Aston Martin V12 Vantage Specs, Engines & Dimensions (2009–2017)

Aston Martin V12 Vantage Engines and Transmissions

The Aston Martin V12 Vantage engine runs on gasoline and drives the rear wheels. Selected examples include the 5.9 MT Roadster and 5.9 Sportshift versions of both bodies. The manual gives you direct clutch control; Sportshift automates clutch operation, though its automated manual design can feel less smooth in traffic than a conventional automatic.

Coupe — Aston Martin V12 Vantage Engines and Transmissions

Coupe Aston Martin V12 Vantage Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
5.9 MT	Gasoline	5935 cm³	517 hp	380 kW	570 N⋅m	Manual	RWD
5.9 MT	Gasoline	5935 cm³	573 hp	421 kW	620 N⋅m	Manual	RWD
5.9 MT	Gasoline	5935 cm³	600 hp	441 kW	690 N⋅m	Manual	RWD
5.9 Sportshift	Gasoline	5935 cm³	573 hp	421 kW	620 N⋅m	Robotic	RWD

Roadster — Aston Martin V12 Vantage Engines and Transmissions

Roadster Aston Martin V12 Vantage Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
5.9 MT	Gasoline	5935 cm³	517 hp	380 kW	570 N⋅m	Manual	RWD
5.9 Sportshift	Gasoline	5935 cm³	573 hp	421 kW	620 N⋅m	Robotic	RWD

Aston Martin V12 Vantage Dimensions

Coupe — Aston Martin V12 Vantage Dimensions

Coupe Aston Martin V12 Vantage Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
5.9 MT	4385 mm	1865 mm	1250 mm	2600 mm	1680 kg	2000 kg	110 mm
5.9 MT	4385 mm	1865 mm	1250 mm	2600 mm	1676 kg	Not provided	110 mm
5.9 MT	4385 mm	1865 mm	1250 mm	2600 mm	1600 kg	Not provided	110 mm
5.9 Sportshift	4385 mm	1865 mm	1250 mm	2600 mm	1680 kg	Not provided	110 mm

Roadster — Aston Martin V12 Vantage Dimensions

Roadster Aston Martin V12 Vantage Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
5.9 MT	4385 mm	1865 mm	1250 mm	2600 mm	1760 kg	1980 kg	110 mm
5.9 Sportshift	4385 mm	1865 mm	1250 mm	2600 mm	1745 kg	Not provided	110 mm

Aston Martin V12 Vantage Cargo Space

Coupe — Aston Martin V12 Vantage Cargo Space

Coupe Aston Martin V12 Vantage Cargo Space
Modification	Trunk volume min
5.9 MT	300 l
5.9 MT	300 l
5.9 MT	300 l
5.9 Sportshift	300 l

Roadster — Aston Martin V12 Vantage Cargo Space

Roadster Aston Martin V12 Vantage Cargo Space
Modification	Trunk volume min
5.9 MT	144 l
5.9 Sportshift	144 l

Aston Martin V12 Vantage Trims and Equipment

When exploring Aston Martin V12 Vantage trim levels, distinguish equipment names from powertrain designations: V12 Vantage Carbon Black is an equipment configuration associated with the 5.9 Sportshift Coupe. For an individual car, check its fitted features and options, since the technical version alone does not establish its full equipment specification.

Aston Martin V12 Vantage Trims and Equipment
Modification	Body	Equipment
5.9 MT	Coupe	V12 Vantage Carbon Black
5.9 MT	Coupe	V12 Vantage Carbon Black
5.9 MT	Coupe	V12 Vantage Carbon Black
5.9 Sportshift	Coupe	V12 Vantage Carbon Black
5.9 MT	Roadster	V12 Vantage Carbon Black
5.9 Sportshift	Roadster	V12 Vantage Carbon Black

Aston Martin V12 Vantage Specs, Engines & Dimensions (2009–2017) — First Generation
