Subaru B4 Specs, Engines & Dimensions (1998–2003) — Third Generation

The third-generation Subaru B4 is offered as a Sedan and an Estate 5-door. You get a practical, all-weather family car rather than a flashy luxury flagship.

← All Subaru models

Subaru B4 Engines and Transmissions

The Subaru B4 engine you will see in selected 3.0 AT cars is a 3.0 gasoline unit with an automatic transmission. That powertrain is offered in both the Sedan and the Estate 5-door, with all-wheel drive as the drivetrain. Treat these as examples of the generation, not the complete lineup.

Sedan — Subaru B4 Engines and Transmissions

Sedan Subaru B4 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 AT	Gasoline	1994 cm³	137 hp	101 kW	186 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1994 cm³	137 hp	101 kW	186 N⋅m	Manual	AWD
2.0 MT	Gasoline	1994 cm³	155 hp	114 kW	196 N⋅m	Manual	AWD
2.0 AT	Gasoline	1994 cm³	155 hp	114 kW	196 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1994 cm³	260 hp	191 kW	319 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1994 cm³	280 hp	206 kW	343 N⋅m	Manual	AWD
2.5 MT	Gasoline	2457 cm³	156 hp	115 kW	223 N⋅m	Manual	AWD
2.5 MT	Gasoline	2457 cm³	167 hp	123 kW	225 N⋅m	Manual	AWD
2.5 AT	Gasoline	2457 cm³	167 hp	123 kW	225 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2457 cm³	170 hp	125 kW	238 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2999 cm³	220 hp	162 kW	289 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1994 cm³	125 hp	92 kW	184 N⋅m	Manual	AWD
2.0 AT	Gasoline	1994 cm³	125 hp	92 kW	184 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2457 cm³	156 hp	115 kW	223 N⋅m	Automatic	AWD

Estate 5-door — Subaru B4 Engines and Transmissions

Estate 5-door Subaru B4 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1994 cm³	125 hp	92 kW	184 N⋅m	Manual	AWD
2.0 MT	Gasoline	1994 cm³	137 hp	101 kW	186 N⋅m	Manual	AWD
2.0 AT	Gasoline	1994 cm³	137 hp	101 kW	186 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1994 cm³	155 hp	114 kW	196 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1994 cm³	155 hp	114 kW	196 N⋅m	Manual	AWD
2.0 AT	Gasoline	1994 cm³	260 hp	191 kW	318 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1994 cm³	280 hp	206 kW	343 N⋅m	Manual	AWD
2.5 MT	Gasoline	2457 cm³	156 hp	115 kW	223 N⋅m	Manual	AWD
2.5 AT	Gasoline	2457 cm³	156 hp	115 kW	223 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2457 cm³	167 hp	123 kW	235 N⋅m	Automatic	AWD
2.5 MT	Gasoline	2457 cm³	167 hp	123 kW	235 N⋅m	Manual	AWD
2.5 AT	Gasoline	2457 cm³	167 hp	123 kW	235 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2457 cm³	170 hp	125 kW	238 N⋅m	Automatic	AWD
2.5 MT	Gasoline	2457 cm³	170 hp	125 kW	238 N⋅m	Manual	AWD
3.0 AT	Gasoline	2999 cm³	220 hp	162 kW	289 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1994 cm³	125 hp	92 kW	184 N⋅m	Automatic	AWD

Subaru B4 Dimensions

Sedan — Subaru B4 Dimensions

Sedan Subaru B4 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 AT	4605 mm	1695 mm	1415 mm	2650 mm	1380 kg	Not provided	155 mm
2.0 MT	4605 mm	1695 mm	1415 mm	2650 mm	1360 kg	Not provided	155 mm
2.0 MT	4605 mm	1695 mm	1415 mm	2650 mm	1410 kg	1870 kg	155 mm
2.0 AT	4605 mm	1695 mm	1415 mm	2650 mm	1390 kg	1870 kg	155 mm
2.0 AT	4605 mm	1695 mm	1415 mm	2650 mm	1380 kg	1520 kg	155 mm
2.0 MT	4605 mm	1695 mm	1415 mm	2650 mm	1440 kg	Not provided	155 mm
2.5 MT	4605 mm	1695 mm	1415 mm	2650 mm	1410 kg	1875 kg	155 mm
2.5 MT	4605 mm	1695 mm	1415 mm	2650 mm	1410 kg	1875 kg	155 mm
2.5 AT	4605 mm	1695 mm	1415 mm	2650 mm	1410 kg	1875 kg	155 mm
2.5 AT	4605 mm	1695 mm	1415 mm	2650 mm	1440 kg	1900 kg	155 mm
3.0 AT	4605 mm	1695 mm	1415 mm	2650 mm	1490 kg	1950 kg	155 mm
2.0 MT	4605 mm	1695 mm	1415 mm	2650 mm	1390 kg	1870 kg	155 mm
2.0 AT	4605 mm	1695 mm	1415 mm	2650 mm	1390 kg	1870 kg	155 mm
2.5 AT	4605 mm	1695 mm	1415 mm	2650 mm	1420 kg	1875 kg	160 mm

Estate 5-door — Subaru B4 Dimensions

Estate 5-door Subaru B4 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4680 mm	1695 mm	1515 mm	2650 mm	1390 kg	1870 kg	155 mm
2.0 MT	4680 mm	1695 mm	1515 mm	2650 mm	1370 kg	Not provided	155 mm
2.0 AT	4680 mm	1695 mm	1515 mm	2650 mm	1400 kg	Not provided	155 mm
2.0 AT	4680 mm	1695 mm	1515 mm	2650 mm	1440 kg	Not provided	165 mm
2.0 MT	4680 mm	1695 mm	1515 mm	2650 mm	1420 kg	Not provided	165 mm
2.0 AT	4680 mm	1695 mm	1515 mm	2650 mm	1510 kg	Not provided	160 mm
2.0 MT	4680 mm	1695 mm	1515 mm	2650 mm	1480 kg	Not provided	160 mm
2.5 MT	4680 mm	1695 mm	1515 mm	2650 mm	1410 kg	1875 kg	155 mm
2.5 AT	4680 mm	1695 mm	1515 mm	2650 mm	1450 kg	1800 kg	160 mm
2.5 AT	4680 mm	1695 mm	1515 mm	2650 mm	1460 kg	Not provided	160 mm
2.5 MT	4680 mm	1695 mm	1515 mm	2650 mm	1460 kg	Not provided	200 mm
2.5 AT	4680 mm	1695 mm	1515 mm	2650 mm	1480 kg	Not provided	200 mm
2.5 AT	4680 mm	1695 mm	1515 mm	2650 mm	1490 kg	Not provided	200 mm
2.5 MT	4680 mm	1695 mm	1515 mm	2650 mm	1470 kg	Not provided	200 mm
3.0 AT	4680 mm	1695 mm	1515 mm	2650 mm	1570 kg	Not provided	160 mm
2.0 AT	4680 mm	1695 mm	1515 mm	2650 mm	1390 kg	1870 kg	155 mm

Subaru B4 Cargo Space

Sedan — Subaru B4 Cargo Space

Sedan Subaru B4 Cargo Space
Modification	Trunk volume min
2.0 AT	465 l
2.0 MT	465 l
2.0 MT	465 l
2.0 AT	465 l
2.0 AT	465 l
2.0 MT	465 l
2.5 MT	465 l
2.5 MT	465 l
2.5 AT	465 l
2.5 AT	465 l
3.0 AT	465 l
2.0 MT	465 l
2.0 AT	465 l
2.5 AT	465 l

Estate 5-door — Subaru B4 Cargo Space

Estate 5-door Subaru B4 Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 MT	528 l	1646 l
2.0 MT	528 l	1646 l
2.0 AT	528 l	1646 l
2.0 AT	528 l	1646 l
2.0 MT	528 l	1646 l
2.0 AT	528 l	1646 l
2.0 MT	528 l	1646 l
2.5 MT	528 l	1646 l
2.5 AT	528 l	1646 l
2.5 AT	528 l	1646 l
2.5 MT	528 l	1646 l
2.5 AT	528 l	1646 l
2.5 AT	528 l	1646 l
2.5 MT	528 l	1646 l
3.0 AT	528 l	1646 l
2.0 AT	528 l	1646 l

Subaru B4 Trims and Equipment

Subaru B4 Trims and Equipment
Modification	Body	Equipment
2.5 MT	Sedan	Base
2.0 MT	Sedan	Base
2.0 MT	Sedan	GL
2.0 MT	Sedan	LX
2.0 AT	Sedan	Base
2.0 AT	Sedan	GL
2.5 AT	Sedan	Base
2.0 AT	Estate 5-door	GL
