Toyota Hilux Surf Specs, Engines & Dimensions (1989–1991) — Second Generation
The second-generation Toyota Hilux Surf is a truck-based SUV offered in three-door and five-door bodies, pairing rugged ladder-frame underpinnings with everyday usability for drivers who want genuine off-road capability without giving up family practicality.
Toyota Hilux Surf Engines and Transmissions Toyota Hilux Surf Dimensions ← All Toyota models
Toyota Hilux Surf Engines and Transmissions
Toyota Hilux Surf engine options span petrol and diesel. The 2.0 MT and 2.0 AT gasoline versions suit mixed driving, with the automatic easing traffic work, while the 2.5 MT diesel favours torque and economy. These examples use all-wheel drive, the drivetrain that defines the model's rough-road character.
SUV 3-doors — Toyota Hilux Surf Engines and Transmissions
SUV 3-doors Toyota Hilux Surf Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 AT Gasoline 1998 cm³ 97 hp 71 kW 160 N⋅m Automatic AWD 2.0 MT Gasoline 1998 cm³ 97 hp 71 kW 160 N⋅m Manual AWD 3.0 AT Gasoline 2958 cm³ 150 hp 110 kW 245 N⋅m Automatic AWD 3.0 MT Gasoline 2958 cm³ 150 hp 110 kW 245 N⋅m Manual AWD 2.5 MT Diesel 2446 cm³ 94 hp 69 kW 240 N⋅m Manual AWD 2.5 AT Diesel 2446 cm³ 94 hp 69 kW 240 N⋅m Automatic AWD 2.8 MT Diesel 2779 cm³ 91 hp 67 kW 188 N⋅m Manual AWD
SUV 5-doors — Toyota Hilux Surf Engines and Transmissions
SUV 5-doors Toyota Hilux Surf Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 AT Gasoline 1998 cm³ 97 hp 71 kW 159 N⋅m Automatic AWD 2.0 MT Gasoline 1998 cm³ 97 hp 71 kW 159 N⋅m Manual AWD 3.0 MT Gasoline 2958 cm³ 150 hp 110 kW 245 N⋅m Manual AWD 3.0 AT Gasoline 2958 cm³ 150 hp 110 kW 245 N⋅m Automatic AWD 2.5 MT Diesel 2446 cm³ 94 hp 69 kW 240 N⋅m Manual AWD 2.5 AT Diesel 2446 cm³ 94 hp 69 kW 240 N⋅m Automatic AWD 2.8 MT Diesel 2779 cm³ 91 hp 67 kW 188 N⋅m Manual AWD
Toyota Hilux Surf Dimensions
SUV 3-doors — Toyota Hilux Surf Dimensions
SUV 3-doors Toyota Hilux Surf Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 2.0 AT 4470 mm 1690 mm 1745 mm 2625 mm Not provided 210 mm 2.0 MT 4470 mm 1690 mm 1745 mm 2625 mm 1630 kg 210 mm 3.0 AT 4470 mm 1690 mm 1745 mm 2625 mm Not provided 210 mm 3.0 MT 4470 mm 1690 mm 1745 mm 2625 mm 1630 kg 210 mm 2.5 MT 4470 mm 1690 mm 1745 mm 2625 mm 1630 kg 210 mm 2.5 AT 4470 mm 1690 mm 1745 mm 2625 mm Not provided 210 mm 2.8 MT 4470 mm 1690 mm 1745 mm 2625 mm 1710 kg 210 mm
SUV 5-doors — Toyota Hilux Surf Dimensions
SUV 5-doors Toyota Hilux Surf Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 2.0 AT 4470 mm 1690 mm 1745 mm 2625 mm 1670 kg 210 mm 2.0 MT 4470 mm 1690 mm 1745 mm 2625 mm 1640 kg 210 mm 3.0 MT 4470 mm 1690 mm 1745 mm 2625 mm 1740 kg 210 mm 3.0 AT 4470 mm 1690 mm 1745 mm 2625 mm 1800 kg 210 mm 2.5 MT 4470 mm 1690 mm 1745 mm 2625 mm 1630 kg 210 mm 2.5 AT 4470 mm 1690 mm 1745 mm 2625 mm Not provided 210 mm 2.8 MT 4470 mm 1690 mm 1745 mm 2625 mm 1710 kg 210 mm
