Toyota Passo Specs, Engines & Dimensions (2004–2010)

Toyota Passo Engines and Transmissions

Each Toyota Passo engine is a small gasoline unit tuned for economy rather than speed. A 1.0 with an automatic suits stop-and-go traffic, while the 1.3 with a manual gearbox feels livelier on open roads. Most versions drive the front wheels, though an all-wheel-drive automatic adds grip in poor weather.

Mini 5-doors — Toyota Passo Engines and Transmissions

Mini 5-doors Toyota Passo Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.0 AT	Gasoline	996 cm³	71 hp	52 kW	94 N⋅m	Automatic	FWD
1.0 AT	Gasoline	996 cm³	71 hp	52 kW	94 N⋅m	Automatic	AWD
1.3 AT	Gasoline	1297 cm³	90 hp	66 kW	123 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1297 cm³	92 hp	68 kW	123 N⋅m	Manual	FWD
1.3 AT	Gasoline	1297 cm³	92 hp	68 kW	123 N⋅m	Automatic	FWD

Toyota Passo Dimensions

Mini 5-doors — Toyota Passo Dimensions

Mini 5-doors Toyota Passo Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
1.0 AT	3630 mm	1665 mm	1550 mm	2440 mm	900 kg	160 mm
1.0 AT	3630 mm	1665 mm	1550 mm	2440 mm	940 kg	160 mm
1.3 AT	3630 mm	1665 mm	1550 mm	2440 mm	940 kg	160 mm
1.3 MT	3630 mm	1665 mm	1550 mm	2440 mm	930 kg	160 mm
1.3 AT	3630 mm	1665 mm	1550 mm	2440 mm	930 kg	160 mm

Toyota Passo Cargo Space

Mini 5-doors — Toyota Passo Cargo Space

Mini 5-doors Toyota Passo Cargo Space
Modification	Trunk volume min	Trunk volume max
1.0 AT	225 l	630 l
1.0 AT	225 l	630 l
1.3 AT	225 l	630 l
1.3 MT	225 l	630 l
1.3 AT	225 l	630 l

Toyota Passo Specs, Engines & Dimensions (2004–2010) — First Generation

Toyota Passo

Toyota Passo

Toyota Passo

Toyota Passo

Toyota Passo

Toyota Passo Engines and Transmissions

Mini 5-doors — Toyota Passo Engines and Transmissions

Toyota Passo Dimensions

Mini 5-doors — Toyota Passo Dimensions

Toyota Passo Cargo Space

Mini 5-doors — Toyota Passo Cargo Space
