Aston Martin Vantage Specs, Engines & Dimensions (1969–1989)

Aston Martin Vantage Engines and Transmissions

Every Aston Martin Vantage engine here is gasoline-fuelled and naturally aspirated, mounted well back for balance and driving rear wheels through a transaxle. The powertrain rewards revs rather than low-speed shove, and transmission choices typically span a conventional manual or a paddle-operated automated gearbox, depending on the individual car.

Cabrio — Aston Martin Vantage Engines and Transmissions

Cabrio Aston Martin Vantage Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Transmission	Type of drive
5.3 MT	Gasoline	5340 cm³	340 hp	250 kW	Manual	RWD
5.3 AT	Gasoline	5340 cm³	340 hp	250 kW	Automatic	RWD
5.3 AT	Gasoline	5340 cm³	375 hp	276 kW	Automatic	RWD
5.3 MT	Gasoline	5340 cm³	375 hp	276 kW	Manual	RWD

Coupe — Aston Martin Vantage Engines and Transmissions

Coupe Aston Martin Vantage Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Transmission	Type of drive
5.3 AT	Gasoline	5340 cm³	340 hp	250 kW	Automatic	RWD
5.3 MT	Gasoline	5340 cm³	340 hp	250 kW	Manual	RWD
5.3 MT	Gasoline	5340 cm³	375 hp	276 kW	Manual	RWD
5.3 AT	Gasoline	5340 cm³	375 hp	276 kW	Automatic	RWD

Aston Martin Vantage Dimensions

Cabrio — Aston Martin Vantage Dimensions

Cabrio Aston Martin Vantage Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
5.3 MT	4585 mm	1830 mm	1330 mm	2611 mm	1815 kg	140 mm
5.3 AT	4585 mm	1830 mm	1330 mm	2611 mm	1815 kg	140 mm
5.3 AT	4585 mm	1830 mm	1330 mm	2611 mm	1815 kg	140 mm
5.3 MT	4585 mm	1830 mm	1330 mm	2611 mm	1815 kg	140 mm

Coupe — Aston Martin Vantage Dimensions

Coupe Aston Martin Vantage Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
5.3 AT	4585 mm	1830 mm	1330 mm	2611 mm	Not provided	140 mm
5.3 MT	4585 mm	1830 mm	1330 mm	2611 mm	1820 kg	140 mm
5.3 MT	4585 mm	1830 mm	1330 mm	2611 mm	Not provided	140 mm
5.3 AT	4585 mm	1830 mm	1330 mm	2611 mm	Not provided	140 mm
