Catalog / BMW / 3 series / 5 generation, restyling
BMW 3 Series Engines and Transmissions
A BMW 3 Series engine may be a smooth gasoline unit or a torque-rich diesel, and the powertrain largely sets the car's character. Examples include the 325i 2.5 AT Cabrio with rear-wheel drive, the 330xd 3.0 MT Sedan on all-wheel drive, and the 335i 3.0 DSG Cabrio with a robotic transmission.
Cabrio — BMW 3 Series Engines and Transmissions
Cabrio BMW 3 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 320i 2.0 MT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Manual RWD 325i 2.5 AT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Automatic RWD 325i 2.5 MT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Manual RWD 335i 3.0 MT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Manual RWD 320i 2.0 MT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Manual RWD 323i 2.5 MT Gasoline 2497 cm³ 177 hp 130 kW 230 N⋅m Manual RWD 325i 3.0 MT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Manual RWD 328i 3.0 MT Gasoline 2996 cm³ 234 hp 172 kW 271 N⋅m Manual RWD 328i 3.0 AT Gasoline 2996 cm³ 234 hp 172 kW 271 N⋅m Automatic RWD 330i 3.0 MT Gasoline 2996 cm³ 258 hp 190 kW 300 N⋅m Manual RWD 330i 3.0 MT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Manual RWD 330i 3.0 AT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Automatic RWD 320d 2.0 AT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Automatic RWD 320d 2.0 MT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Manual RWD 320d 2.0 MT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Manual RWD 320d 2.0 AT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Automatic RWD 325d 3.0 AT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Automatic RWD 325d 3.0 MT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Manual RWD 325d 3.0 MT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Manual RWD 330d 3.0 MT Diesel 2993 cm³ 231 hp 170 kW 500 N⋅m Manual RWD 330d 3.0 AT Diesel 2993 cm³ 231 hp 170 kW 500 N⋅m Automatic RWD 330d 3.0 MT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Manual RWD 330d 3.0 AT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Automatic RWD 320i 2.0 AT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Automatic RWD 335i 3.0 DSG Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Robotic RWD 318i 2.0 MT Gasoline 1995 cm³ 143 hp 105 kW 190 N⋅m Manual RWD 320i 2.0 AT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Automatic RWD 325i 3.0 AT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Automatic RWD 330i 3.0 AT Gasoline 2996 cm³ 258 hp 190 kW 300 N⋅m Automatic RWD 325d 3.0 AT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Automatic RWD
Sedan — BMW 3 Series Engines and Transmissions
Sedan BMW 3 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 318i 2.0 MT Gasoline 1995 cm³ 136 hp 100 kW 180 N⋅m Manual RWD 325xi 2.5 MT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Manual AWD 325xi 2.5 AT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Automatic AWD 325i 2.5 MT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Manual RWD 330i 3.0 AT Gasoline 2996 cm³ 272 hp 200 kW 315 N⋅m Automatic RWD 330xi 3.0 MT Gasoline 2996 cm³ 272 hp 200 kW 315 N⋅m Manual AWD 330i 3.0 MT Gasoline 2996 cm³ 272 hp 200 kW 315 N⋅m Manual RWD 335xi 3.0 AT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Automatic AWD 335xi 3.0 MT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Manual AWD 316i 1.8 MT Gasoline 1796 cm³ 116 hp 85 kW 175 N⋅m Manual RWD 318i 2.0 MT Gasoline 1995 cm³ 143 hp 105 kW 190 N⋅m Manual RWD 318i 2.0 AT Gasoline 1995 cm³ 143 hp 105 kW 190 N⋅m Automatic RWD 320i 2.0 MT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Manual RWD 320i 2.0 AT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Automatic RWD 323i 2.5 MT Gasoline 2497 cm³ 177 hp 130 kW 230 N⋅m Manual RWD 323i 2.5 AT Gasoline 2497 cm³ 177 hp 130 kW 230 N⋅m Automatic RWD 335i 3.0 AT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Automatic RWD 335i 3.0 MT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Manual RWD 325i 3.0 MT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Manual RWD 325i 3.0 AT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Automatic RWD 325xi 3.0 MT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Manual AWD 325xi 3.0 AT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Automatic AWD 328xi 3.0 MT Gasoline 2996 cm³ 234 hp 172 kW 271 N⋅m Manual AWD 328i 3.0 MT Gasoline 2996 cm³ 234 hp 172 kW 271 N⋅m Manual RWD 328i 3.0 AT Gasoline 2996 cm³ 234 hp 172 kW 271 N⋅m Automatic RWD 328xi 3.0 AT Gasoline 2996 cm³ 234 hp 172 kW 271 N⋅m Automatic AWD 330i 3.0 AT Gasoline 2996 cm³ 258 hp 190 kW 300 N⋅m Automatic RWD 330i 3.0 MT Gasoline 2996 cm³ 258 hp 190 kW 300 N⋅m Manual RWD 320xd 2.0 MT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Manual AWD 320xd 2.0 AT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Automatic AWD 320d 2.0 MT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Manual RWD 320d 2.0 AT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Automatic RWD 330xd 3.0 MT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Manual AWD 330xd .0 AT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Automatic AWD 316d 2.0 MT Diesel 1995 cm³ 116 hp 85 kW 260 N⋅m Manual RWD 318i 2.0 MT Diesel 1995 cm³ 143 hp 105 kW 320 N⋅m Manual RWD 318i 2.0 AT Diesel 1995 cm³ 143 hp 105 kW 320 N⋅m Automatic RWD 320d 2.0 MT Diesel 1995 cm³ 150 hp 110 kW 330 N⋅m Manual RWD 320d 2.0 MT Diesel 1995 cm³ 163 hp 120 kW 380 N⋅m Manual RWD 320d 2.0 AT Diesel 1995 cm³ 163 hp 120 kW 340 N⋅m Automatic RWD 320d 2.0 MT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Manual RWD 320d 2.0 AT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Automatic RWD 320xd 2.0 MT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Manual AWD 320xd 2.0 AT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Automatic AWD 325d 3.0 AT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Automatic RWD 325d 3.0 MT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Manual RWD 325d 3.0 MT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Manual RWD 325d 3.0 AT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Automatic RWD 330d 3.0 MT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Manual RWD 330d 3.0 AT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Automatic RWD 335d 3.0 AT Diesel 2993 cm³ 286 hp 210 kW 580 N⋅m Automatic RWD 335d 3.0 MT Diesel 2993 cm³ 286 hp 210 kW 580 N⋅m Manual RWD 318i 2.0 AT Gasoline 1995 cm³ 136 hp 100 kW 180 N⋅m Automatic RWD 320i 2.0 MT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Manual RWD 320i 2.0 AT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Automatic RWD 325i 2.5 AT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Automatic RWD 330xi 3.0 AT Gasoline 2996 cm³ 272 hp 200 kW 315 N⋅m Automatic AWD 320d 2.0 AT Diesel 1995 cm³ 150 hp 110 kW 330 N⋅m Automatic RWD
Coupe — BMW 3 Series Engines and Transmissions
Coupe BMW 3 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 320i 2.0 MT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Manual RWD 335xi 3.0 MT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Manual AWD 318i 2.0 MT Gasoline 1995 cm³ 143 hp 105 kW 190 N⋅m Manual RWD 320i 2.0 MT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Manual RWD 320i 2.0 AT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Automatic RWD 320i 2.5 AT Gasoline 2497 cm³ 204 hp 150 kW 250 N⋅m Automatic RWD 320xi 2.5 AT Gasoline 2497 cm³ 204 hp 150 kW 250 N⋅m Automatic AWD 325i 2.5 MT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Manual RWD 325xi 2.5 MT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Manual AWD 325xi 2.5 AT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Automatic AWD 335i 3.0 MT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Manual RWD 325i 3.0 MT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Manual RWD 325i 3.0 AT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Automatic RWD 325xi 3.0 MT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Manual AWD 325xi 3.0 AT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Automatic AWD 328i 3.0 MT Gasoline 2996 cm³ 233 hp 171 kW 271 N⋅m Manual RWD 328i 3.0 AT Gasoline 2996 cm³ 233 hp 171 kW 271 N⋅m Automatic RWD 328xi 3.0 MT Gasoline 2996 cm³ 233 hp 171 kW 271 N⋅m Manual AWD 328xi 3.0 AT Gasoline 2996 cm³ 233 hp 171 kW 271 N⋅m Automatic AWD 330i 3.0 MT Gasoline 2996 cm³ 272 hp 200 kW 315 N⋅m Manual RWD 330i 3.0 AT Gasoline 2996 cm³ 272 hp 200 kW 315 N⋅m Automatic RWD 330xi 3.0 MT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Manual AWD 330xi 3.0 AT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Automatic AWD 320d 2.0 MT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Manual RWD 320d 2.0 AT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Automatic RWD 320xd 2.0 MT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Manual AWD 320xd 2.0 AT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Automatic AWD 325d 3.0 MT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Manual RWD 325d 3.0 AT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Automatic RWD 325d 3.0 MT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Manual RWD 325d 3.0 AT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Automatic RWD 330d 3.0 MT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Manual RWD 330d 3.0 AT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Automatic RWD 330xd 3.0 MT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Manual AWD 330xd 3.0 AT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Automatic AWD 335d 3.0 AT Diesel 2993 cm³ 286 hp 210 kW 580 N⋅m Automatic RWD 320i 2.0 AT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Automatic RWD 335xi 3.0 AT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Automatic AWD 325i 2.5 AT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Automatic RWD 335i 3.0 DSG Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Robotic RWD 330i 3.0 AT Gasoline 2996 cm³ 258 hp 190 kW 300 N⋅m Automatic RWD
Estate 5-door — BMW 3 Series Engines and Transmissions
Estate 5-door BMW 3 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 320i 2.0 MT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Manual RWD 320i 2.0 AT Gasoline 1995 cm³ 156 hp 115 kW 200 N⋅m Automatic RWD 325i 2.5 AT Gasoline 2479 cm³ 218 hp 160 kW 250 N⋅m Automatic RWD 325i 2.5 MT Gasoline 2479 cm³ 218 hp 160 kW 250 N⋅m Manual RWD 325xi 2.5 MT Gasoline 2479 cm³ 218 hp 160 kW 250 N⋅m Manual AWD 325xi 2.5 AT Gasoline 2479 cm³ 218 hp 160 kW 250 N⋅m Automatic AWD 316i 1.6 MT Gasoline 1599 cm³ 122 hp 90 kW 160 N⋅m Manual RWD 316i 1.6 AT Gasoline 1599 cm³ 122 hp 90 kW 160 N⋅m Automatic RWD 318i 2.0 MT Gasoline 1995 cm³ 143 hp 105 kW 190 N⋅m Manual RWD 318i 2.0 AT Gasoline 1995 cm³ 143 hp 105 kW 190 N⋅m Automatic RWD 320i 2.0 MT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Manual RWD 320i 2.0 AT Gasoline 1995 cm³ 170 hp 125 kW 210 N⋅m Automatic RWD 335i 3.0 MT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Manual RWD 335i 3.0 AT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Automatic RWD 335xi 3.0 MT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Manual AWD 335xi 3.0 AT Gasoline 2979 cm³ 306 hp 225 kW 400 N⋅m Automatic AWD 325i 3.0 MT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Manual RWD 325i 3.0 AT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Automatic RWD 325xi 3.0 MT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Manual AWD 325xi 3.0 AT Gasoline 2996 cm³ 218 hp 160 kW 270 N⋅m Automatic AWD 330i 3.0 AT Gasoline 2996 cm³ 258 hp 190 kW 300 N⋅m Automatic RWD 330i 3.0 MT Gasoline 2996 cm³ 258 hp 190 kW 300 N⋅m Manual RWD 330i 3.0 MT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Manual RWD 330i 3.0 AT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Automatic RWD 330xi 3.0 MT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Manual AWD 330xi 3.0 AT Gasoline 2996 cm³ 272 hp 200 kW 320 N⋅m Automatic AWD 320d 2.0 AT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Automatic RWD 320d 2.0 MT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Manual RWD 330xd 3.0 MT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Manual AWD 330xd 3.0 AT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Automatic AWD 335d 3.0 AT Diesel 2993 cm³ 286 hp 210 kW 580 N⋅m Automatic RWD 316d 2.0 MT Diesel 1995 cm³ 115 hp 85 kW 260 N⋅m Manual RWD 318d 2.0 MT Diesel 1995 cm³ 143 hp 105 kW 320 N⋅m Manual RWD 318d 2.0 AT Diesel 1995 cm³ 143 hp 105 kW 320 N⋅m Automatic RWD 320d 2.0 MT Diesel 1995 cm³ 163 hp 120 kW 380 N⋅m Manual RWD 320xd 2.0 AT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Automatic AWD 320xd 2.0 MT Diesel 1995 cm³ 177 hp 130 kW 350 N⋅m Manual AWD 320d 2.0 MT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Manual RWD 320d 2.0 AT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Automatic RWD 320xd 2.0 MT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Manual AWD 320xd 2.0 AT Diesel 1995 cm³ 184 hp 135 kW 380 N⋅m Automatic AWD 325d 3.0 MT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Manual RWD 325d 3.0 AT Diesel 2993 cm³ 197 hp 145 kW 410 N⋅m Automatic RWD 325d 3.0 MT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Manual RWD 325d 3.0 AT Diesel 2993 cm³ 204 hp 150 kW 430 N⋅m Automatic RWD 330d 3.0 MT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Manual RWD 330d 3.0 AT Diesel 2993 cm³ 245 hp 180 kW 520 N⋅m Automatic RWD
BMW 3 Series Dimensions
Cabrio — BMW 3 Series Dimensions
Cabrio BMW 3 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 320i 2.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1670 kg 2025 kg 138 mm 325i 2.5 AT 4580 mm 1782 mm 1384 mm 2760 mm 1760 kg 2115 kg 138 mm 325i 2.5 MT 4580 mm 1782 mm 1384 mm 2760 mm 1730 kg 2085 kg 138 mm 335i 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1735 kg 2165 kg 138 mm 320i 2.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1595 kg 2025 kg 138 mm 323i 2.5 MT 4580 mm 1782 mm 1384 mm 2760 mm 1730 kg Not provided 143 mm 325i 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1655 kg 2085 kg 138 mm 328i 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1525 kg 1970 kg 143 mm 328i 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1720 kg 2120 kg 143 mm 330i 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1780 kg Not provided 143 mm 330i 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1705 kg 2135 kg 138 mm 330i 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1720 kg 2150 kg 138 mm 320d 2.0 AT 4580 mm 1782 mm 1384 mm 2760 mm Not provided Not provided 143 mm 320d 2.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1670 kg Not provided 143 mm 320d 2.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1655 kg 2085 kg 138 mm 320d 2.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1670 kg 2100 kg 138 mm 325d 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm Not provided Not provided 143 mm 325d 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1670 kg Not provided 143 mm 325d 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1740 kg 2170 kg 138 mm 330d 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1670 kg Not provided 143 mm 330d 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm Not provided Not provided 143 mm 330d 3.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1750 kg 2180 kg 138 mm 330d 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1765 kg 2195 kg 138 mm 320i 2.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1670 kg 2025 kg 138 mm 335i 3.0 DSG 4580 mm 1782 mm 1384 mm 2760 mm 1750 kg 2180 kg 138 mm 318i 2.0 MT 4580 mm 1782 mm 1384 mm 2760 mm 1595 kg 2025 kg 138 mm 320i 2.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1625 kg 2055 kg 138 mm 325i 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1685 kg 2115 kg 138 mm 330i 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1780 kg Not provided 143 mm 325d 3.0 AT 4580 mm 1782 mm 1384 mm 2760 mm 1755 kg 2180 kg 138 mm
Sedan — BMW 3 Series Dimensions
Sedan BMW 3 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 318i 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1880 kg 143 mm 325xi 2.5 MT 4531 mm 1817 mm 1421 mm 2760 mm 1615 kg 2060 kg 144 mm 325xi 2.5 AT 4531 mm 1817 mm 1421 mm 2760 mm 1615 kg 2060 kg 145 mm 325i 2.5 MT 4531 mm 1817 mm 1421 mm 2760 mm 1505 kg 1950 kg 145 mm 330i 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1555 kg 2000 kg 144 mm 330xi 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1655 kg 2100 kg 144 mm 330i 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1555 kg 2000 kg 144 mm 335xi 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1720 kg 2165 kg 144 mm 335xi 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1720 kg 2165 kg 144 mm 316i 1.8 MT 4531 mm 1817 mm 1421 mm 2760 mm 1325 kg 1840 kg 143 mm 318i 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1360 kg 1880 kg 144 mm 318i 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1390 kg 1910 kg 144 mm 320i 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1370 kg 1890 kg 144 mm 320i 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1400 kg 1920 kg 144 mm 323i 2.5 MT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1950 kg 143 mm 323i 2.5 AT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1950 kg 143 mm 335i 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1550 kg 2070 kg 144 mm 335i 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1535 kg 2055 kg 144 mm 325i 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1430 kg 1950 kg 144 mm 325i 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1460 kg 1980 kg 144 mm 325xi 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1540 kg 2060 kg 140 mm 325xi 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1560 kg 2080 kg 140 mm 328xi 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1525 kg 1970 kg 143 mm 328i 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1525 kg 1970 kg 143 mm 328i 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1525 kg 1970 kg 143 mm 328xi 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1635 kg 2115 kg 143 mm 330i 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm Not provided 1970 kg 143 mm 330i 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1525 kg 1970 kg 143 mm 320xd 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1525 kg 1950 kg 144 mm 320xd 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1530 kg 1950 kg 143 mm 320d 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1505 kg 1950 kg 143 mm 320d 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1505 kg 1950 kg 144 mm 330xd 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1635 kg 2155 kg 140 mm 330xd .0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1650 kg 2170 kg 140 mm 316d 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1400 kg 1920 kg 144 mm 318i 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1415 kg 1935 kg 144 mm 318i 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1430 kg 1950 kg 144 mm 320d 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1950 kg 143 mm 320d 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1420 kg 1940 kg 129 mm 320d 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1950 kg 143 mm 320d 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1420 kg 1940 kg 144 mm 320d 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1430 kg 1950 kg 144 mm 320xd 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1525 kg 2045 kg 140 mm 320xd 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1540 kg 2060 kg 140 mm 325d 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1950 kg 143 mm 325d 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1950 kg 143 mm 325d 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1525 kg 2045 kg 144 mm 325d 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1540 kg 2060 kg 144 mm 330d 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1535 kg 2055 kg 144 mm 330d 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1550 kg 2070 kg 144 mm 335d 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1580 kg 2100 kg 144 mm 335d 3.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1655 kg 2100 kg 143 mm 318i 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1880 kg 143 mm 320i 2.0 MT 4531 mm 1817 mm 1421 mm 2760 mm 1445 kg 1890 kg 143 mm 320i 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1445 kg 1890 kg 114 mm 325i 2.5 AT 4531 mm 1817 mm 1421 mm 2760 mm 1505 kg 1950 kg 143 mm 330xi 3.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1655 kg 2100 kg 144 mm 320d 2.0 AT 4531 mm 1817 mm 1421 mm 2760 mm 1435 kg 1950 kg 143 mm
Coupe — BMW 3 Series Dimensions
Coupe BMW 3 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 320i 2.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1670 kg 2025 kg 143 mm 335xi 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1605 kg 2085 kg 143 mm 318i 2.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1360 kg 1810 kg 143 mm 320i 2.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1360 kg 1810 kg 143 mm 320i 2.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1390 kg 1840 kg 143 mm 320i 2.5 AT 4580 mm 1782 mm 1395 mm 2760 mm 1525 kg 1930 kg 143 mm 320xi 2.5 AT 4580 mm 1782 mm 1395 mm 2760 mm 1525 kg 1930 kg 143 mm 325i 2.5 MT 4580 mm 1782 mm 1395 mm 2760 mm 1495 kg 1900 kg 143 mm 325xi 2.5 MT 4580 mm 1782 mm 1395 mm 2760 mm 1605 kg 2010 kg 143 mm 325xi 2.5 AT 4580 mm 1782 mm 1395 mm 2760 mm 1625 kg 2030 kg 143 mm 335i 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1525 kg 2005 kg 143 mm 325i 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1430 kg 1910 kg 143 mm 325i 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1460 kg 1940 kg 143 mm 325xi 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1530 kg 2010 kg 143 mm 325xi 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1550 kg 2030 kg 143 mm 328i 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1525 kg 1945 kg 143 mm 328i 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1555 kg 1975 kg 143 mm 328xi 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1625 kg 2045 kg 143 mm 328xi 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1645 kg 2065 kg 143 mm 330i 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1545 kg 1950 kg 143 mm 330i 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1560 kg 1965 kg 143 mm 330xi 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1565 kg 2045 kg 143 mm 330xi 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1580 kg 2060 kg 143 mm 320d 2.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1420 kg 1900 kg 143 mm 320d 2.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1430 kg 1910 kg 143 mm 320xd 2.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1515 kg 1995 kg 143 mm 320xd 2.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1530 kg 2010 kg 143 mm 325d 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1490 kg 1995 kg 143 mm 325d 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1420 kg Not provided 143 mm 325d 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1515 kg 1995 kg 143 mm 325d 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1530 kg 2010 kg 143 mm 330d 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1525 kg 2005 kg 143 mm 330d 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1540 kg 2020 kg 143 mm 330xd 3.0 MT 4580 mm 1782 mm 1395 mm 2760 mm 1625 kg 2085 kg 143 mm 330xd 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1640 kg 2100 kg 143 mm 335d 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1570 kg 2050 kg 143 mm 320i 2.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1670 kg 2025 kg 143 mm 335xi 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm 1680 kg 2100 kg 143 mm 325i 2.5 AT 4580 mm 1782 mm 1395 mm 2760 mm 1525 kg 1930 kg 143 mm 335i 3.0 DSG 4580 mm 1782 mm 1395 mm 2760 mm 1600 kg Not provided 143 mm 330i 3.0 AT 4580 mm 1782 mm 1395 mm 2760 mm Not provided Not provided 141 mm
Estate 5-door — BMW 3 Series Dimensions
Estate 5-door BMW 3 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 320i 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1505 kg 1970 kg 141 mm 320i 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1505 kg 1970 kg 141 mm 325i 2.5 AT 4527 mm 2013 mm 1418 mm 2760 mm 1615 kg 2080 kg 141 mm 325i 2.5 MT 4527 mm 2013 mm 1418 mm 2760 mm 1585 kg 2050 kg 141 mm 325xi 2.5 MT 4527 mm 2013 mm 1418 mm 2760 mm 1715 kg 2180 kg 141 mm 325xi 2.5 AT 4527 mm 2013 mm 1418 mm 2760 mm 1735 kg 2200 kg 141 mm 316i 1.6 MT 4527 mm 2013 mm 1418 mm 2760 mm Not provided Not provided 141 mm 316i 1.6 AT 4527 mm 2013 mm 1418 mm 2760 mm Not provided Not provided 141 mm 318i 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1430 kg 1970 kg 141 mm 318i 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1460 kg 2000 kg 141 mm 320i 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1430 kg 1970 kg 141 mm 320i 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1460 kg 2000 kg 141 mm 335i 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1595 kg 2135 kg 141 mm 335i 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1610 kg 2150 kg 141 mm 335xi 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1660 kg 2200 kg 140 mm 335xi 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1675 kg 2215 kg 140 mm 325i 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1490 kg 2030 kg 141 mm 325i 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1520 kg 2060 kg 141 mm 325xi 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1640 kg 2180 kg 140 mm 325xi 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1660 kg 2200 kg 140 mm 330i 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm Not provided 2070 kg 141 mm 330i 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1535 kg 2070 kg 141 mm 330i 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1540 kg 2080 kg 141 mm 330i 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1555 kg 2095 kg 141 mm 330xi 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1640 kg 2180 kg 140 mm 330xi 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1660 kg 2200 kg 140 mm 320d 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1595 kg 2060 kg 141 mm 320d 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1580 kg 2045 kg 141 mm 330xd 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1700 kg 2240 kg 140 mm 330xd 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1715 kg 2255 kg 140 mm 335d 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1645 kg 2185 kg 141 mm 316d 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1475 kg 2015 kg 141 mm 318d 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1490 kg 2030 kg 141 mm 318d 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1505 kg 2045 kg 141 mm 320d 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1505 kg 2045 kg 126 mm 320xd 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm Not provided 2045 kg 141 mm 320xd 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1580 kg 2045 kg 141 mm 320d 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1505 kg 2045 kg 141 mm 320d 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1520 kg 2060 kg 141 mm 320xd 2.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1590 kg 2130 kg 140 mm 320xd 2.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1605 kg 2145 kg 140 mm 325d 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1510 kg 2045 kg 141 mm 325d 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1575 kg 2155 kg 141 mm 325d 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1590 kg 2130 kg 141 mm 325d 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1605 kg 2145 kg 141 mm 330d 3.0 MT 4527 mm 2013 mm 1418 mm 2760 mm 1600 kg 2140 kg 141 mm 330d 3.0 AT 4527 mm 2013 mm 1418 mm 2760 mm 1615 kg 2155 kg 141 mm
BMW 3 Series Cargo Space
Cabrio — BMW 3 Series Cargo Space
Sedan — BMW 3 Series Cargo Space
Coupe — BMW 3 Series Cargo Space
Estate 5-door — BMW 3 Series Cargo Space
BMW 3 Series Trims and Equipment
BMW 3 Series trim levels sit on top of a technical version rather than replacing it: the 325xi 2.5 AT Sedan, for instance, is offered as 325 Business Plus and 325 Business Plus Navi. Such equipment packages usually group comfort and infotainment features, with navigation marking the higher option here.
