Catalog / Subaru / B4 / 5 generation
Subaru B4 Engines and Transmissions
Your Subaru B4 engine choice is a complete powertrain, not just capacity. Selected sedan examples include the 3.6 AT petrol automatic, the 2.0 MT diesel with a manual gearbox, and the 2.0 CVT petrol with a variable transmission. Each of these drivetrains uses all-wheel drive.
Sedan — Subaru B4 Engines and Transmissions
Sedan Subaru B4 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.5 AT Gasoline 2457 cm³ 265 hp 195 kW 350 N⋅m Automatic AWD 2.5 MT Gasoline 2457 cm³ 167 hp 123 kW 229 N⋅m Manual AWD 2.5 MT Gasoline 2457 cm³ 285 hp 210 kW 350 N⋅m Manual AWD 2.5 AT Gasoline 2457 cm³ 285 hp 210 kW 350 N⋅m Automatic AWD 3.6 AT Gasoline 3629 cm³ 256 hp 188 kW 335 N⋅m Automatic AWD 2.0 MT Diesel 1998 cm³ 150 hp 110 kW 350 N⋅m Manual AWD 2.0 CVT Gasoline 1994 cm³ 150 hp 110 kW 196 N⋅m Variable AWD 2.0 MT Gasoline 1994 cm³ 150 hp 110 kW 196 N⋅m Manual AWD 2.5 CVT Gasoline 2457 cm³ 167 hp 123 kW 229 N⋅m Variable AWD
Estate 5-door — Subaru B4 Engines and Transmissions
Estate 5-door Subaru B4 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1994 cm³ 150 hp 110 kW 196 N⋅m Manual AWD 2.5 CVT Gasoline 2457 cm³ 167 hp 123 kW 229 N⋅m Variable AWD 2.5 AT Gasoline 2457 cm³ 265 hp 195 kW 350 N⋅m Automatic AWD 2.5 MT Gasoline 2457 cm³ 285 hp 210 kW 350 N⋅m Manual AWD 2.5 AT Gasoline 2457 cm³ 285 hp 210 kW 350 N⋅m Automatic AWD 2.0 MT Diesel 1998 cm³ 150 hp 110 kW 350 N⋅m Manual AWD 2.0 CVT Gasoline 1994 cm³ 150 hp 110 kW 196 N⋅m Variable AWD
Subaru B4 Dimensions
Sedan — Subaru B4 Dimensions
Sedan Subaru B4 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.5 AT 4730 mm 1780 mm 1505 mm 2750 mm 1542 kg 2080 kg 150 mm 2.5 MT 4730 mm 1780 mm 1505 mm 2750 mm 1390 kg 1510 kg 150 mm 2.5 MT 4730 mm 1780 mm 1505 mm 2750 mm 1542 kg Not provided 150 mm 2.5 AT 4730 mm 1780 mm 1505 mm 2750 mm Not provided Not provided 150 mm 3.6 AT 4730 mm 1780 mm 1505 mm 2750 mm 1542 kg Not provided 150 mm 2.0 MT 4730 mm 1780 mm 1505 mm 2750 mm 1460 kg Not provided 150 mm 2.0 CVT 4730 mm 1780 mm 1505 mm 2750 mm 1460 kg 2020 kg 150 mm 2.0 MT 4730 mm 1780 mm 1505 mm 2750 mm 1420 kg 2000 kg 150 mm 2.5 CVT 4730 mm 1780 mm 1505 mm 2750 mm 1479 kg 2030 kg 150 mm
Estate 5-door — Subaru B4 Dimensions
Estate 5-door Subaru B4 Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 2.0 MT 4775 mm 1780 mm 1505 mm 2750 mm 1420 kg 150 mm 2.5 CVT 4775 mm 1780 mm 1505 mm 2750 mm 1462 kg 150 mm 2.5 AT 4775 mm 1780 mm 1505 mm 2750 mm 1542 kg 150 mm 2.5 MT 4775 mm 1780 mm 1505 mm 2750 mm 1542 kg 150 mm 2.5 AT 4775 mm 1780 mm 1505 mm 2750 mm Not provided 150 mm 2.0 MT 4775 mm 1780 mm 1505 mm 2750 mm 1460 kg 150 mm 2.0 CVT 4775 mm 1780 mm 1505 mm 2750 mm 1460 kg 150 mm
Subaru B4 Cargo Space
Sedan — Subaru B4 Cargo Space
Estate 5-door — Subaru B4 Cargo Space
Subaru B4 Trims and Equipment
You choose Subaru B4 trim levels on top of a technical version, so equipment can change while the engine and gearbox stay the same. On the 2.0 CVT sedan petrol with variable transmission and all-wheel drive, BA and UA are equipment configurations that alter cabin kit, not the mechanical layout.
