Catalog / Volkswagen / Quantum / 1 generation
Volkswagen Quantum Engines and Transmissions
Volkswagen Quantum engine and transmission choices include the 1.8 AT sedan, whose automatic reduces effort in stop-start traffic. The 1.8 MT and 2.0 MT sedans give you direct control over gear selection through a manual transmission. These examples all use gasoline engines and front-wheel drive.
Sedan — Volkswagen Quantum Engines and Transmissions
Sedan Volkswagen Quantum Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 AT Gasoline 1781 cm³ 90 hp 66 kW 152 N⋅m Automatic FWD 1.8 MT Gasoline 1781 cm³ 90 hp 66 kW 152 N⋅m Manual FWD 2.0 MT Gasoline 1984 cm³ 114 hp 84 kW 172 N⋅m Manual FWD 2.0 AT Gasoline 1984 cm³ 114 hp 84 kW 172 N⋅m Automatic FWD
Estate 5-door — Volkswagen Quantum Engines and Transmissions
Estate 5-door Volkswagen Quantum Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 AT Gasoline 1781 cm³ 90 hp 66 kW 152 N⋅m Automatic FWD 1.8 MT Gasoline 1781 cm³ 90 hp 66 kW 152 N⋅m Manual FWD 2.0 MT Gasoline 1984 cm³ 114 hp 84 kW 172 N⋅m Manual FWD 2.0 AT Gasoline 1984 cm³ 114 hp 84 kW 172 N⋅m Automatic FWD
Volkswagen Quantum Dimensions
Sedan — Volkswagen Quantum Dimensions
Sedan Volkswagen Quantum Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 AT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm 1.8 MT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm 2.0 MT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm 2.0 AT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm
Estate 5-door — Volkswagen Quantum Dimensions
Estate 5-door Volkswagen Quantum Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 AT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm 1.8 MT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm 2.0 MT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm 2.0 AT 4633 mm 1700 mm 1511 mm 2550 mm 1125 kg 1585 kg 150 mm
Volkswagen Quantum Cargo Space
Estate 5-door — Volkswagen Quantum Cargo Space
Estate 5-door Volkswagen Quantum Cargo Space Modification Trunk volume min Trunk volume max
1.8 AT 470 l 1535 l 1.8 MT 470 l 1535 l 2.0 MT 470 l 1535 l 2.0 AT 470 l 1535 l
