Catalog / SEAT / Leon / 4 generation
SEAT Leon Engines and Transmissions
SEAT Leon engine options cover several approaches to the same car. The 2.0 DSG appears as a gasoline Estate 5-door and as a diesel Hatchback 5-door, both using a robotic dual-clutch transmission with front-wheel drive, while the 1.5 DSG hatchback brings plug-in hybrid power. Diesel suits long motorway commutes; gasoline feels livelier around town.
Estate 5-door — SEAT Leon Engines and Transmissions
Estate 5-door SEAT Leon Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 DSG Gasoline 1984 cm³ 190 hp 139 kW 326 N⋅m Robotic FWD 1.5 DSG Gasoline 1498 cm³ 150 hp 110 kW 255 N⋅m Robotic FWD
Hatchback 5-door — SEAT Leon Engines and Transmissions
Hatchback 5-door SEAT Leon Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.5 MT Gasoline 1498 cm³ 130 hp 96 kW 200 N⋅m Manual FWD 2.0 DSG Diesel 1968 cm³ 150 hp 110 kW 360 N⋅m Robotic FWD 1.0 MT Gasoline 999 cm³ 115 hp Not provided 203 N⋅m Manual FWD 1.5 DSG Gasoline 1498 cm³ 150 hp 110 kW 255 N⋅m Robotic FWD 2.0 DSG Gasoline 1984 cm³ 190 hp 139 kW 326 N⋅m Robotic FWD 1.0 DSG Gasoline 999 cm³ 110 hp 80 kW 200 N⋅m Robotic FWD 1.5 DSG Plug-in 1498 cm³ 272 hp 200 kW 250 N⋅m Robotic FWD 1.4 DSG Plug-in 1395 cm³ 204 hp 150 kW 250 N⋅m Robotic FWD
SEAT Leon Dimensions
Estate 5-door — SEAT Leon Dimensions
Estate 5-door SEAT Leon Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 DSG 4549 mm 1816 mm 1454 mm 2636 mm 1334 kg 1850 kg 160 mm 1.5 DSG 4549 mm 1816 mm 1454 mm 2636 mm 1361 kg 1900 kg Not provided
Hatchback 5-door — SEAT Leon Dimensions
Hatchback 5-door SEAT Leon Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.5 MT 4282 mm 1816 mm 1459 mm 2618 mm Not provided Not provided Not provided 2.0 DSG 4282 mm 1816 mm 1459 mm 2618 mm Not provided Not provided Not provided 1.0 MT 4282 mm 1816 mm 1459 mm 2618 mm 1197 kg 1720 kg Not provided 1.5 DSG 4282 mm 1816 mm 1459 mm 2618 mm 1361 kg 1900 kg Not provided 2.0 DSG 4282 mm 1816 mm 1459 mm 2618 mm 1334 kg 1850 kg 160 mm 1.0 DSG 4282 mm 1816 mm 1459 mm 2618 mm 1255 kg 1860 kg Not provided 1.5 DSG 4282 mm 1816 mm 1459 mm 2618 mm 1595 kg 2130 kg 160 mm 1.4 DSG 4282 mm 1816 mm 1459 mm 2618 mm 1539 kg 2060 kg 160 mm
SEAT Leon Cargo Space
Estate 5-door — SEAT Leon Cargo Space
Estate 5-door SEAT Leon Cargo Space Modification Trunk volume min
2.0 DSG 587 l 1.5 DSG 587 l
Hatchback 5-door — SEAT Leon Cargo Space
SEAT Leon Trims and Equipment
SEAT Leon trim levels decide what a given technical version actually carries rather than how it drives. The 1.0 MT Hatchback 5-door, a gasoline car with a manual gearbox and front-wheel drive, is offered in Style equipment. Trims usually change upholstery, lighting, wheels and infotainment while the mechanical package stays the same.
SEAT Leon Trims and Equipment Modification Body Equipment
1.0 MT Hatchback 5-door Style 2.0 DSG Hatchback 5-door FR 1.0 DSG Hatchback 5-door Style 1.5 DSG Hatchback 5-door FR
SEAT Leon Battery, Range
SEAT Leon battery capacity matters most on the plug-in hybrids. Both the 1.5 DSG and 1.4 DSG hatchbacks use a lithium-ion battery you recharge from a wallbox or household socket, covering short daily trips on electricity and calling on the combustion engine once the charge runs low.
Hatchback 5-door — SEAT Leon Battery, Range
Hatchback 5-door SEAT Leon Battery, Range Modification Battery power Battery type Driving range, maximum
1.5 DSG 25.8 kWh Lithium-ion batterie 133 km 1.4 DSG 12.8 kWh Lithium-ion batterie Not provided
