Catalog / Peugeot / 508 / 1 generation, restyling
Peugeot 508 Engines and Transmissions
A Peugeot 508 engine in this restyling can be petrol, diesel or hybrid, depending on the powertrain you choose. Among Estate 5-door examples, a 1.6 MT diesel uses a manual gearbox and front-wheel drive, while a 1.6 EGS gasoline pairs with a robotic transmission. The 2.0 EGS hybrid drivetrain adds all-wheel drive.
Estate 5-door — Peugeot 508 Engines and Transmissions
Estate 5-door Peugeot 508 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 EGS Hybrid 1997 cm³ 163 hp 120 kW 300 N⋅m Robotic AWD 2.0 AT Diesel 1997 cm³ 180 hp 133 kW 400 N⋅m Automatic FWD 1.6 MT Diesel 1560 cm³ 115 hp 85 kW 270 N⋅m Manual FWD 1.6 EGS Diesel 1560 cm³ 115 hp 85 kW 270 N⋅m Robotic FWD 2.0 AT Diesel 1997 cm³ 136 hp 100 kW 320 N⋅m Automatic FWD 2.0 MT Diesel 1997 cm³ 150 hp 110 kW 370 N⋅m Manual FWD 2.0 AT Diesel 1997 cm³ 163 hp 120 kW 340 N⋅m Automatic FWD 2.0 MT Diesel 1997 cm³ 163 hp 120 kW 340 N⋅m Manual FWD 2.0 AT Diesel 1997 cm³ 180 hp 132 kW 400 N⋅m Automatic FWD 2.2 AT Diesel 2179 cm³ 204 hp 150 kW 450 N⋅m Automatic FWD 1.6 EGS Gasoline 1598 cm³ 120 hp 88 kW 160 N⋅m Robotic FWD 1.6 AT Gasoline 1598 cm³ 150 hp 110 kW 240 N⋅m Automatic FWD 1.6 AT Gasoline 1598 cm³ 156 hp 115 kW 240 N⋅m Automatic FWD 1.6 MT Gasoline 1598 cm³ 165 hp 121 kW 240 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 165 hp 121 kW 240 N⋅m Automatic FWD
Sedan — Peugeot 508 Engines and Transmissions
Sedan Peugeot 508 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 AT Gasoline 1598 cm³ 150 hp 110 kW 240 N⋅m Automatic FWD 1.6 EGS Gasoline 1598 cm³ 120 hp 88 kW 160 N⋅m Robotic FWD 1.6 AT Gasoline 1598 cm³ 156 hp 115 kW 240 N⋅m Automatic FWD 1.6 AT Gasoline 1598 cm³ 165 hp 121 kW 240 N⋅m Automatic FWD 2.0 AT Diesel 1997 cm³ 180 hp 132 kW 400 N⋅m Automatic FWD 1.6 MT Diesel 1560 cm³ 115 hp 84 kW 270 N⋅m Manual FWD 1.6 EGS Diesel 1560 cm³ 115 hp 85 kW 270 N⋅m Robotic FWD 2.0 AT Diesel 1997 cm³ 136 hp 100 kW 340 N⋅m Automatic FWD 2.0 AT Diesel 1997 cm³ 140 hp 103 kW 320 N⋅m Automatic FWD 2.0 MT Diesel 1997 cm³ 150 hp 110 kW 370 N⋅m Manual FWD 2.0 MT Diesel 1997 cm³ 163 hp 120 kW 340 N⋅m Manual FWD 2.0 AT Diesel 1997 cm³ 163 hp 120 kW 340 N⋅m Automatic FWD 2.0 AT Diesel 1997 cm³ 180 hp 133 kW 400 N⋅m Automatic FWD 2.2 AT Diesel 2179 cm³ 204 hp 150 kW 450 N⋅m Automatic FWD 2.0 ETG Hybrid 1997 cm³ 163 hp 120 kW 300 N⋅m Robotic FWD 1.6 AT Gasoline 1598 cm³ 156 hp 115 kW 240 N⋅m Automatic FWD 1.6 MT Gasoline 1598 cm³ 165 hp 121 kW 240 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 165 hp 121 kW 240 N⋅m Automatic FWD
Peugeot 508 Dimensions
Estate 5-door — Peugeot 508 Dimensions
Estate 5-door Peugeot 508 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 EGS 4828 mm 1864 mm 1525 mm 2817 mm 1845 kg 2325 kg 184 mm 2.0 AT 4828 mm 1864 mm 1525 mm 2817 mm 1725 kg 2240 kg 184 mm 1.6 MT 4828 mm 1864 mm 1525 mm 2817 mm 1505 kg 2100 kg 170 mm 1.6 EGS 4828 mm 1864 mm 1525 mm 2817 mm 1505 kg 2100 kg 170 mm 2.0 AT 4828 mm 1864 mm 1525 mm 2817 mm Not provided Not provided 170 mm 2.0 MT 4828 mm 1864 mm 1525 mm 2817 mm 1595 kg 2200 kg 170 mm 2.0 AT 4828 mm 1864 mm 1525 mm 2817 mm 1615 kg 2180 kg 170 mm 2.0 MT 4828 mm 1864 mm 1525 mm 2817 mm 1575 kg 2140 kg 170 mm 2.0 AT 4828 mm 1864 mm 1525 mm 2817 mm 1695 kg 2240 kg 170 mm 2.2 AT 4828 mm 1864 mm 1525 mm 2817 mm 1735 kg 2280 kg 170 mm 1.6 EGS 4828 mm 1864 mm 1525 mm 2817 mm 1485 kg 2055 kg 170 mm 1.6 AT 4828 mm 1864 mm 1525 mm 2817 mm Not provided Not provided 170 mm 1.6 AT 4828 mm 1864 mm 1525 mm 2817 mm Not provided Not provided 170 mm 1.6 MT 4828 mm 1864 mm 1525 mm 2817 mm 1495 kg 2080 kg 170 mm 1.6 AT 4828 mm 1864 mm 1525 mm 2817 mm 1505 kg 2100 kg 170 mm
Sedan — Peugeot 508 Dimensions
Sedan Peugeot 508 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 AT 4792 mm 1853 mm 1456 mm 2817 mm 1485 kg Not provided 170 mm 1.6 EGS 4792 mm 1853 mm 1456 mm 2817 mm 1465 kg 1945 kg 170 mm 1.6 AT 4792 mm 1853 mm 1456 mm 2817 mm Not provided Not provided 170 mm 1.6 AT 4792 mm 1853 mm 1456 mm 2817 mm 1485 kg 2015 kg 170 mm 2.0 AT 4792 mm 1853 mm 1456 mm 2817 mm 1615 kg 2165 kg 170 mm 1.6 MT 4792 mm 1853 mm 1456 mm 2817 mm 1485 kg 2005 kg 170 mm 1.6 EGS 4792 mm 1853 mm 1456 mm 2817 mm 1485 kg 2005 kg 170 mm 2.0 AT 4792 mm 1853 mm 1456 mm 2817 mm 1595 kg Not provided 170 mm 2.0 AT 4792 mm 1853 mm 1456 mm 2817 mm 1430 kg Not provided 170 mm 2.0 MT 4792 mm 1853 mm 1456 mm 2817 mm 1575 kg 2125 kg 170 mm 2.0 MT 4792 mm 1853 mm 1456 mm 2817 mm 1505 kg 2075 kg 170 mm 2.0 AT 4792 mm 1853 mm 1456 mm 2817 mm 1595 kg 2105 kg 170 mm 2.0 AT 4792 mm 1853 mm 1456 mm 2817 mm 1615 kg 2165 kg 170 mm 2.2 AT 4792 mm 1853 mm 1456 mm 2817 mm 1615 kg Not provided 170 mm 2.0 ETG 4792 mm 1853 mm 1456 mm 2817 mm 1735 kg 2265 kg 170 mm 1.6 AT 4792 mm 1853 mm 1456 mm 2817 mm Not provided Not provided 170 mm 1.6 MT 4792 mm 1853 mm 1456 mm 2817 mm 1475 kg 1995 kg 170 mm 1.6 AT 4792 mm 1853 mm 1456 mm 2817 mm 1505 kg 2100 kg 170 mm
Peugeot 508 Cargo Space
Estate 5-door — Peugeot 508 Cargo Space
Sedan — Peugeot 508 Cargo Space
Peugeot 508 Trims and Equipment
Peugeot 508 trim levels sit on a technical version, so you pick the powertrain first and the cabin equipment next. On the 1.6 MT Sedan with a gasoline engine, manual gearbox and front-wheel drive, Active is one named equipment configuration. That trim shapes comfort and convenience without changing the drivetrain.
Peugeot 508 Trims and Equipment Modification Body Equipment
1.6 AT Sedan Active 1.6 AT Sedan Allure 2.0 AT Sedan Allure 1.6 MT Sedan Active
