Audi TT Specs, Engines & Dimensions (2010–2014)

Audi TT Engines and Transmissions

Each Audi TT engine is turbocharged, so strong pull arrives early rather than at high revs. A 1.8 Coupe with manual gearbox and front-wheel drive suits drivers who like simplicity, while 2.0 versions with the S-tronic dual-clutch transmission and quattro all-wheel drive add quicker shifts and surer traction; diesel powertrains favour economy over outright response.

Coupe — Audi TT Engines and Transmissions

Coupe Audi TT Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1798 cm³	160 hp	118 kW	250 N⋅m	Manual	FWD
2.0 S-tronic	Gasoline	1984 cm³	211 hp	155 kW	350 N⋅m	Robotic	AWD
2.0 MT	Diesel	1968 cm³	170 hp	125 kW	350 N⋅m	Manual	AWD
2.0 S-tronic	Diesel	1968 cm³	170 hp	125 kW	350 N⋅m	Robotic	AWD
1.8 S-tronic	Gasoline	1798 cm³	160 hp	118 kW	250 N⋅m	Robotic	FWD
2.0 MT	Gasoline	1984 cm³	211 hp	155 kW	350 N⋅m	Manual	FWD
2.0 S-tronic	Gasoline	1984 cm³	211 hp	155 kW	350 N⋅m	Robotic	FWD

Roadster — Audi TT Engines and Transmissions

Roadster Audi TT Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 S-tronic	Gasoline	1984 cm³	211 hp	155 kW	350 N⋅m	Robotic	AWD
1.8 MT	Gasoline	1798 cm³	160 hp	118 kW	250 N⋅m	Manual	FWD
2.0 MT	Gasoline	1984 cm³	211 hp	155 kW	350 N⋅m	Manual	FWD
2.0 MT	Diesel	1968 cm³	170 hp	125 kW	350 N⋅m	Manual	AWD
2.0 S-tronic	Diesel	1968 cm³	170 hp	125 kW	350 N⋅m	Robotic	AWD
1.8 S-tronic	Gasoline	1798 cm³	160 hp	118 kW	250 N⋅m	Robotic	FWD
2.0 S-tronic	Gasoline	1984 cm³	211 hp	155 kW	350 N⋅m	Robotic	FWD

Audi TT Dimensions

Coupe — Audi TT Dimensions

Coupe Audi TT Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4198 mm	1842 mm	1353 mm	2468 mm	1260 kg	1660 kg	130 mm
2.0 S-tronic	4198 mm	1842 mm	1353 mm	2468 mm	1380 kg	1780 kg	130 mm
2.0 MT	4198 mm	1842 mm	1353 mm	2468 mm	1390 kg	1790 kg	130 mm
2.0 S-tronic	4198 mm	1842 mm	1353 mm	2468 mm	1415 kg	1815 kg	130 mm
1.8 S-tronic	4198 mm	1842 mm	1353 mm	2468 mm	1280 kg	1680 kg	Not provided
2.0 MT	4198 mm	1842 mm	1353 mm	2468 mm	1280 kg	1680 kg	130 mm
2.0 S-tronic	4198 mm	1842 mm	1353 mm	2468 mm	1300 kg	1700 kg	130 mm

Roadster — Audi TT Dimensions

Roadster Audi TT Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 S-tronic	4198 mm	1842 mm	1358 mm	2468 mm	1425 kg	1745 kg	130 mm
1.8 MT	4198 mm	1842 mm	1358 mm	2468 mm	1305 kg	1625 kg	130 mm
2.0 MT	4198 mm	1842 mm	1358 mm	2468 mm	1390 kg	1615 kg	130 mm
2.0 MT	4198 mm	1842 mm	1358 mm	2468 mm	1430 kg	1750 kg	130 mm
2.0 S-tronic	4198 mm	1842 mm	1358 mm	2468 mm	1460 kg	1780 kg	130 mm
1.8 S-tronic	4198 mm	1842 mm	1358 mm	2468 mm	1320 kg	1640 kg	130 mm
2.0 S-tronic	4198 mm	1842 mm	1358 mm	2468 mm	1320 kg	1640 kg	130 mm

Audi TT Cargo Space

Coupe — Audi TT Cargo Space

Coupe Audi TT Cargo Space
Modification	Trunk volume min	Trunk volume max
1.8 MT	292 l	700 l
2.0 S-tronic	292 l	700 l
2.0 MT	292 l	700 l
2.0 S-tronic	292 l	700 l
1.8 S-tronic	292 l	700 l
2.0 MT	292 l	700 l
2.0 S-tronic	292 l	700 l

Roadster — Audi TT Cargo Space

Roadster Audi TT Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 S-tronic	250 l	700 l
1.8 MT	250 l	700 l
2.0 MT	250 l	700 l
2.0 MT	250 l	700 l
2.0 S-tronic	250 l	700 l
1.8 S-tronic	250 l	700 l
2.0 S-tronic	250 l	700 l

Audi TT Trims and Equipment

Audi TT trim levels sit on top of the technical version rather than replacing it: the 1.8 manual Coupe is offered in Base equipment, which already covers the essentials expected of a sports coupe. Much of the appeal came from options, so two cars sharing one engine can differ widely in seats, lighting and infotainment.

Audi TT Trims and Equipment
Modification	Body	Equipment
1.8 MT	Coupe	Base
1.8 S-tronic	Roadster	Base
