Catalog / Volkswagen / Arteon / 1 generation, restyling
Volkswagen Arteon Engines and Transmissions
Volkswagen Arteon engine choices include a gasoline 2.0 DSG Liftback with front-wheel drive and a diesel 2.0 DSG estate with all-wheel drive. Both examples use a dual-clutch automatic transmission. The front-wheel-drive 1.4 DSG plug-in hybrid Liftback adds electric assistance, making regular charging part of getting the most from this powertrain.
Liftback — Volkswagen Arteon Engines and Transmissions
Liftback Volkswagen Arteon Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 DSG Diesel 1968 cm³ 190 hp 139 kW 400 N⋅m Robotic AWD 2.0 DSG Diesel 1968 cm³ 190 hp 139 kW 400 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 190 hp 139 kW 400 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 190 hp 139 kW 400 N⋅m Robotic AWD 2.0 DSG Diesel 1968 cm³ 150 hp 110 kW 360 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 200 hp 147 kW 410 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 200 hp 147 kW 410 N⋅m Robotic AWD 2.0 DSG Gasoline 1984 cm³ 190 hp 139 kW 320 N⋅m Robotic FWD 2.0 DSG Gasoline 1984 cm³ 280 hp 205 kW 400 N⋅m Robotic AWD 1.4 DSG Plug-in 1395 cm³ 218 hp 160 kW 400 N⋅m Robotic FWD
Estate 5-door — Volkswagen Arteon Engines and Transmissions
Estate 5-door Volkswagen Arteon Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 DSG Gasoline 1984 cm³ 280 hp 205 kW 350 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 150 hp 110 kW 360 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 200 hp 147 kW 410 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 200 hp 147 kW 410 N⋅m Robotic AWD 1.4 DSG Plug-in 1395 cm³ 218 hp 160 kW 400 N⋅m Robotic FWD 2.0 DSG Gasoline 1984 cm³ 190 hp 139 kW 320 N⋅m Robotic FWD
Volkswagen Arteon Dimensions
Liftback — Volkswagen Arteon Dimensions
Liftback Volkswagen Arteon Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1665 kg 2300 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1665 kg 2300 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1592 kg 2220 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1676 kg 2290 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1650 kg 2200 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1650 kg 2200 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1724 kg 2280 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1650 kg 2200 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1728 kg 2270 kg 138 mm 1.4 DSG 4866 mm 1871 mm 1457 mm 2836 mm 1800 kg 2300 kg 138 mm
Estate 5-door — Volkswagen Arteon Dimensions
Estate 5-door Volkswagen Arteon Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 DSG 4866 mm 1871 mm 1459 mm 2836 mm 1751 kg 2250 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1459 mm 2836 mm 1660 kg 2210 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1459 mm 2836 mm 1651 kg 2200 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1459 mm 2836 mm 1733 kg 2290 kg 138 mm 1.4 DSG 4866 mm 1871 mm 1459 mm 2836 mm 1815 kg 2290 kg 138 mm 2.0 DSG 4866 mm 1871 mm 1459 mm 2836 mm 1617 kg 2170 kg 138 mm
Volkswagen Arteon Cargo Space
Liftback — Volkswagen Arteon Cargo Space
Volkswagen Arteon Battery, Range, Charging
The 1.4 DSG plug-in hybrid Liftback and Estate 5-door both use a lithium-ion battery. Volkswagen Arteon battery capacity helps determine electric range, while temperature, speed and heating use affect how far each charge takes you. Charging regularly lets you cover more everyday journeys electrically, with the gasoline engine available for longer trips.
Liftback — Volkswagen Arteon Battery, Range, Charging
Liftback Volkswagen Arteon Battery, Range, Charging Modification Battery power Battery type Driving range, maximum Full charge home Full public charging time
1.4 DSG 10.4 kWh Lithium-ion batterie 70 km 300 min 210 min
Estate 5-door — Volkswagen Arteon Battery, Range, Charging
Estate 5-door Volkswagen Arteon Battery, Range, Charging Modification Battery power Battery type Driving range, maximum Full charge home Full public charging time
1.4 DSG 10.4 kWh Lithium-ion batterie 69 km 300 min 210 min
