Subaru Forester Specs, Engines & Dimensions (2007–2010)

Subaru Forester Engines and Transmissions

A Subaru Forester engine in this generation is part of a powertrain aimed at mixed roads. One example is the 2.0 MT: a diesel SUV 5-doors with a manual transmission and all-wheel drive, useful if you want low-rev pull and more control of the drivetrain. Other pairings existed beyond this configuration.

SUV 5-doors — Subaru Forester Engines and Transmissions

SUV 5-doors Subaru Forester Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.5 AT	Gasoline	2457 cm³	173 hp	126 kW	229 N⋅m	Automatic	AWD
2.5 MT	Gasoline	2457 cm³	173 hp	126 kW	229 N⋅m	Manual	AWD
2.5 MT	Gasoline	2457 cm³	230 hp	169 kW	320 N⋅m	Manual	AWD
2.0 MT	Gasoline	1994 cm³	230 hp	169 kW	319 N⋅m	Manual	AWD
2.0 AT	Gasoline	1994 cm³	230 hp	169 kW	319 N⋅m	Automatic	AWD
2.0 MT	Diesel	1998 cm³	147 hp	108 kW	350 N⋅m	Manual	AWD
2.0 AT	Gasoline	1994 cm³	150 hp	110 kW	196 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1994 cm³	150 hp	110 kW	196 N⋅m	Manual	AWD
2.5 AT	Gasoline	2457 cm³	230 hp	169 kW	320 N⋅m	Automatic	AWD

Subaru Forester Dimensions

SUV 5-doors — Subaru Forester Dimensions

SUV 5-doors Subaru Forester Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.5 AT	4560 mm	1780 mm	1700 mm	2615 mm	1515 kg	2000 kg	220 mm
2.5 MT	4560 mm	1780 mm	1700 mm	2615 mm	1495 kg	2000 kg	220 mm
2.5 MT	4560 mm	1780 mm	1700 mm	2615 mm	1525 kg	2000 kg	225 mm
2.0 MT	4560 mm	1780 mm	1700 mm	2615 mm	1460 kg	2000 kg	225 mm
2.0 AT	4560 mm	1780 mm	1700 mm	2615 mm	1480 kg	2000 kg	225 mm
2.0 MT	4560 mm	1780 mm	1700 mm	2615 mm	1405 kg	1880 kg	205 mm
2.0 AT	4560 mm	1780 mm	1700 mm	2615 mm	1495 kg	1880 kg	215 mm
2.0 MT	4560 mm	1780 mm	1700 mm	2615 mm	1480 kg	1880 kg	215 mm
2.5 AT	4560 mm	1780 mm	1700 mm	2615 mm	1575 kg	2000 kg	225 mm

Subaru Forester Cargo Space

SUV 5-doors — Subaru Forester Cargo Space

SUV 5-doors Subaru Forester Cargo Space
Modification	Trunk volume min	Trunk volume max
2.5 AT	450 l	1660 l
2.5 MT	450 l	1660 l
2.5 MT	450 l	1660 l
2.0 MT	450 l	1660 l
2.0 AT	450 l	1660 l
2.0 MT	450 l	1660 l
2.0 AT	450 l	1660 l
2.0 MT	450 l	1660 l
2.5 AT	450 l	1660 l

Subaru Forester Trims and Equipment

Subaru Forester Trims and Equipment
Modification	Body	Equipment
2.5 AT	SUV 5-doors	2.0XS (2H)
2.5 AT	SUV 5-doors	2.0XS (VR)
2.5 AT	SUV 5-doors	2.5XS (62)
2.5 MT	SUV 5-doors	2.0XS (VR)
2.5 MT	SUV 5-doors	2.5XS (62)
2.5 MT	SUV 5-doors	2.5XT (2S)
2.0 AT	SUV 5-doors	X
2.0 AT	SUV 5-doors	2.0XS (2H)
2.0 AT	SUV 5-doors	2.0XS (RR)
2.0 AT	SUV 5-doors	2.0XS (VQ)
2.0 AT	SUV 5-doors	2.0XS (VR)
2.0 AT	SUV 5-doors	X Plus
2.0 AT	SUV 5-doors	XS
2.0 AT	SUV 5-doors	X
2.0 AT	SUV 5-doors	B
2.0 MT	SUV 5-doors	2.0XS (SR)
2.0 MT	SUV 5-doors	X Plus
2.0 MT	SUV 5-doors	XS
2.0 MT	SUV 5-doors	X
2.0 MT	SUV 5-doors	B
2.5 AT	SUV 5-doors	2.0XS (2H)
