Toyota Tacoma Specs, Engines & Dimensions (1997–2004) — First Generation Restyling

The refreshed first-generation Toyota Tacoma comes in single-cab, extended-cab and double-cab pickup bodies. Your choice depends on how much passenger space you need and how you plan to use the truck.

← All Toyota models

Toyota Tacoma Engines and Transmissions

Toyota Tacoma engine and transmission combinations include gasoline double-cab examples such as the rear-wheel-drive 2.4 AT and the 2.4 MT with either rear-wheel drive or all-wheel drive. The automatic reduces gear-changing work in traffic, while the manual gives you direct control over gear selection on hills or when carrying a load.

Pickup double-cab — Toyota Tacoma Engines and Transmissions

Pickup double-cab Toyota Tacoma Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 MT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Manual	AWD
2.4 MT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Manual	RWD
2.4 AT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Automatic	AWD
2.4 AT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Automatic	RWD
2.7 MT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Manual	AWD
2.7 AT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Automatic	RWD
2.7 MT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Manual	RWD
2.7 AT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Automatic	AWD
3.4 AT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Automatic	AWD
3.4 AT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Automatic	RWD
3.4 MT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Manual	AWD
3.4 MT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Manual	RWD

Pickup single-cab — Toyota Tacoma Engines and Transmissions

Pickup single-cab Toyota Tacoma Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 MT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Manual	RWD
2.4 AT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Automatic	AWD
2.4 AT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Automatic	RWD
2.4 MT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Manual	AWD
2.7 AT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Automatic	AWD
2.7 MT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Manual	AWD
2.7 MT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Manual	RWD
2.7 AT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Automatic	RWD
3.4 AT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Automatic	AWD
3.4 MT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Manual	AWD
3.4 AT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Automatic	RWD
3.4 MT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Manual	RWD

Pickup 1.5-cab — Toyota Tacoma Engines and Transmissions

Pickup 1.5-cab Toyota Tacoma Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 AT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Automatic	AWD
2.4 MT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Manual	RWD
2.4 MT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Manual	AWD
2.4 AT	Gasoline	2392 cm³	142 hp	104 kW	217 N⋅m	Automatic	RWD
2.7 AT	Gasoline	2694 cm³	150 hp	110 kW	240 N⋅m	Automatic	RWD
2.7 MT	Gasoline	2694 cm³	150 hp	110 kW	240 N⋅m	Manual	AWD
2.7 AT	Gasoline	2694 cm³	150 hp	110 kW	240 N⋅m	Automatic	AWD
2.7 MT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Manual	AWD
2.7 AT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Automatic	AWD
2.7 AT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Automatic	RWD
2.7 MT	Gasoline	2694 cm³	182 hp	134 kW	240 N⋅m	Manual	RWD
3.4 MT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Manual	AWD
3.4 AT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Automatic	AWD
3.4 AT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Automatic	RWD
3.4 MT	Gasoline	3378 cm³	190 hp	140 kW	298 N⋅m	Manual	RWD

Toyota Tacoma Dimensions

Pickup double-cab — Toyota Tacoma Dimensions

Pickup double-cab Toyota Tacoma Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 MT	5138 mm	1781 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm
2.4 MT	5138 mm	1781 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm
2.4 AT	5138 mm	1781 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.4 AT	5138 mm	1781 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.7 MT	5138 mm	1781 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm
2.7 AT	5138 mm	1781 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.7 MT	5138 mm	1781 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm
2.7 AT	5138 mm	1781 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
3.4 AT	5138 mm	1781 mm	1715 mm	3096 mm	1681 kg	2315 kg	254 mm
3.4 AT	5138 mm	1781 mm	1715 mm	3096 mm	1576 kg	2315 kg	254 mm
3.4 MT	5138 mm	1781 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm
3.4 MT	5138 mm	1781 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm

Pickup single-cab — Toyota Tacoma Dimensions

Pickup single-cab Toyota Tacoma Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 MT	4686 mm	1689 mm	1570 mm	2624 mm	Not provided	1928 kg	215 mm
2.4 AT	4686 mm	1689 mm	1570 mm	2624 mm	Not provided	1928 kg	215 mm
2.4 AT	4686 mm	1689 mm	1570 mm	2624 mm	Not provided	1928 kg	215 mm
2.4 MT	4686 mm	1689 mm	1570 mm	2624 mm	1247 kg	1928 kg	215 mm
2.7 AT	4686 mm	1689 mm	1570 mm	2624 mm	Not provided	1928 kg	215 mm
2.7 MT	4686 mm	1689 mm	1570 mm	2624 mm	1247 kg	1928 kg	215 mm
2.7 MT	4686 mm	1689 mm	1570 mm	2624 mm	1247 kg	1928 kg	215 mm
2.7 AT	4686 mm	1689 mm	1570 mm	2624 mm	Not provided	1928 kg	215 mm
3.4 AT	4686 mm	1689 mm	1570 mm	2624 mm	1606 kg	2315 kg	275 mm
3.4 MT	4686 mm	1689 mm	1570 mm	2624 mm	1247 kg	1928 kg	215 mm
3.4 AT	4686 mm	1689 mm	1570 mm	2624 mm	Not provided	1928 kg	215 mm
3.4 MT	4686 mm	1689 mm	1570 mm	2624 mm	Not provided	1928 kg	215 mm

Pickup 1.5-cab — Toyota Tacoma Dimensions

Pickup 1.5-cab Toyota Tacoma Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 AT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.4 MT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.4 MT	5138 mm	1689 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm
2.4 AT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.7 AT	5138 mm	1689 mm	1715 mm	3096 mm	1487 kg	2315 kg	275 mm
2.7 MT	5138 mm	1689 mm	1715 mm	3096 mm	1574 kg	2315 kg	275 mm
2.7 AT	5138 mm	1689 mm	1715 mm	3096 mm	1588 kg	2315 kg	275 mm
2.7 MT	5138 mm	1689 mm	1715 mm	3096 mm	1247 kg	1928 kg	215 mm
2.7 AT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.7 AT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
2.7 MT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
3.4 MT	5138 mm	1689 mm	1715 mm	3096 mm	1594 kg	2315 kg	275 mm
3.4 AT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
3.4 AT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
3.4 MT	5138 mm	1689 mm	1715 mm	3096 mm	Not provided	1928 kg	215 mm
