Toyota Corolla II Specs, Engines & Dimensions (1994–1997)

Toyota Corolla II Engines and Transmissions

Powertrain choice on this three-door hatch is easy to grasp. A Toyota Corolla II engine in the selected 1.5 MT and 1.5 AT examples is a 1.5-litre diesel, paired with a manual or automatic transmission and a front-wheel-drive drivetrain for daily commuting.

Hatchback 3-door — Toyota Corolla II Engines and Transmissions

Hatchback 3-door Toyota Corolla II Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 MT	Gasoline	1331 cm³	97 hp	71 kW	113 N⋅m	Manual	FWD
1.3 AT	Gasoline	1331 cm³	97 hp	71 kW	113 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1331 cm³	100 hp	74 kW	116 N⋅m	Manual	FWD
1.3 AT	Gasoline	1331 cm³	100 hp	74 kW	116 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1496 cm³	97 hp	71 kW	113 N⋅m	Manual	AWD
1.5 AT	Gasoline	1496 cm³	97 hp	71 kW	113 N⋅m	Automatic	AWD
1.5 MT	Gasoline	1496 cm³	100 hp	74 kW	126 N⋅m	Manual	FWD
1.5 AT	Gasoline	1496 cm³	100 hp	74 kW	126 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1496 cm³	105 hp	77 kW	127 N⋅m	Manual	FWD
1.5 MT	Gasoline	1496 cm³	105 hp	77 kW	127 N⋅m	Manual	AWD
1.5 AT	Gasoline	1496 cm³	105 hp	77 kW	127 N⋅m	Automatic	FWD
1.5 AT	Gasoline	1496 cm³	105 hp	77 kW	127 N⋅m	Automatic	AWD
1.5 MT	Gasoline	1496 cm³	115 hp	85 kW	135 N⋅m	Manual	FWD
1.5 AT	Gasoline	1496 cm³	115 hp	85 kW	135 N⋅m	Automatic	FWD
1.5 MT	Diesel	1453 cm³	67 hp	49 kW	137 N⋅m	Manual	FWD
1.5 AT	Diesel	1453 cm³	67 hp	49 kW	137 N⋅m	Automatic	FWD

Toyota Corolla II Dimensions

Hatchback 3-door — Toyota Corolla II Dimensions

Hatchback 3-door Toyota Corolla II Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
1.3 MT	3930 mm	1645 mm	1365 mm	2380 mm	840 kg	160 mm
1.3 AT	3930 mm	1645 mm	1365 mm	2380 mm	860 kg	160 mm
1.3 MT	3930 mm	1645 mm	1365 mm	2380 mm	830 kg	160 mm
1.3 AT	3930 mm	1645 mm	1365 mm	2380 mm	850 kg	160 mm
1.5 MT	3930 mm	1645 mm	1365 mm	2380 mm	980 kg	155 mm
1.5 AT	3930 mm	1645 mm	1365 mm	2380 mm	1020 kg	155 mm
1.5 MT	3930 mm	1645 mm	1365 mm	2380 mm	880 kg	150 mm
1.5 AT	3930 mm	1645 mm	1365 mm	2380 mm	920 kg	150 mm
1.5 MT	3930 mm	1645 mm	1365 mm	2380 mm	850 kg	150 mm
1.5 MT	3930 mm	1645 mm	1365 mm	2380 mm	950 kg	155 mm
1.5 AT	3930 mm	1645 mm	1365 mm	2380 mm	890 kg	150 mm
1.5 AT	3930 mm	1645 mm	1365 mm	2380 mm	990 kg	155 mm
1.5 MT	3930 mm	1645 mm	1365 mm	2380 mm	880 kg	150 mm
1.5 AT	3930 mm	1645 mm	1365 mm	2380 mm	920 kg	150 mm
1.5 MT	3930 mm	1645 mm	1365 mm	2380 mm	870 kg	155 mm
1.5 AT	3930 mm	1645 mm	1365 mm	2380 mm	910 kg	155 mm
