Suzuki Grand Vitara Specs, Engines & Dimensions (2005–2008)

Suzuki Grand Vitara Engines and Transmissions

The third-generation Grand Vitara offered a range of petrol and diesel engines. A 1.6-litre petrol with a manual gearbox and all-wheel drive suited everyday driving, while a 1.9-litre diesel provided stronger low-speed pull for towing or rough terrain. For those prioritising comfort, a 2.4-litre petrol could be paired with an automatic transmission in rear-wheel-drive form.

SUV 3-doors — Suzuki Grand Vitara Engines and Transmissions

SUV 3-doors Suzuki Grand Vitara Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1586 cm³	106 hp	78 kW	145 N⋅m	Manual	AWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Automatic	AWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	AWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	RWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	225 N⋅m	Automatic	RWD
1.9 MT	Diesel	1870 cm³	129 hp	95 kW	300 N⋅m	Manual	AWD

SUV 5-doors — Suzuki Grand Vitara Engines and Transmissions

SUV 5-doors Suzuki Grand Vitara Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.9 MT	Diesel	1870 cm³	129 hp	95 kW	300 N⋅m	Manual	AWD
2.0 MT	Gasoline	1995 cm³	140 hp	103 kW	183 N⋅m	Manual	AWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	AWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Automatic	RWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	RWD
2.7 AT	Gasoline	2736 cm³	185 hp	138 kW	250 N⋅m	Automatic	AWD
2.7 MT	Gasoline	2736 cm³	185 hp	138 kW	250 N⋅m	Manual	AWD
2.7 MT	Gasoline	2736 cm³	185 hp	138 kW	250 N⋅m	Manual	RWD
2.7 AT	Gasoline	2736 cm³	185 hp	138 kW	250 N⋅m	Automatic	RWD
2.0 AT	Gasoline	1995 cm³	140 hp	103 kW	183 N⋅m	Automatic	AWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Automatic	AWD

Suzuki Grand Vitara Dimensions

SUV 3-doors — Suzuki Grand Vitara Dimensions

SUV 3-doors Suzuki Grand Vitara Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4005 mm	1810 mm	1695 mm	2440 mm	1445 kg	1800 kg	200 mm
2.4 AT	4005 mm	1810 mm	1695 mm	2440 mm	1445 kg	1800 kg	200 mm
2.4 MT	4005 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm
2.4 MT	4005 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm
2.4 AT	4005 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm
1.9 MT	4005 mm	1810 mm	1695 mm	2440 mm	1445 kg	1870 kg	200 mm

SUV 5-doors — Suzuki Grand Vitara Dimensions

SUV 5-doors Suzuki Grand Vitara Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.9 MT	4470 mm	1810 mm	1695 mm	2640 mm	1445 kg	2070 kg	200 mm
2.0 MT	4470 mm	1810 mm	1695 mm	2640 mm	1580 kg	2070 kg	200 mm
2.4 MT	4470 mm	1810 mm	1695 mm	2640 mm	1552 kg	2100 kg	200 mm
2.4 AT	4470 mm	1810 mm	1695 mm	2640 mm	1567 kg	2100 kg	200 mm
2.4 MT	4470 mm	1810 mm	1695 mm	2640 mm	1552 kg	2100 kg	200 mm
2.7 AT	4470 mm	1810 mm	1695 mm	2640 mm	1670 kg	2010 kg	200 mm
2.7 MT	4470 mm	1810 mm	1695 mm	2640 mm	1670 kg	2010 kg	200 mm
2.7 MT	4470 mm	1810 mm	1695 mm	2640 mm	1565 kg	2100 kg	200 mm
2.7 AT	4470 mm	1810 mm	1695 mm	2640 mm	1590 kg	2100 kg	200 mm
2.0 AT	4470 mm	1810 mm	1695 mm	2640 mm	1580 kg	2070 kg	200 mm
2.4 AT	4470 mm	1810 mm	1695 mm	2640 mm	1567 kg	2100 kg	200 mm

Suzuki Grand Vitara Cargo Space

SUV 3-doors — Suzuki Grand Vitara Cargo Space

SUV 3-doors Suzuki Grand Vitara Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	137 l	1050 l
2.4 AT	137 l	1050 l
2.4 MT	137 l	1050 l
2.4 MT	137 l	1050 l
2.4 AT	137 l	1050 l
1.9 MT	137 l	1050 l

SUV 5-doors — Suzuki Grand Vitara Cargo Space

SUV 5-doors Suzuki Grand Vitara Cargo Space
Modification	Trunk volume min	Trunk volume max
1.9 MT	399 l	1300 l
2.0 MT	399 l	1300 l
2.4 MT	399 l	1300 l
2.4 AT	399 l	1300 l
2.4 MT	399 l	1300 l
2.7 AT	399 l	1300 l
2.7 MT	399 l	1300 l
2.7 MT	399 l	1300 l
2.7 AT	399 l	1300 l
2.0 AT	399 l	1300 l
2.4 AT	399 l	1300 l

Suzuki Grand Vitara Trims and Equipment

Trim levels affected both comfort and convenience. For example, the 2.0-litre automatic all-wheel-drive five-door came in JLX and JLX-AL specifications. JLX-AL typically added features like leather upholstery or an upgraded audio system, while JLX covered the essentials. Equipment varied by market, so buyers should verify specifics for their region.

Suzuki Grand Vitara Trims and Equipment
Modification	Body	Equipment
2.0 AT	SUV 5-doors	JLX
2.0 AT	SUV 5-doors	JLX-AL
