Suzuki Crossover SX4 Specs, Engines & Dimensions (2016–2022)

Suzuki Crossover SX4 Engines and Transmissions

Suzuki Crossover SX4 engine choices include gasoline versions such as the front-wheel-drive 1.0 AT and 1.0 MT, offering automatic convenience in traffic or manual control over gear changes. The diesel 1.6 MT combines a manual transmission with all-wheel drive, which can help you pull away on slippery surfaces. These examples illustrate some of the available powertrain combinations.

SUV 5-doors — Suzuki Crossover SX4 Engines and Transmissions

SUV 5-doors Suzuki Crossover SX4 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.0 AT	Gasoline	998 cm³	111 hp	81 kW	170 N⋅m	Automatic	FWD
1.0 MT	Gasoline	998 cm³	111 hp	81 kW	170 N⋅m	Manual	FWD
1.4 AT	Gasoline	1373 cm³	140 hp	Not provided	224 N⋅m	Automatic	AWD
1.4 MT	Gasoline	1373 cm³	140 hp	102 kW	220 N⋅m	Manual	AWD
1.6 AT	Gasoline	1586 cm³	117 hp	86 kW	151 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1586 cm³	117 hp	86 kW	151 N⋅m	Manual	FWD
1.6 AT	Gasoline	1586 cm³	117 hp	86 kW	151 N⋅m	Automatic	AWD
1.6 MT	Gasoline	1586 cm³	117 hp	86 kW	151 N⋅m	Manual	AWD
1.6 AT	Diesel	1598 cm³	120 hp	88 kW	320 N⋅m	Automatic	AWD
1.6 MT	Diesel	1598 cm³	120 hp	88 kW	320 N⋅m	Manual	AWD
1.4 MT	Gasoline	1373 cm³	140 hp	102 kW	224 N⋅m	Manual	FWD
1.4 AT	Gasoline	1373 cm³	140 hp	102 kW	224 N⋅m	Automatic	FWD
1.4 AT	Gasoline	1373 cm³	129 hp	94 kW	242 N⋅m	Automatic	FWD

Suzuki Crossover SX4 Dimensions

SUV 5-doors — Suzuki Crossover SX4 Dimensions

SUV 5-doors Suzuki Crossover SX4 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.0 AT	4300 mm	1785 mm	1585 mm	2600 mm	1235 kg	1730 kg	180 mm
1.0 MT	4300 mm	1785 mm	1585 mm	2600 mm	1165 kg	1730 kg	180 mm
1.4 AT	4300 mm	1785 mm	1585 mm	2600 mm	1235 kg	1730 kg	180 mm
1.4 MT	4300 mm	1785 mm	1585 mm	2600 mm	1215 kg	1730 kg	180 mm
1.6 AT	4300 mm	1785 mm	1585 mm	2600 mm	1130 kg	1720 kg	180 mm
1.6 MT	4300 mm	1785 mm	1585 mm	2600 mm	1085 kg	1720 kg	180 mm
1.6 AT	4300 mm	1785 mm	1585 mm	2600 mm	1195 kg	1720 kg	180 mm
1.6 MT	4300 mm	1785 mm	1585 mm	2600 mm	1170 kg	1720 kg	180 mm
1.6 AT	4300 mm	1785 mm	1585 mm	2600 mm	1430 kg	1720 kg	180 mm
1.6 MT	4300 mm	1785 mm	1585 mm	2600 mm	1410 kg	1860 kg	180 mm
1.4 MT	4300 mm	1785 mm	1585 mm	2600 mm	1175 kg	1730 kg	180 mm
1.4 AT	4300 mm	1785 mm	1585 mm	2600 mm	1195 kg	1730 kg	180 mm
1.4 AT	4300 mm	1785 mm	1585 mm	2600 mm	1300 kg	1725 kg	180 mm

Suzuki Crossover SX4 Cargo Space

SUV 5-doors — Suzuki Crossover SX4 Cargo Space

SUV 5-doors Suzuki Crossover SX4 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.0 AT	430 l	876 l
1.0 MT	430 l	876 l
1.4 AT	430 l	876 l
1.4 MT	430 l	876 l
1.6 AT	430 l	876 l
1.6 MT	430 l	876 l
1.6 AT	430 l	876 l
1.6 MT	430 l	876 l
1.6 AT	430 l	876 l
1.6 MT	430 l	876 l
1.4 MT	430 l	876 l
1.4 AT	430 l	876 l
1.4 AT	430 l	876 l

Suzuki Crossover SX4 Trims and Equipment

Suzuki Crossover SX4 trim levels distinguish equipment packages within a technical version. The gasoline, automatic, front-wheel-drive 1.6 AT has configurations named GLX and GL AT. When choosing between them, check the individual car’s comfort, convenience and safety equipment: the shared powertrain does not mean both trims have identical features.

Suzuki Crossover SX4 Trims and Equipment
Modification	Body	Equipment
1.4 AT	SUV 5-doors	Tabi
1.6 AT	SUV 5-doors	GLX
1.6 AT	SUV 5-doors	GL AT
1.6 MT	SUV 5-doors	GL MT
1.4 MT	SUV 5-doors	GLX
1.4 AT	SUV 5-doors	GLX
1.4 AT	SUV 5-doors	GLX
