Volkswagen Quantum Specs, Engines & Dimensions (1985–1988)

Volkswagen Quantum Engines and Transmissions

Volkswagen Quantum engine and transmission choices include the 1.8 AT sedan, whose automatic reduces effort in stop-start traffic. The 1.8 MT and 2.0 MT sedans give you direct control over gear selection through a manual transmission. These examples all use gasoline engines and front-wheel drive.

Sedan — Volkswagen Quantum Engines and Transmissions

Sedan Volkswagen Quantum Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 AT	Gasoline	1781 cm³	90 hp	66 kW	152 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1781 cm³	90 hp	66 kW	152 N⋅m	Manual	FWD
2.0 MT	Gasoline	1984 cm³	114 hp	84 kW	172 N⋅m	Manual	FWD
2.0 AT	Gasoline	1984 cm³	114 hp	84 kW	172 N⋅m	Automatic	FWD

Estate 5-door — Volkswagen Quantum Engines and Transmissions

Estate 5-door Volkswagen Quantum Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 AT	Gasoline	1781 cm³	90 hp	66 kW	152 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1781 cm³	90 hp	66 kW	152 N⋅m	Manual	FWD
2.0 MT	Gasoline	1984 cm³	114 hp	84 kW	172 N⋅m	Manual	FWD
2.0 AT	Gasoline	1984 cm³	114 hp	84 kW	172 N⋅m	Automatic	FWD

Volkswagen Quantum Dimensions

Sedan — Volkswagen Quantum Dimensions

Sedan Volkswagen Quantum Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 AT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm
1.8 MT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm
2.0 MT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm
2.0 AT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm

Estate 5-door — Volkswagen Quantum Dimensions

Estate 5-door Volkswagen Quantum Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 AT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm
1.8 MT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm
2.0 MT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm
2.0 AT	4633 mm	1700 mm	1511 mm	2550 mm	1125 kg	1585 kg	150 mm

Volkswagen Quantum Cargo Space

Estate 5-door — Volkswagen Quantum Cargo Space

Estate 5-door Volkswagen Quantum Cargo Space
Modification	Trunk volume min	Trunk volume max
1.8 AT	470 l	1535 l
1.8 MT	470 l	1535 l
2.0 MT	470 l	1535 l
2.0 AT	470 l	1535 l
