Volkswagen Arteon Specs, Engines & Dimensions (from 2020)

Volkswagen Arteon Engines and Transmissions

Volkswagen Arteon engine choices include a gasoline 2.0 DSG Liftback with front-wheel drive and a diesel 2.0 DSG estate with all-wheel drive. Both examples use a dual-clutch automatic transmission. The front-wheel-drive 1.4 DSG plug-in hybrid Liftback adds electric assistance, making regular charging part of getting the most from this powertrain.

Liftback — Volkswagen Arteon Engines and Transmissions

Liftback Volkswagen Arteon Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 DSG	Diesel	1968 cm³	190 hp	139 kW	400 N⋅m	Robotic	AWD
2.0 DSG	Diesel	1968 cm³	190 hp	139 kW	400 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	190 hp	139 kW	400 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	190 hp	139 kW	400 N⋅m	Robotic	AWD
2.0 DSG	Diesel	1968 cm³	150 hp	110 kW	360 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	200 hp	147 kW	410 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	200 hp	147 kW	410 N⋅m	Robotic	AWD
2.0 DSG	Gasoline	1984 cm³	190 hp	139 kW	320 N⋅m	Robotic	FWD
2.0 DSG	Gasoline	1984 cm³	280 hp	205 kW	400 N⋅m	Robotic	AWD
1.4 DSG	Plug-in	1395 cm³	218 hp	160 kW	400 N⋅m	Robotic	FWD

Estate 5-door — Volkswagen Arteon Engines and Transmissions

Estate 5-door Volkswagen Arteon Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 DSG	Gasoline	1984 cm³	280 hp	205 kW	350 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	150 hp	110 kW	360 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	200 hp	147 kW	410 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	200 hp	147 kW	410 N⋅m	Robotic	AWD
1.4 DSG	Plug-in	1395 cm³	218 hp	160 kW	400 N⋅m	Robotic	FWD
2.0 DSG	Gasoline	1984 cm³	190 hp	139 kW	320 N⋅m	Robotic	FWD

Volkswagen Arteon Dimensions

Liftback — Volkswagen Arteon Dimensions

Liftback Volkswagen Arteon Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1665 kg	2300 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1665 kg	2300 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1592 kg	2220 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1676 kg	2290 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1650 kg	2200 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1650 kg	2200 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1724 kg	2280 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1650 kg	2200 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1728 kg	2270 kg	138 mm
1.4 DSG	4866 mm	1871 mm	1457 mm	2836 mm	1800 kg	2300 kg	138 mm

Estate 5-door — Volkswagen Arteon Dimensions

Estate 5-door Volkswagen Arteon Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 DSG	4866 mm	1871 mm	1459 mm	2836 mm	1751 kg	2250 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1459 mm	2836 mm	1660 kg	2210 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1459 mm	2836 mm	1651 kg	2200 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1459 mm	2836 mm	1733 kg	2290 kg	138 mm
1.4 DSG	4866 mm	1871 mm	1459 mm	2836 mm	1815 kg	2290 kg	138 mm
2.0 DSG	4866 mm	1871 mm	1459 mm	2836 mm	1617 kg	2170 kg	138 mm

Volkswagen Arteon Cargo Space

Liftback — Volkswagen Arteon Cargo Space

Liftback Volkswagen Arteon Cargo Space
Modification	Trunk volume min
2.0 DSG	563 l
2.0 DSG	563 l
2.0 DSG	563 l
2.0 DSG	563 l
2.0 DSG	563 l
2.0 DSG	563 l
2.0 DSG	563 l
2.0 DSG	563 l
2.0 DSG	563 l
1.4 DSG	563 l

Volkswagen Arteon Battery, Range, Charging

The 1.4 DSG plug-in hybrid Liftback and Estate 5-door both use a lithium-ion battery. Volkswagen Arteon battery capacity helps determine electric range, while temperature, speed and heating use affect how far each charge takes you. Charging regularly lets you cover more everyday journeys electrically, with the gasoline engine available for longer trips.

Liftback — Volkswagen Arteon Battery, Range, Charging

Liftback Volkswagen Arteon Battery, Range, Charging
Modification	Battery power	Battery type	Driving range, maximum	Full charge home	Full public charging time
1.4 DSG	10.4 kWh	Lithium-ion batterie	70 km	300 min	210 min

Estate 5-door — Volkswagen Arteon Battery, Range, Charging

Estate 5-door Volkswagen Arteon Battery, Range, Charging
Modification	Battery power	Battery type	Driving range, maximum	Full charge home	Full public charging time
1.4 DSG	10.4 kWh	Lithium-ion batterie	69 km	300 min	210 min
