Toyota Camry Wheel Bolt Pattern and Offset

Direct Answer for the 2009 Toyota Camry

The 2009 Toyota Camry uses a 5x114.3 mm wheel bolt pattern. This means the wheel has five lug holes arranged on a circle with a diameter of 114.3 millimeters. The pattern is shared across most Camry generations from the late 1990s through the early 2010s, but offset, center bore, and lug nut requirements differ by year and wheel size.

Bolt Pattern by Camry Model Year

Several Camry model years share the 5x114.3 mm bolt pattern. This includes the 1998, 2002, 2003, 2005, 2007, 2009, and 2010 model years. While the bolt circle is consistent, the wheel offset and center bore can vary, particularly between generations and between factory wheel options.

Model Year | Bolt Pattern | Typical Center Bore | Common Factory Offset; 1998 | 5x114.3 mm | 60.1 mm | +45 mm; 2002 | 5x114.3 mm | 60.1 mm | +45 mm; 2003 | 5x114.3 mm | 60.1 mm | +45 mm; 2005 | 5x114.3 mm | 60.1 mm | +45 mm; 2007 | 5x114.3 mm | 60.1 mm | +45 mm; 2009 | 5x114.3 mm | 60.1 mm | +45 mm; 2010 | 5x114.3 mm | 60.1 mm | +45 mm

Wheel Offset for the 2010 Camry

For the 2010 Toyota Camry, the factory wheel offset is approximately +45 mm. Offset is the distance from the wheel's mounting surface to the centerline of the wheel. A positive offset means the mounting surface sits outward from the centerline. For most stock Camry wheels in this generation, the acceptable offset range is roughly +38 mm to +45 mm. Using a significantly lower or higher offset can cause tire rubbing, increased bearing wear, or altered steering feel.

Qualification and Practical Fitment

The 5x114.3 mm specification applies to the standard four-cylinder and V6 Camry trims for the listed years. Hybrid models from the same period also use 5x114.3 mm, but their recommended wheel weights and aerodynamic characteristics may differ. Always confirm the specific wheel offset stamped on the back of a factory wheel before swapping. Aftermarket wheels with the correct bolt pattern but an offset outside the factory range may require hub-centric rings or fender modifications.

Lug Nuts and Thread Pitch

The Camry models covered here use a 12x1.5 mm thread pitch for the wheel studs. Lug nuts must match this thread pitch. The factory lug nut seat is a conical, or acorn, style. Using a flat or ball-seat lug nut on a conical seat, or vice versa, will not safely secure the wheel.

What This Means for Wheel Shopping

When selecting wheels for a 2009 or related Camry, start with the 5x114.3 mm bolt pattern. Then check the center bore. The Camry's 60.1 mm center bore is common, but many aftermarket wheels use a larger bore to fit multiple vehicles. If the wheel's center bore is larger than 60.1 mm, hub-centric rings sized to 60.1 mm inner diameter are required for a vibration-free fit. Wheels with a smaller center bore than 60.1 mm will not mount without machining, which is not recommended for a daily driver.

Data Gaps and Uncertainty

Factory offset can vary by a few millimeters depending on the specific wheel option, such as 16-inch steel wheels versus 17-inch alloy wheels. The +45 mm figure is the most common offset, but a small number of Camry alloy wheels from these years were listed with offsets from +40 mm to +50 mm. Without a specific wheel part number or a stamping on the original wheel, the exact offset cannot be confirmed from model year alone.
