Volkswagen Golf GTI Specs, Engines & Dimensions (2017–2019)

Volkswagen Golf GTI Engines and Transmissions

You get a Volkswagen Golf GTI engine that is a 2.0-liter gasoline unit with a front-wheel-drive drivetrain. Selected examples include the 2.0 MT manual on Hatchback 5-door and Hatchback 3-door bodies, plus a 2.0L DSG that pairs the same powertrain with a robotic transmission on the five-door.

Hatchback 5-door — Volkswagen Golf GTI Engines and Transmissions

Hatchback 5-door Volkswagen Golf GTI Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1984 cm³	230 hp	169 kW	350 N⋅m	Manual	FWD
2.0 DSG	Gasoline	1984 cm³	290 hp	213 kW	380 N⋅m	Robotic	FWD
2.0 DSG	Gasoline	1984 cm³	230 hp	169 kW	350 N⋅m	Robotic	FWD
2.0L DSG	Gasoline	1984 cm³	245 hp	180 kW	377 N⋅m	Robotic	FWD

Hatchback 3-door — Volkswagen Golf GTI Engines and Transmissions

Hatchback 3-door Volkswagen Golf GTI Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1984 cm³	230 hp	169 kW	350 N⋅m	Manual	FWD
2.0 DSG	Gasoline	1984 cm³	290 hp	213 kW	380 N⋅m	Robotic	FWD
2.0L DSG	Gasoline	1984 cm³	245 hp	180 kW	377 N⋅m	Robotic	FWD
2.0 DSG	Gasoline	1984 cm³	230 hp	169 kW	350 N⋅m	Robotic	FWD

Volkswagen Golf GTI Dimensions

Hatchback 5-door — Volkswagen Golf GTI Dimensions

Hatchback 5-door Volkswagen Golf GTI Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4268 mm	1790 mm	1482 mm	2626 mm	1364 kg	1850 kg	133 mm
2.0 DSG	4268 mm	1790 mm	1482 mm	2626 mm	1430 kg	1900 kg	Not provided
2.0 DSG	4268 mm	1790 mm	1482 mm	2626 mm	1386 kg	1870 kg	133 mm
2.0L DSG	4268 mm	1790 mm	1482 mm	2626 mm	1445 kg	1920 kg	133 mm

Hatchback 3-door — Volkswagen Golf GTI Dimensions

Hatchback 3-door Volkswagen Golf GTI Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4268 mm	1790 mm	1442 mm	2626 mm	1364 kg	1850 kg	133 mm
2.0 DSG	4268 mm	1790 mm	1442 mm	2626 mm	1430 kg	1900 kg	Not provided
2.0L DSG	4268 mm	1790 mm	1442 mm	2626 mm	1445 kg	1920 kg	133 mm
2.0 DSG	4268 mm	1790 mm	1442 mm	2626 mm	1386 kg	1870 kg	133 mm

Volkswagen Golf GTI Cargo Space

Hatchback 5-door — Volkswagen Golf GTI Cargo Space

Hatchback 5-door Volkswagen Golf GTI Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 MT	380 l	1270 l
2.0 DSG	380 l	1270 l
2.0 DSG	380 l	1270 l
2.0L DSG	380 l	1270 l

Hatchback 3-door — Volkswagen Golf GTI Cargo Space

Hatchback 3-door Volkswagen Golf GTI Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 MT	380 l	1270 l
2.0 DSG	380 l	1270 l
2.0L DSG	380 l	1270 l
2.0 DSG	380 l	1270 l

Volkswagen Golf GTI Trims and Equipment

Volkswagen Golf GTI trim levels sit on top of the technical version you choose rather than replacing it. On the 2.0L DSG Hatchback 5-door, equipment is grouped under the GTi name, so cabin features and extras can vary while the gasoline robotic front-wheel-drive layout stays the same.

Volkswagen Golf GTI Trims and Equipment
Modification	Body	Equipment
2.0 DSG	Hatchback 5-door	GTi
2.0L DSG	Hatchback 5-door	GTi
2.0L DSG	Hatchback 3-door	Performance
2.0 DSG	Hatchback 3-door	GTi
