Catalog / Pontiac / Grand AM / 3 generation
Pontiac Grand AM Engines and Transmissions
A Pontiac Grand AM engine in this generation is a gasoline unit with a front-wheel-drive drivetrain. You get a manual transmission in the 2.0 MT Coupe, or an automatic in the 2.0 AT and 2.3 AT Coupes for easier daily driving. Those powertrains are selected examples, not the full lineup.
Coupe — Pontiac Grand AM Engines and Transmissions
Coupe Pontiac Grand AM Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 MT Gasoline 1994 cm³ 165 hp 121 kW 200 N⋅m Manual FWD 2.0 AT Gasoline 1994 cm³ 165 hp 121 kW 200 N⋅m Automatic FWD 2.3 AT Gasoline 2260 cm³ 160 hp 118 kW 210 N⋅m Automatic FWD 2.3 MT Gasoline 2260 cm³ 180 hp 132 kW 190 N⋅m Manual FWD 2.5 MT Gasoline 2471 cm³ 92 hp 68 kW 183 N⋅m Manual FWD 2.5 AT Gasoline 2471 cm³ 92 hp 68 kW 183 N⋅m Automatic FWD 2.5 MT Gasoline 2471 cm³ 98 hp 72 kW 183 N⋅m Manual FWD 2.5 AT Gasoline 2471 cm³ 98 hp 72 kW 183 N⋅m Automatic FWD 3.1 MT Gasoline 3135 cm³ 125 hp 92 kW 200 N⋅m Manual FWD 3.1 AT Gasoline 3135 cm³ 125 hp 92 kW 200 N⋅m Automatic FWD
Sedan — Pontiac Grand AM Engines and Transmissions
Sedan Pontiac Grand AM Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 MT Gasoline 1994 cm³ 165 hp 121 kW 200 N⋅m Manual FWD 2.0 AT Gasoline 1994 cm³ 165 hp 121 kW 200 N⋅m Automatic FWD 2.3 AT Gasoline 2260 cm³ 160 hp 118 kW 210 N⋅m Automatic FWD 2.3 MT Gasoline 2260 cm³ 180 hp 132 kW 190 N⋅m Manual FWD 3.1 MT Gasoline 3135 cm³ 125 hp 92 kW 200 N⋅m Manual FWD 3.1 AT Gasoline 3135 cm³ 125 hp 92 kW 200 N⋅m Automatic FWD 2.5 MT Gasoline 2471 cm³ 90 hp 66 kW 173 N⋅m Manual FWD 2.5 AT Gasoline 2471 cm³ 90 hp 66 kW 173 N⋅m Automatic FWD 2.5 MT Gasoline 2471 cm³ 98 hp 72 kW 183 N⋅m Manual FWD 2.5 AT Gasoline 2471 cm³ 98 hp 72 kW 183 N⋅m Automatic FWD
Pontiac Grand AM Dimensions
Coupe — Pontiac Grand AM Dimensions
Coupe Pontiac Grand AM Dimensions Modification Length Width Height Wheelbase Ground clearance, minimum
2.0 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.0 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.3 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.3 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 3.1 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 3.1 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm
Sedan — Pontiac Grand AM Dimensions
Sedan Pontiac Grand AM Dimensions Modification Length Width Height Wheelbase Ground clearance, minimum
2.0 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.0 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.3 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.3 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 3.1 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 3.1 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 MT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm 2.5 AT 4510 mm 1690 mm 1340 mm 2630 mm 140 mm
