Toyota Corolla Specs, Engines & Dimensions (2018–2023) — Twelfth Generation

The twelfth-generation Toyota Corolla offers estate, sedan and five-door hatchback bodies to suit different routines. Your choice of powertrain and equipment matters alongside body style, especially if you divide your driving between town and longer trips.

← All Toyota models

Toyota Corolla Engines and Transmissions

Toyota Corolla engine choices include the front-wheel-drive 1.2 MT estate, whose manual transmission gives you direct control over gear changes, and the front-wheel-drive 1.8 CVT hybrid estate for automatic convenience. The gasoline 1.2 CVT hatchback provides an all-wheel-drive example, so body style alone does not tell you which drivetrain is fitted.

Estate 5-door — Toyota Corolla Engines and Transmissions

Estate 5-door Toyota Corolla Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.2 MT	Gasoline	1197 cm³	116 hp	85 kW	185 N⋅m	Manual	FWD
1.2 CVT	Gasoline	1197 cm³	116 hp	85 kW	185 N⋅m	Variable	FWD
1.8 CVT	Hybrid	1798 cm³	98 hp	72 kW	142 N⋅m	Variable	FWD
2.0 CVT	Hybrid	1987 cm³	196 hp	144 kW	190 N⋅m	Variable	FWD
2ZR-FXE	Hybrid	1598 cm³	122 hp	89 kW	145 N⋅m	Variable	FWD
1.8 2ZR-FXE	Hybrid	1798 cm³	122 hp	89 kW	145 N⋅m	Variable	FWD

Sedan — Toyota Corolla Engines and Transmissions

Sedan Toyota Corolla Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1598 cm³	122 hp	90 kW	153 N⋅m	Manual	FWD
2.0 CVT	Hybrid	1987 cm³	169 hp	124 kW	205 N⋅m	Variable	FWD
1.8 2ZR-FXE	Hybrid	1798 cm³	121 hp	88 kW	145 N⋅m	Variable	FWD
1.6 1ZR-FAE	Gasoline	1598 cm³	132 hp	90 kW	162 N⋅m	Variable	FWD
1.8 CVT	Hybrid	1798 cm³	98 hp	72 kW	142 N⋅m	Variable	FWD
1.8 2ZR-FXE	Hybrid	1798 cm³	121 hp	88 kW	145 N⋅m	Variable	FWD
1.5 M15A-FKS CVT	Gasoline	1490 cm³	125 hp	91 kW	156 N⋅m	Variable	FWD
1.8 2ZR-FXE	Hybrid	1798 cm³	136 hp	100 kW	211 N⋅m	Variable	FWD

Hatchback 5-door — Toyota Corolla Engines and Transmissions

Hatchback 5-door Toyota Corolla Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.2 CVT	Gasoline	1197 cm³	116 hp	85 kW	185 N⋅m	Variable	AWD
2.0 CVT	Gasoline	1987 cm³	168 hp	125 kW	205 N⋅m	Variable	FWD
2.0 MT	Gasoline	1987 cm³	168 hp	125 kW	205 N⋅m	Manual	FWD
2.0 CVT	Hybrid	1987 cm³	153 hp	112 kW	190 N⋅m	Variable	FWD
2.0 CVT	Hybrid	1987 cm³	169 hp	124 kW	205 N⋅m	Variable	FWD
1.2 MT	Gasoline	1197 cm³	116 hp	85 kW	185 N⋅m	Manual	FWD
1.2 CVT	Gasoline	1197 cm³	116 hp	85 kW	185 N⋅m	Variable	FWD
1.8 2ZR-FXE	Hybrid	1798 cm³	121 hp	88 kW	145 N⋅m	Variable	FWD
1.8 2ZR-FXE	Hybrid	1798 cm³	136 hp	100 kW	211 N⋅m	Variable	FWD

Toyota Corolla Dimensions

Estate 5-door — Toyota Corolla Dimensions

Estate 5-door Toyota Corolla Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.2 MT	4650 mm	1790 mm	1435 mm	2700 mm	Not provided	Not provided	135 mm
1.2 CVT	4650 mm	1790 mm	1435 mm	2700 mm	Not provided	Not provided	135 mm
1.8 CVT	4650 mm	1790 mm	1435 mm	2700 mm	1370 kg	Not provided	135 mm
2.0 CVT	4650 mm	1790 mm	1435 mm	2700 mm	1465 kg	Not provided	135 mm
2ZR-FXE	4650 mm	1790 mm	1435 mm	2700 mm	1290 kg	1805 kg	135 mm
1.8 2ZR-FXE	4650 mm	1790 mm	1435 mm	2700 mm	1290 kg	1805 kg	135 mm

Sedan — Toyota Corolla Dimensions

Sedan Toyota Corolla Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4630 mm	1780 mm	1435 mm	2700 mm	1370 kg	1785 kg	150 mm
2.0 CVT	4630 mm	1780 mm	1435 mm	2700 mm	1465 kg	Not provided	135 mm
1.8 2ZR-FXE	4630 mm	1780 mm	1435 mm	2700 mm	1310 kg	1805 kg	135 mm
1.6 1ZR-FAE	4630 mm	1780 mm	1435 mm	2700 mm	1205 kg	1805 kg	150 mm
1.8 CVT	4630 mm	1780 mm	1435 mm	2700 mm	1380 kg	1835 kg	135 mm
1.8 2ZR-FXE	4630 mm	1780 mm	1435 mm	2700 mm	1310 kg	1805 kg	135 mm
1.5 M15A-FKS CVT	4630 mm	1780 mm	1435 mm	2700 mm	1300 kg	1805 kg	130 mm
1.8 2ZR-FXE	4630 mm	1780 mm	1435 mm	2700 mm	1310 kg	1805 kg	135 mm

Hatchback 5-door — Toyota Corolla Dimensions

Hatchback 5-door Toyota Corolla Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.2 CVT	4370 mm	1790 mm	1435 mm	2640 mm	1370 kg	Not provided	130 mm
2.0 CVT	4370 mm	1790 mm	1435 mm	2640 mm	1390 kg	Not provided	130 mm
2.0 MT	4370 mm	1790 mm	1435 mm	2640 mm	1390 kg	Not provided	130 mm
2.0 CVT	4370 mm	1790 mm	1435 mm	2640 mm	1410 kg	Not provided	135 mm
2.0 CVT	4370 mm	1790 mm	1435 mm	2640 mm	1465 kg	Not provided	135 mm
1.2 MT	4370 mm	1790 mm	1435 mm	2640 mm	1380 kg	Not provided	135 mm
1.2 CVT	4370 mm	1790 mm	1435 mm	2640 mm	1380 kg	Not provided	135 mm
1.8 2ZR-FXE	4370 mm	1790 mm	1435 mm	2640 mm	1310 kg	1805 kg	135 mm
1.8 2ZR-FXE	4370 mm	1790 mm	1435 mm	2640 mm	1310 kg	1805 kg	135 mm

Toyota Corolla Cargo Space

Estate 5-door — Toyota Corolla Cargo Space

Estate 5-door Toyota Corolla Cargo Space
Modification	Trunk volume min
1.2 MT	471 l
1.2 CVT	471 l
1.8 CVT	471 l
2.0 CVT	471 l
2ZR-FXE	471 l
1.8 2ZR-FXE	471 l

Sedan — Toyota Corolla Cargo Space

Sedan Toyota Corolla Cargo Space
Modification	Trunk volume min
1.6 MT	471 l
2.0 CVT	471 l
1.8 2ZR-FXE	471 l
1.6 1ZR-FAE	471 l
1.8 CVT	471 l
1.8 2ZR-FXE	471 l
1.5 M15A-FKS CVT	471 l
1.8 2ZR-FXE	471 l

Hatchback 5-door — Toyota Corolla Cargo Space

Hatchback 5-door Toyota Corolla Cargo Space
Modification	Trunk volume min	Trunk volume max
1.2 CVT	313 l	1052 l
2.0 CVT	313 l	1052 l
2.0 MT	313 l	1052 l
2.0 CVT	313 l	1052 l
2.0 CVT	313 l	1052 l
1.2 MT	313 l	1052 l
1.2 CVT	313 l	1052 l
1.8 2ZR-FXE	313 l	1052 l
1.8 2ZR-FXE	313 l	1052 l

Toyota Corolla Trims and Equipment

Sense and Active are Toyota Corolla trim levels offered with the gasoline, front-wheel-drive 1.5 M15A-FKS CVT sedan. They identify equipment configurations within that technical version. When choosing, check the actual car’s comfort, multimedia and driver-assistance features against your priorities, since the engine designation alone does not establish its equipment.

Toyota Corolla Trims and Equipment
Modification	Body	Equipment
1.8 CVT	Estate 5-door	Space
2ZR-FXE	Estate 5-door	Space Plus
1.8 2ZR-FXE	Estate 5-door	Space
1.8 2ZR-FXE	Estate 5-door	Comfort Estate
1.6 MT	Sedan	Base
1.6 MT	Sedan	Classic
1.6 1ZR-FAE	Sedan	Sense
1.6 1ZR-FAE	Sedan	Sun
1.6 1ZR-FAE	Sedan	Limited
1.8 CVT	Sedan	Sense
1.8 CVT	Sedan	Sun
1.8 CVT	Sedan	Limited
1.8 CVT	Sedan	Flow
1.8 2ZR-FXE	Sedan	Limited
1.8 2ZR-FXE	Sedan	Active
1.8 2ZR-FXE	Sedan	Executive
1.8 2ZR-FXE	Sedan	Comfort
1.8 2ZR-FXE	Sedan	Style
1.8 2ZR-FXE	Sedan	Flow
1.8 2ZR-FXE	Sedan	Lounge Luxury
1.8 2ZR-FXE	Sedan	Lounge
1.5 M15A-FKS CVT	Sedan	Sense
1.5 M15A-FKS CVT	Sedan	Active
1.5 M15A-FKS CVT	Sedan	Comfort
1.5 M15A-FKS CVT	Sedan	Style
1.5 M15A-FKS CVT	Sedan	Icon M
1.5 M15A-FKS CVT	Sedan	Icon
1.5 M15A-FKS CVT	Sedan	Style SF
1.2 MT	Hatchback 5-door	Comfort
1.2 CVT	Hatchback 5-door	Excite

Toyota Corolla Battery

The hybrid estate versions named 2ZR-FXE and 1.8 2ZR-FXE use a metal hydride battery to support electric assistance. In everyday driving, this stores recovered braking energy for reuse without routine plug-in charging. Toyota Corolla battery capacity therefore serves a different purpose here from the large energy reserve in a fully electric car.

Estate 5-door — Toyota Corolla Battery

Estate 5-door Toyota Corolla Battery
Modification	Battery power	Battery type
2ZR-FXE	0.7 kWh	Metal hydride battery
1.8 2ZR-FXE	0.7 kWh	Metal hydride battery

Sedan — Toyota Corolla Battery

Sedan Toyota Corolla Battery
Modification	Battery power	Battery type
1.8 2ZR-FXE	0.7 kWh	Metal hydride battery
1.8 2ZR-FXE	0.7 kWh	Metal hydride battery
1.8 2ZR-FXE	0.7 kWh	Metal hydride battery

Hatchback 5-door — Toyota Corolla Battery

Hatchback 5-door Toyota Corolla Battery
Modification	Battery power	Battery type
1.8 2ZR-FXE	0.7 kWh	Metal hydride battery
1.8 2ZR-FXE	0.7 kWh	Metal hydride battery
