Catalog / SEAT / Ibiza / 3 generation
SEAT Ibiza Engines and Transmissions
The SEAT Ibiza engine lineup covers a range of gasoline options to suit different needs. For those who prefer a classic driving feel, manual transmissions are available with the 2.0 MT and 1.8 MT, delivering direct control. If convenience matters more, the 1.4 AT pairs a smooth automatic with front-wheel drive. All variants are front-wheel drive, keeping the Ibiza agile and efficient for daily commutes.
Mini 5-doors — SEAT Ibiza Engines and Transmissions
Mini 5-doors SEAT Ibiza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.2 MT Gasoline 1198 cm³ 54 hp 40 kW 106 N⋅m Manual FWD 1.2 MT Gasoline 1198 cm³ 64 hp 47 kW 112 N⋅m Manual FWD 2.0 MT Gasoline 1984 cm³ 115 hp 85 kW 170 N⋅m Manual FWD 1.4 MT Diesel 1422 cm³ 75 hp 55 kW 195 N⋅m Manual FWD 1.4 MT Diesel 1422 cm³ 80 hp 59 kW 195 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 101 hp 74 kW 240 N⋅m Manual FWD 1.4 AT Gasoline 1390 cm³ 75 hp 55 kW 126 N⋅m Automatic FWD 1.4 MT Gasoline 1390 cm³ 75 hp 55 kW 126 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 100 hp 74 kW 126 N⋅m Manual FWD 1.8 MT Gasoline 1781 cm³ 150 hp 110 kW 220 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 64 hp 47 kW 125 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 130 hp 96 kW 310 N⋅m Manual FWD
Mini 3-doors — SEAT Ibiza Engines and Transmissions
Mini 3-doors SEAT Ibiza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.2 MT Gasoline 1198 cm³ 54 hp 40 kW 106 N⋅m Manual FWD 1.2 MT Gasoline 1198 cm³ 64 hp 47 kW 112 N⋅m Manual FWD 2.0 MT Gasoline 1984 cm³ 115 hp 85 kW 170 N⋅m Manual FWD 1.4 MT Diesel 1422 cm³ 75 hp 55 kW 195 N⋅m Manual FWD 1.4 MT Diesel 1422 cm³ 80 hp 59 kW 195 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 101 hp 74 kW 240 N⋅m Manual FWD 1.4 AT Gasoline 1390 cm³ 75 hp 55 kW 126 N⋅m Automatic FWD 1.4 MT Gasoline 1390 cm³ 75 hp 55 kW 126 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 100 hp 74 kW 126 N⋅m Manual FWD 1.8 MT Gasoline 1781 cm³ 150 hp 110 kW 220 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 64 hp 47 kW 125 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 130 hp 96 kW 310 N⋅m Manual FWD
SEAT Ibiza Dimensions
Mini 5-doors — SEAT Ibiza Dimensions
Mini 5-doors SEAT Ibiza Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.2 MT 3953 mm 1698 mm 1441 mm 2460 mm 1010 kg Not provided 110 mm 1.2 MT 3953 mm 1698 mm 1441 mm 2460 mm 1053 kg 1560 kg Not provided 2.0 MT 3953 mm 1698 mm 1441 mm 2460 mm 1125 kg 1645 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1132 kg 1645 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1095 kg Not provided 110 mm 1.9 MT 3953 mm 1698 mm 1441 mm 2460 mm 1170 kg 1682 kg Not provided 1.4 AT 3953 mm 1698 mm 1441 mm 2460 mm 1090 kg 1600 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1055 kg 1565 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1055 kg 1565 kg Not provided 1.8 MT 3953 mm 1698 mm 1441 mm 2460 mm 1180 kg 1675 kg Not provided 1.9 MT 3953 mm 1698 mm 1441 mm 2460 mm 1130 kg 1635 kg Not provided 1.9 MT 3953 mm 1698 mm 1441 mm 2460 mm 1205 kg 1700 kg Not provided
Mini 3-doors — SEAT Ibiza Dimensions
Mini 3-doors SEAT Ibiza Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.2 MT 3953 mm 1698 mm 1441 mm 2460 mm 1010 kg Not provided 110 mm 1.2 MT 3953 mm 1698 mm 1441 mm 2460 mm 1053 kg 1560 kg Not provided 2.0 MT 3953 mm 1698 mm 1441 mm 2460 mm 1125 kg 1645 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1132 kg 1645 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1095 kg Not provided 110 mm 1.9 MT 3953 mm 1698 mm 1441 mm 2460 mm 1170 kg 1682 kg Not provided 1.4 AT 3953 mm 1698 mm 1441 mm 2460 mm 1090 kg 1600 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1055 kg 1565 kg Not provided 1.4 MT 3953 mm 1698 mm 1441 mm 2460 mm 1055 kg 1565 kg Not provided 1.8 MT 3953 mm 1698 mm 1441 mm 2460 mm 1180 kg 1675 kg Not provided 1.9 MT 3953 mm 1698 mm 1441 mm 2460 mm 1130 kg 1635 kg Not provided 1.9 MT 3953 mm 1698 mm 1441 mm 2460 mm 1205 kg 1700 kg Not provided
SEAT Ibiza Cargo Space
Mini 5-doors — SEAT Ibiza Cargo Space
Mini 3-doors — SEAT Ibiza Cargo Space
