Suzuki Grand Vitara Specs, Engines & Dimensions (2008–2012)

Suzuki Grand Vitara Engines and Transmissions

The Suzuki Grand Vitara engine range balances everyday efficiency with off-road readiness. A 1.6-liter petrol and a 1.9-liter diesel pair with a manual gearbox and all-wheel drive in the three-door body, suiting drivers who want direct control. A 2.4-liter petrol with an automatic transmission and rear-wheel drive offers a more relaxed setup for those prioritizing comfort.

SUV 3-doors — Suzuki Grand Vitara Engines and Transmissions

SUV 3-doors Suzuki Grand Vitara Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1586 cm³	106 hp	78 kW	145 N⋅m	Manual	AWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	225 N⋅m	Automatic	AWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	AWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	225 N⋅m	Automatic	RWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	RWD
1.9 MT	Diesel	1870 cm³	129 hp	95 kW	300 N⋅m	Manual	AWD
2.4 AT	Gasoline	2393 cm³	165 hp	121 kW	227 N⋅m	Automatic	AWD

SUV 5-doors — Suzuki Grand Vitara Engines and Transmissions

SUV 5-doors Suzuki Grand Vitara Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1995 cm³	140 hp	103 kW	183 N⋅m	Manual	AWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	AWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Automatic	RWD
2.4 MT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Manual	RWD
3.2 AT	Gasoline	3195 cm³	233 hp	171 kW	291 N⋅m	Automatic	AWD
1.9 MT	Diesel	1870 cm³	129 hp	95 kW	300 N⋅m	Manual	AWD
2.0 AT	Gasoline	1995 cm³	140 hp	103 kW	183 N⋅m	Automatic	AWD
2.4 AT	Gasoline	2393 cm³	169 hp	124 kW	227 N⋅m	Automatic	AWD
2.4 AT	Gasoline	2393 cm³	165 hp	121 kW	227 N⋅m	Automatic	AWD

Suzuki Grand Vitara Dimensions

SUV 3-doors — Suzuki Grand Vitara Dimensions

SUV 3-doors Suzuki Grand Vitara Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4060 mm	1810 mm	1695 mm	2440 mm	1405 kg	1830 kg	200 mm
2.4 AT	4060 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm
2.4 MT	4060 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm
2.4 AT	4060 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm
2.4 MT	4060 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm
1.9 MT	4060 mm	1810 mm	1695 mm	2440 mm	1660 kg	2070 kg	200 mm
2.4 AT	4060 mm	1810 mm	1695 mm	2440 mm	1459 kg	1890 kg	200 mm

SUV 5-doors — Suzuki Grand Vitara Dimensions

SUV 5-doors Suzuki Grand Vitara Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4500 mm	1810 mm	1695 mm	2640 mm	1533 kg	2070 kg	200 mm
2.4 MT	4500 mm	1810 mm	1695 mm	2640 mm	1552 kg	2100 kg	200 mm
2.4 AT	4500 mm	1810 mm	1695 mm	2640 mm	1567 kg	2100 kg	200 mm
2.4 MT	4500 mm	1810 mm	1695 mm	2640 mm	1552 kg	2100 kg	200 mm
3.2 AT	4500 mm	1810 mm	1695 mm	2640 mm	1677 kg	2170 kg	200 mm
1.9 MT	4500 mm	1810 mm	1695 mm	2640 mm	1660 kg	2070 kg	200 mm
2.0 AT	4500 mm	1810 mm	1695 mm	2640 mm	1548 kg	2070 kg	200 mm
2.4 AT	4500 mm	1810 mm	1695 mm	2640 mm	1567 kg	2100 kg	200 mm
2.4 AT	4500 mm	1810 mm	1695 mm	2640 mm	1567 kg	2100 kg	200 mm

Suzuki Grand Vitara Cargo Space

SUV 3-doors — Suzuki Grand Vitara Cargo Space

SUV 3-doors Suzuki Grand Vitara Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	184 l	964 l
2.4 AT	184 l	964 l
2.4 MT	184 l	964 l
2.4 AT	184 l	964 l
2.4 MT	184 l	964 l
1.9 MT	184 l	964 l
2.4 AT	184 l	964 l

SUV 5-doors — Suzuki Grand Vitara Cargo Space

SUV 5-doors Suzuki Grand Vitara Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 MT	398 l	1386 l
2.4 MT	398 l	1386 l
2.4 AT	398 l	1386 l
2.4 MT	398 l	1386 l
3.2 AT	398 l	1386 l
1.9 MT	398 l	1386 l
2.0 AT	398 l	1386 l
2.4 AT	398 l	1386 l
2.4 AT	398 l	1386 l

Suzuki Grand Vitara Trims and Equipment

Suzuki Grand Vitara trim levels bundle equipment around specific technical versions. On the five-door 2.0 automatic with all-wheel drive, the JLX-E provides a well-equipped baseline, while the JLX-E SE Exclusive adds premium touches. This structure lets buyers choose a ready-made package rather than navigating a long list of individual options.

Suzuki Grand Vitara Trims and Equipment
Modification	Body	Equipment
1.6 MT	SUV 3-doors	JLX-A
2.4 AT	SUV 3-doors	JLX-E
2.4 AT	SUV 3-doors	JLX 3D
2.0 MT	SUV 5-doors	JLX-A
2.0 AT	SUV 5-doors	JLX-E
2.0 AT	SUV 5-doors	JLX-E SE Exclusive
2.0 AT	SUV 5-doors	JLX-AL
2.4 AT	SUV 5-doors	JLX-EL
2.4 AT	SUV 5-doors	JLX-ELS
2.4 AT	SUV 5-doors	JLX-E
