Catalog / Volkswagen / Golf GTI / 6 generation
Volkswagen Golf GTI Engines and Transmissions
The Volkswagen Golf GTI engine in this generation is a 2.0-liter gasoline unit sending power to the front wheels. Cabrio examples include 2.0 MT with a manual gearbox and 2.0 DSG with robotic shifting; the Hatchback 5-door sample also uses 2.0 MT.
Cabrio — Volkswagen Golf GTI Engines and Transmissions
Cabrio Volkswagen Golf GTI Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 MT Gasoline 1984 cm³ 210 hp 155 kW 280 N⋅m Manual FWD 2.0 DSG Gasoline 1984 cm³ 210 hp 155 kW 280 N⋅m Robotic FWD
Hatchback 3-door — Volkswagen Golf GTI Engines and Transmissions
Hatchback 3-door Volkswagen Golf GTI Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 DSG Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Robotic FWD 2.0 MT Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Manual FWD 2.0 MT Gasoline 1984 cm³ 210 hp 155 kW 280 N⋅m Manual FWD 2.0 DSG Gasoline 1984 cm³ 210 hp 155 kW 280 N⋅m Robotic FWD
Hatchback 5-door — Volkswagen Golf GTI Engines and Transmissions
Hatchback 5-door Volkswagen Golf GTI Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 DSG Gasoline 1984 cm³ 235 hp 173 kW 300 N⋅m Robotic FWD 2.0 MT Gasoline 1984 cm³ 210 hp 155 kW 280 N⋅m Manual FWD 2.0 DSG Gasoline 1984 cm³ 210 hp 155 kW 280 N⋅m Robotic FWD
Volkswagen Golf GTI Dimensions
Cabrio — Volkswagen Golf GTI Dimensions
Cabrio Volkswagen Golf GTI Dimensions Modification Length Width Height Wheelbase Curb weight
2.0 MT 4246 mm 1782 mm 1423 mm 2578 mm 1458 kg 2.0 DSG 4246 mm 1782 mm 1423 mm 2578 mm 1480 kg
Hatchback 3-door — Volkswagen Golf GTI Dimensions
Hatchback 3-door Volkswagen Golf GTI Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 DSG 4213 mm 1786 mm 1501 mm 2578 mm 1314 kg 1820 kg 120 mm 2.0 MT 4213 mm 1786 mm 1501 mm 2578 mm 1290 kg 1820 kg 120 mm 2.0 MT 4213 mm 1786 mm 1501 mm 2578 mm 1318 kg 1870 kg 140 mm 2.0 DSG 4213 mm 1786 mm 1501 mm 2578 mm 1339 kg 1890 kg 140 mm
Hatchback 5-door — Volkswagen Golf GTI Dimensions
Hatchback 5-door Volkswagen Golf GTI Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 DSG 4213 mm 1786 mm 1501 mm 2578 mm 1420 kg 1910 kg 140 mm 2.0 MT 4213 mm 1786 mm 1501 mm 2578 mm 1318 kg 1870 kg 140 mm 2.0 DSG 4213 mm 1786 mm 1501 mm 2578 mm 1339 kg 1890 kg 140 mm
Volkswagen Golf GTI Cargo Space
Cabrio — Volkswagen Golf GTI Cargo Space
Cabrio Volkswagen Golf GTI Cargo Space Modification Trunk volume min
2.0 MT 250 l 2.0 DSG 250 l
Hatchback 3-door — Volkswagen Golf GTI Cargo Space
Hatchback 3-door Volkswagen Golf GTI Cargo Space Modification Trunk volume min Trunk volume max
2.0 DSG 350 l 1305 l 2.0 MT 350 l 1305 l 2.0 MT 350 l 1305 l 2.0 DSG 350 l 1305 l
Hatchback 5-door — Volkswagen Golf GTI Cargo Space
Hatchback 5-door Volkswagen Golf GTI Cargo Space Modification Trunk volume min Trunk volume max
2.0 DSG 350 l 1305 l 2.0 MT 350 l 1305 l 2.0 DSG 350 l 1305 l
Volkswagen Golf GTI Trims and Equipment
You will see Volkswagen Golf GTI trim levels as equipment packs sitting on a named technical version. The 2.0 MT Hatchback 5-door, for example, uses configurations named GTI, so cabin and exterior follow that pack while the manual, gasoline, front-drive layout stays the same.
Volkswagen Golf GTI Trims and Equipment Modification Body Equipment
2.0 MT Hatchback 3-door GTI 2.0 MT Hatchback 3-door GTI Adidas 2.0 MT Hatchback 3-door GTI 2.0 DSG Hatchback 3-door GTI 2.0 MT Hatchback 5-door GTI 2.0 DSG Hatchback 5-door GTI
