Aston Martin DB9 Specs, Engines & Dimensions (2003–2008)

Aston Martin DB9 Engines and Transmissions

The Aston Martin DB9 engine is a 5.9 gasoline unit shared by Coupe and Cabrio bodies. Selected examples include the 5.9 MT manual and 5.9 AT automatic, both rear-wheel drive. Your transmission choice is what changes how the powertrain and drivetrain feel day to day.

Cabrio — Aston Martin DB9 Engines and Transmissions

Cabrio Aston Martin DB9 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
5.9 MT	Gasoline	5935 cm³	450 hp	331 kW	570 N⋅m	Manual	RWD
5.9 AT	Gasoline	5935 cm³	450 hp	331 kW	570 N⋅m	Automatic	RWD

Coupe — Aston Martin DB9 Engines and Transmissions

Coupe Aston Martin DB9 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
5.9 MT	Gasoline	5935 cm³	450 hp	331 kW	570 N⋅m	Manual	RWD
5.9 AT	Gasoline	5935 cm³	450 hp	331 kW	570 N⋅m	Automatic	RWD

Aston Martin DB9 Dimensions

Cabrio — Aston Martin DB9 Dimensions

Cabrio Aston Martin DB9 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
5.9 MT	4697 mm	1875 mm	1318 mm	2745 mm	1800 kg	2045 kg	110 mm
5.9 AT	4697 mm	1875 mm	1318 mm	2745 mm	1800 kg	2045 kg	110 mm

Coupe — Aston Martin DB9 Dimensions

Coupe Aston Martin DB9 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
5.9 MT	4697 mm	1875 mm	1318 mm	2745 mm	1800 kg	2045 kg	110 mm
5.9 AT	4697 mm	1875 mm	1318 mm	2745 mm	1800 kg	2045 kg	110 mm

Aston Martin DB9 Cargo Space

Cabrio — Aston Martin DB9 Cargo Space

Cabrio Aston Martin DB9 Cargo Space
Modification	Trunk volume min
5.9 MT	197 l
5.9 AT	197 l

Coupe — Aston Martin DB9 Cargo Space

Coupe Aston Martin DB9 Cargo Space
Modification	Trunk volume min
5.9 MT	170 l
5.9 AT	170 l
