Catalog / BMW / 02 (E10) / 1 generation
BMW 02 (E10) Engines and Transmissions
Every BMW 02 (E10) engine is a gasoline four-cylinder driving the rear wheels, so the character changes mainly with displacement. Smaller units such as the 1.6 MT Cabrio stay light and eager, while the 1.8 MT and the automatic 2.0 AT Sedan add relaxed pulling power. Manual transmissions dominate; automatics suit calmer driving.
Cabrio — BMW 02 (E10) Engines and Transmissions
Cabrio BMW 02 (E10) Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Gasoline 1574 cm³ 85 hp 63 kW 130 N⋅m Manual RWD
Sedan 2-doors — BMW 02 (E10) Engines and Transmissions
Sedan 2-doors BMW 02 (E10) Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Gasoline 1573 cm³ 105 hp 78 kW 131 N⋅m Manual RWD 1.8 MT Gasoline 1766 cm³ 90 hp 66 kW 146 N⋅m Manual RWD 2.0 MT Gasoline 1991 cm³ 101 hp 74 kW 157 N⋅m Manual RWD 2.0 MT Gasoline 1991 cm³ 120 hp 88 kW 167 N⋅m Manual RWD 2.0 MT Gasoline 1991 cm³ 132 hp 97 kW 178 N⋅m Manual RWD 2.0 MT Gasoline 1991 cm³ 170 hp 125 kW 240 N⋅m Manual RWD 1.6 MT Gasoline 1573 cm³ 74 hp 54 kW 118 N⋅m Manual RWD 1.6 MT Gasoline 1573 cm³ 83 hp 61 kW Not provided Manual RWD 2.0 AT Gasoline 1991 cm³ 101 hp 74 kW 157 N⋅m Automatic RWD
Hatchback 3-door — BMW 02 (E10) Engines and Transmissions
Hatchback 3-door BMW 02 (E10) Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Gasoline 1574 cm³ 85 hp 63 kW 130 N⋅m Manual RWD 1.8 MT Gasoline 1766 cm³ 91 hp 67 kW 144 N⋅m Manual RWD 2.0 MT Gasoline 1991 cm³ 99 hp 73 kW 157 N⋅m Manual RWD 2.0 MT Gasoline 1991 cm³ 132 hp 97 kW 177 N⋅m Manual RWD
BMW 02 (E10) Dimensions
Cabrio — BMW 02 (E10) Dimensions
Cabrio BMW 02 (E10) Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 1.6 MT 4230 mm 1590 mm 1360 mm 2500 mm 980 kg 160 mm
Sedan 2-doors — BMW 02 (E10) Dimensions
Sedan 2-doors BMW 02 (E10) Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 1.6 MT 4230 mm 1590 mm 1410 mm 2500 mm 960 kg 160 mm 1.8 MT 4230 mm 1590 mm 1410 mm 2500 mm 970 kg 160 mm 2.0 MT 4230 mm 1590 mm 1410 mm 2500 mm 940 kg 160 mm 2.0 MT 4230 mm 1590 mm 1410 mm 2500 mm 960 kg 160 mm 2.0 MT 4230 mm 1590 mm 1410 mm 2500 mm 1026 kg 160 mm 2.0 MT 4230 mm 1590 mm 1410 mm 2500 mm 1060 kg Not provided 1.6 MT 4230 mm 1590 mm 1410 mm 2500 mm 980 kg 160 mm 1.6 MT 4230 mm 1590 mm 1410 mm 2500 mm 940 kg 160 mm 2.0 AT 4230 mm 1590 mm 1410 mm 2500 mm 995 kg 160 mm
Hatchback 3-door — BMW 02 (E10) Dimensions
Hatchback 3-door BMW 02 (E10) Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 1.6 MT 4110 mm 1590 mm 1380 mm 2500 mm 1030 kg 160 mm 1.8 MT 4110 mm 1590 mm 1380 mm 2500 mm 1030 kg 160 mm 2.0 MT 4110 mm 1590 mm 1380 mm 2500 mm 1030 kg 160 mm 2.0 MT 4110 mm 1590 mm 1380 mm 2500 mm 1070 kg 140 mm
