Porsche 718 Cayman Specs, Engines & Dimensions (2004–2009)

Porsche 718 Cayman Engines and Transmissions

The 2.7 MT and 2.7 AT illustrate two gasoline powertrain choices, both with rear-wheel drive. The manual lets you choose gears and operate the clutch yourself, while the automatic reduces that workload in traffic. Consider how involved you want to be when choosing your engine and transmission combination.

Coupe — Porsche 718 Cayman Engines and Transmissions

Coupe Porsche 718 Cayman Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.7 MT	Gasoline	2687 cm³	245 hp	180 kW	273 N⋅m	Manual	RWD
2.7 AT	Gasoline	2687 cm³	245 hp	180 kW	270 N⋅m	Automatic	RWD
3.4 AT	Gasoline	3387 cm³	303 hp	223 kW	340 N⋅m	Automatic	RWD
3.4 MT	Gasoline	3387 cm³	303 hp	223 kW	340 N⋅m	Manual	RWD
3.4 MT	Gasoline	3386 cm³	295 hp	217 kW	340 N⋅m	Manual	RWD
3.4 AT	Gasoline	3386 cm³	295 hp	217 kW	340 N⋅m	Automatic	RWD

Porsche 718 Cayman Dimensions

Coupe — Porsche 718 Cayman Dimensions

Coupe Porsche 718 Cayman Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.7 MT	4341 mm	1801 mm	1305 mm	2415 mm	1300 kg	1620 kg	121 mm
2.7 AT	4341 mm	1801 mm	1305 mm	2415 mm	1360 kg	1630 kg	114 mm
3.4 AT	4341 mm	1801 mm	1305 mm	2415 mm	1340 kg	1630 kg	114 mm
3.4 MT	4341 mm	1801 mm	1305 mm	2415 mm	1340 kg	1630 kg	114 mm
3.4 MT	4341 mm	1801 mm	1305 mm	2415 mm	1340 kg	1630 kg	121 mm
3.4 AT	4341 mm	1801 mm	1305 mm	2415 mm	1385 kg	1670 kg	121 mm

Porsche 718 Cayman Cargo Space

Coupe — Porsche 718 Cayman Cargo Space

Coupe Porsche 718 Cayman Cargo Space
Modification	Trunk volume min	Trunk volume max
2.7 MT	150 l	260 l
2.7 AT	150 l	260 l
3.4 AT	150 l	260 l
3.4 MT	150 l	260 l
3.4 MT	150 l	260 l
3.4 AT	150 l	260 l

Porsche 718 Cayman Trims and Equipment

For the 2.7 MT, Cayman and Individual are named equipment configurations. When comparing Porsche 718 Cayman trim levels, look beyond the badge to the actual car’s fitted options. Seats, cabin conveniences and other equipment can influence everyday comfort, so check which features each example includes.

Porsche 718 Cayman Trims and Equipment
Modification	Body	Equipment
2.7 MT	Coupe	Cayman
2.7 MT	Coupe	Individual
2.7 AT	Coupe	Individual
3.4 MT	Coupe	Porsche Design Edition 1
3.4 MT	Coupe	S Sport
3.4 MT	Coupe	Individual
3.4 AT	Coupe	Individual
