Catalog / Suzuki / Equator / 1 generation
Suzuki Equator Engines and Transmissions
The Suzuki Equator engine range is gasoline, so the powertrain you choose is about transmission and drivetrain, not fuel type. Double-cab 2.5 AT and 2.5 MT examples send power to the rear wheels. The 4.0 AT pairs a larger engine with all-wheel drive for mixed surfaces.
Pickup double-cab — Suzuki Equator Engines and Transmissions
Pickup double-cab Suzuki Equator Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.5 AT Gasoline 2488 cm³ 152 hp 112 kW 232 N⋅m Automatic RWD 2.5 MT Gasoline 2488 cm³ 152 hp 112 kW 232 N⋅m Manual RWD 4.0 AT Gasoline 3954 cm³ 265 hp 195 kW 381 N⋅m Automatic AWD 4.0 AT Gasoline 3954 cm³ 265 hp 195 kW 381 N⋅m Automatic RWD
Pickup 1.5-cab — Suzuki Equator Engines and Transmissions
Pickup 1.5-cab Suzuki Equator Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.5 AT Gasoline 2488 cm³ 152 hp 112 kW 232 N⋅m Automatic RWD 2.5 MT Gasoline 2488 cm³ 152 hp 112 kW 232 N⋅m Manual RWD 4.0 AT Gasoline 3954 cm³ 265 hp 195 kW 381 N⋅m Automatic AWD 4.0 AT Gasoline 3954 cm³ 265 hp 195 kW 381 N⋅m Automatic RWD
Suzuki Equator Dimensions
Pickup double-cab — Suzuki Equator Dimensions
Pickup double-cab Suzuki Equator Dimensions Modification Length Width Height Wheelbase Ground clearance, minimum
2.5 AT 5591 mm 1849 mm 1780 mm 3200 mm 218 mm 2.5 MT 5591 mm 1849 mm 1780 mm 3200 mm 218 mm 4.0 AT 5591 mm 1849 mm 1780 mm 3200 mm 218 mm 4.0 AT 5591 mm 1849 mm 1780 mm 3200 mm 218 mm
Pickup 1.5-cab — Suzuki Equator Dimensions
Pickup 1.5-cab Suzuki Equator Dimensions Modification Length Width Height Wheelbase Ground clearance, minimum
2.5 AT 5248 mm 1849 mm 1780 mm 3200 mm 218 mm 2.5 MT 5248 mm 1849 mm 1780 mm 3200 mm 218 mm 4.0 AT 5248 mm 1849 mm 1780 mm 3200 mm 218 mm 4.0 AT 5248 mm 1849 mm 1780 mm 3200 mm 218 mm
