Catalog / Pontiac / Grand AM / 5 generation
Pontiac Grand AM Engines and Transmissions
A Pontiac Grand AM engine sits in a gasoline powertrain that drives the front wheels. Coupe examples include the 2.2 MT with a manual transmission, the 2.2 AT with automatic, and the 2.4 MT for a larger four and a stick. Those are samples, not every pairing.
Coupe — Pontiac Grand AM Engines and Transmissions
Coupe Pontiac Grand AM Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.2 MT Gasoline 2189 cm³ 140 hp 103 kW 203 N⋅m Manual FWD 2.2 AT Gasoline 2189 cm³ 140 hp 103 kW 203 N⋅m Automatic FWD 2.4 MT Gasoline 2392 cm³ 150 hp 110 kW 210 N⋅m Manual FWD 2.4 AT Gasoline 2392 cm³ 150 hp 110 kW 210 N⋅m Automatic FWD 3.4 AT Gasoline 3350 cm³ 170 hp 125 kW 264 N⋅m Automatic FWD 3.4 AT Gasoline 3350 cm³ 175 hp 129 kW 279 N⋅m Automatic FWD
Sedan — Pontiac Grand AM Engines and Transmissions
Sedan Pontiac Grand AM Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.2 AT Gasoline 2189 cm³ 140 hp 103 kW 203 N⋅m Automatic FWD 2.2 MT Gasoline 2189 cm³ 140 hp 103 kW 203 N⋅m Manual FWD 2.4 MT Gasoline 2392 cm³ 150 hp 110 kW 210 N⋅m Manual FWD 2.4 AT Gasoline 2392 cm³ 150 hp 110 kW 210 N⋅m Automatic FWD 3.4 AT Gasoline 3350 cm³ 170 hp 125 kW 264 N⋅m Automatic FWD 3.4 AT Gasoline 3350 cm³ 175 hp 129 kW 279 N⋅m Automatic FWD
Pontiac Grand AM Dimensions
Coupe — Pontiac Grand AM Dimensions
Coupe Pontiac Grand AM Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 2.2 MT 4730 mm 1790 mm 1380 mm 2718 mm 1395 kg 145 mm 2.2 AT 4730 mm 1790 mm 1380 mm 2718 mm 1395 kg 145 mm 2.4 MT 4730 mm 1790 mm 1380 mm 2718 mm 1415 kg 145 mm 2.4 AT 4730 mm 1790 mm 1380 mm 2718 mm 1385 kg 145 mm 3.4 AT 4730 mm 1790 mm 1380 mm 2718 mm 1400 kg 145 mm 3.4 AT 4730 mm 1790 mm 1380 mm 2718 mm Not provided 145 mm
Sedan — Pontiac Grand AM Dimensions
Sedan Pontiac Grand AM Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 2.2 AT 4730 mm 1790 mm 1400 mm 2718 mm 1415 kg 145 mm 2.2 MT 4730 mm 1790 mm 1400 mm 2718 mm 1415 kg 145 mm 2.4 MT 4730 mm 1790 mm 1400 mm 2718 mm 1415 kg 145 mm 2.4 AT 4730 mm 1790 mm 1400 mm 2718 mm 1385 kg 145 mm 3.4 AT 4730 mm 1790 mm 1400 mm 2718 mm 1430 kg 145 mm 3.4 AT 4730 mm 1790 mm 1400 mm 2718 mm Not provided 145 mm
Pontiac Grand AM Cargo Space
Coupe — Pontiac Grand AM Cargo Space
Sedan — Pontiac Grand AM Cargo Space
