Catalog / Vauxhall / Zafira / 2 generation, restyling
Vauxhall Zafira Engines and Transmissions
Vauxhall Zafira engine choices include the 1.6 MT and 1.8 MT, both petrol versions with a manual transmission and front-wheel drive. You may need to change down for hills or overtaking, particularly when fully loaded, so assess how comfortably each engine keeps pace during a representative test drive.
Compact Van — Vauxhall Zafira Engines and Transmissions
Compact Van Vauxhall Zafira Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 MT Gasoline 1598 cm³ 115 hp 85 kW 150 N⋅m Manual FWD 1.8 MT Gasoline 1796 cm³ 140 hp 103 kW 175 N⋅m Manual FWD 1.7 MT Diesel 1686 cm³ 110 hp 81 kW 260 N⋅m Manual FWD 1.7 MT Diesel 1686 cm³ 125 hp 92 kW 280 N⋅m Manual FWD
Vauxhall Zafira Dimensions
Compact Van — Vauxhall Zafira Dimensions
Compact Van Vauxhall Zafira Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 MT 4467 mm 1801 mm 1635 mm 2703 mm 1435 kg 2075 kg 150 mm 1.8 MT 4467 mm 1801 mm 1635 mm 2703 mm 1440 kg 2080 kg 150 mm 1.7 MT 4467 mm 1801 mm 1635 mm 2703 mm 1505 kg 2075 kg 160 mm 1.7 MT 4467 mm 1801 mm 1635 mm 2703 mm 1505 kg 2075 kg 160 mm
Vauxhall Zafira Cargo Space
Compact Van — Vauxhall Zafira Cargo Space
Compact Van Vauxhall Zafira Cargo Space Modification Trunk volume min Trunk volume max
1.6 MT 540 l 1820 l 1.8 MT 540 l 1820 l 1.7 MT 540 l 1820 l 1.7 MT 540 l 1820 l
