 kW	170 N⋅m	Manual	FWD
2.0 MT	Gasoline	1997 cm³	140 hp	103 kW	200 N⋅m	Manual	FWD
2.0 AT	Gasoline	1997 cm³	140 hp	103 kW	200 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2946 cm³	207 hp	152 kW	285 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2946 cm³	210 hp	154 kW	285 N⋅m	Automatic	FWD
2.0 AT	Diesel	1997 cm³	136 hp	100 kW	320 N⋅m	Automatic	FWD

Citroen C5 Dimensions

Liftback — Citroen C5 Dimensions

Liftback Citroen C5 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4745 mm	1780 mm	1476 mm	2750 mm	1355 kg	1945 kg	150 mm
2.0 MT	4745 mm	1780 mm	1476 mm	2750 mm	1415 kg	2005 kg	150 mm
2.2 MT	4745 mm	1780 mm	1476 mm	2750 mm	1490 kg	2080 kg	150 mm
2.2 AT	4745 mm	1780 mm	1476 mm	2750 mm	1490 kg	2080 kg	150 mm
1.8 MT	4745 mm	1780 mm	1476 mm	2750 mm	1305 kg	1895 kg	150 mm
1.8 MT	4745 mm	1780 mm	1476 mm	2750 mm	1310 kg	1895 kg	150 mm
2.0 MT	4745 mm	1780 mm	1476 mm	2750 mm	1325 kg	1845 kg	150 mm
2.0 AT	4745 mm	1780 mm	1476 mm	2750 mm	1629 kg	2040 kg	150 mm
2.2 AT	4745 mm	1780 mm	1476 mm	2750 mm	1490 kg	2078 kg	150 mm
2.0 AT	4745 mm	1780 mm	1476 mm	2750 mm	1380 kg	1945 kg	150 mm
3.0 AT	4745 mm	1780 mm	1476 mm	2750 mm	1590 kg	2100 kg	150 mm
2.0 AT	4745 mm	1780 mm	1476 mm	2750 mm	1448 kg	1958 kg	150 mm

Estate 5-door — Citroen C5 Dimensions

Estate 5-door Citroen C5 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4839 mm	1780 mm	1511 mm	2750 mm	1370 kg	2055 kg	150 mm
2.0 MT	4839 mm	1780 mm	1511 mm	2750 mm	1450 kg	2120 kg	150 mm
2.2 AT	4839 mm	1780 mm	1511 mm	2750 mm	1520 kg	2170 kg	150 mm
2.2 MT	4839 mm	1780 mm	1511 mm	2750 mm	1520 kg	2170 kg	150 mm
2.2 AT	4839 mm	1780 mm	1511 mm	2750 mm	1520 kg	2170 kg	150 mm
1.8 MT	4839 mm	1780 mm	1511 mm	2750 mm	1345 kg	2015 kg	150 mm
1.8 MT	4839 mm	1780 mm	1511 mm	2750 mm	1420 kg	2015 kg	150 mm
2.0 MT	4839 mm	1780 mm	1511 mm	2750 mm	1355 kg	2025 kg	150 mm
2.0 AT	4839 mm	1780 mm	1511 mm	2750 mm	1410 kg	2080 kg	150 mm
3.0 AT	4839 mm	1780 mm	1511 mm	2750 mm	1620 kg	2180 kg	150 mm
3.0 AT	4839 mm	1780 mm	1511 mm	2750 mm	1550 kg	2180 kg	150 mm
2.0 AT	4839 mm	1780 mm	1511 mm	2750 mm	1649 kg	2160 kg	150 mm

Citroen C5 Cargo Space

Liftback — Citroen C5 Cargo Space

Liftback Citroen C5 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	471 l	1315 l
2.0 MT	471 l	1315 l
2.2 MT	471 l	1315 l
2.2 AT	471 l	1315 l
1.8 MT	471 l	1315 l
1.8 MT	471 l	1315 l
2.0 MT	471 l	1315 l
2.0 AT	471 l	1315 l
2.2 AT	471 l	1315 l
2.0 AT	471 l	1315 l
3.0 AT	471 l	1315 l
2.0 AT	471 l	1315 l

Estate 5-door — Citroen C5 Cargo Space

Estate 5-door Citroen C5 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	563 l	1658 l
2.0 MT	563 l	1658 l
2.2 AT	563 l	1658 l
2.2 MT	563 l	1658 l
2.2 AT	563 l	1658 l
1.8 MT	563 l	1658 l
1.8 MT	563 l	1658 l
2.0 MT	563 l	1658 l
2.0 AT	563 l	1658 l
3.0 AT	563 l	1658 l
3.0 AT	563 l	1658 l
2.0 AT	563 l	1658 l

Citroen C5 Trims and Equipment

Citroen C5 trim levels sit on top of the mechanical version rather than replacing it. The 2.0 AT diesel Liftback, for instance, was offered in SX equipment, so two cars sharing that powertrain can differ in comfort, convenience and safety features depending on the specification chosen.

Citroen C5 Trims and Equipment
Modification	Body	Equipment
2.0 AT	Liftback	SX
2.2 AT	Liftback	SX
2.0 AT	Liftback	SX
2.0 AT	Liftback	SX
