Chevrolet Equinox Specs, Engines & Dimensions (2009–2015)

Chevrolet Equinox Engines and Transmissions

Chevrolet Equinox engine choices here include gasoline automatics in the five-door SUV. The 2.4 AT powertrain can use front-wheel or all-wheel drive, so you keep the drivetrain simple or add traction. A 3.0 AT example pairs the larger gasoline engine with an automatic and front-wheel drive.

SUV 5-doors — Chevrolet Equinox Engines and Transmissions

SUV 5-doors Chevrolet Equinox Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 AT	Gasoline	2384 cm³	182 hp	134 kW	233 N⋅m	Automatic	FWD
2.4 AT	Gasoline	2384 cm³	182 hp	134 kW	233 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2994 cm³	264 hp	194 kW	301 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2994 cm³	264 hp	194 kW	301 N⋅m	Automatic	AWD
3.6 AT	Gasoline	3564 cm³	301 hp	221 kW	369 N⋅m	Automatic	FWD
3.6 AT	Gasoline	3564 cm³	301 hp	221 kW	369 N⋅m	Automatic	AWD

Chevrolet Equinox Dimensions

SUV 5-doors — Chevrolet Equinox Dimensions

SUV 5-doors Chevrolet Equinox Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 AT	4771 mm	1842 mm	1684 mm	2857 mm	1706 kg	2127 kg	199 mm
2.4 AT	4771 mm	1842 mm	1684 mm	2857 mm	1782 kg	2300 kg	199 mm
3.0 AT	4771 mm	1842 mm	1684 mm	2857 mm	1789 kg	2360 kg	199 mm
3.0 AT	4771 mm	1842 mm	1684 mm	2857 mm	1860 kg	2400 kg	199 mm
3.6 AT	4771 mm	1842 mm	1684 mm	2857 mm	1779 kg	2360 kg	199 mm
3.6 AT	4771 mm	1842 mm	1684 mm	2857 mm	1850 kg	2404 kg	199 mm

Chevrolet Equinox Cargo Space

SUV 5-doors — Chevrolet Equinox Cargo Space

SUV 5-doors Chevrolet Equinox Cargo Space
Modification	Trunk volume min	Trunk volume max
2.4 AT	889 l	1803 l
2.4 AT	889 l	1803 l
3.0 AT	889 l	1803 l
3.0 AT	889 l	1803 l
3.6 AT	889 l	1803 l
3.6 AT	889 l	1803 l

Chevrolet Equinox Trims and Equipment

Chevrolet Equinox trim levels sit on a named technical version rather than replacing it. On the front-wheel-drive 2.4 AT, LS and LT change cabin and convenience equipment while the gasoline automatic and five-door SUV layout stay the same. You choose the powertrain first, then the trim that fits your needs.

Chevrolet Equinox Trims and Equipment
Modification	Body	Equipment
2.4 AT	SUV 5-doors	LS
2.4 AT	SUV 5-doors	LT
2.4 AT	SUV 5-doors	LT
