Peugeot 504 Specs, Engines & Dimensions (1968–1996) — First Generation

The first-generation Peugeot 504 spans Pickup single-cab, Estate 5-door, Sedan, Coupe and Cabrio bodies. You get the same rear-drive layout across them, with each shape aimed at a different everyday role.

← All Peugeot models

Peugeot 504 Engines and Transmissions

A Peugeot 504 engine is matched to the job. The Pickup single-cab 1.6 MT gasoline and 1.9 MT diesel pair a manual gearbox with rear-wheel drive for work, while the Coupe 2.0 AT uses gasoline, an automatic and the same rear drivetrain. These are examples, not the full powertrain range.

Pickup single-cab — Peugeot 504 Engines and Transmissions

Pickup single-cab Peugeot 504 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Transmission	Type of drive
1.6 MT	Gasoline	1600 cm³	63 hp	46 kW	Manual	RWD
1.8 MT	Gasoline	1800 cm³	82 hp	60 kW	Manual	RWD
1.9 MT	Diesel	1900 cm³	54 hp	40 kW	Manual	RWD
2.3 MT	Diesel	2300 cm³	69 hp	51 kW	Manual	RWD

Cabrio — Peugeot 504 Engines and Transmissions

Cabrio Peugeot 504 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1971 cm³	98 hp	72 kW	181 N⋅m	Manual	RWD
2.0 AT	Gasoline	1971 cm³	98 hp	72 kW	181 N⋅m	Automatic	RWD
2.0 MT	Gasoline	2000 cm³	106 hp	78 kW	Not provided	Manual	RWD
2.0 AT	Gasoline	2000 cm³	106 hp	78 kW	Not provided	Automatic	RWD
2.7 MT	Gasoline	2664 cm³	144 hp	104 kW	213 N⋅m	Manual	RWD

Coupe — Peugeot 504 Engines and Transmissions

Coupe Peugeot 504 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	2000 cm³	106 hp	78 kW	Not provided	Manual	RWD
2.0 AT	Gasoline	2000 cm³	106 hp	78 kW	Not provided	Automatic	RWD
2.7 MT	Gasoline	2700 cm³	144 hp	106 kW	Not provided	Manual	RWD
2.0 MT	Gasoline	1971 cm³	98 hp	72 kW	181 N⋅m	Manual	RWD

Sedan — Peugeot 504 Engines and Transmissions

Sedan Peugeot 504 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1800 cm³	82 hp	60 kW	Not provided	Manual	RWD
1.8 AT	Gasoline	1800 cm³	97 hp	71 kW	Not provided	Automatic	RWD
1.8 MT	Gasoline	1800 cm³	97 hp	71 kW	Not provided	Manual	RWD
2.0 AT	Gasoline	1971 cm³	98 hp	72 kW	181 N⋅m	Automatic	RWD
2.0 AT	Gasoline	2000 cm³	106 hp	78 kW	Not provided	Automatic	RWD
2.0 MT	Gasoline	2000 cm³	106 hp	78 kW	Not provided	Manual	RWD
1.9 MT	Diesel	1900 cm³	54 hp	40 kW	Not provided	Manual	RWD
2.1 MT	Diesel	2112 cm³	59 hp	41 kW	111 N⋅m	Manual	RWD
2.1 MT	Diesel	2112 cm³	62 hp	46 kW	121 N⋅m	Manual	RWD
2.3 MT	Diesel	2304 cm³	70 hp	51 kW	120 N⋅m	Manual	RWD
1.8 MT	Gasoline	1796 cm³	79 hp	58 kW	140 N⋅m	Manual	RWD
2.0 MT	Gasoline	1971 cm³	98 hp	72 kW	181 N⋅m	Manual	RWD

Estate 5-door — Peugeot 504 Engines and Transmissions

Estate 5-door Peugeot 504 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1800 cm³	79 hp	58 kW	Not provided	Manual	RWD
2.0 MT	Gasoline	2000 cm³	94 hp	69 kW	Not provided	Manual	RWD
2.1 MT	Diesel	2112 cm³	62 hp	46 kW	121 N⋅m	Manual	RWD
2.3 MT	Diesel	2300 cm³	69 hp	51 kW	Not provided	Manual	RWD

Peugeot 504 Dimensions

Pickup single-cab — Peugeot 504 Dimensions

Pickup single-cab Peugeot 504 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
1.6 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm
1.8 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm
1.9 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm
2.3 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm

Cabrio — Peugeot 504 Dimensions

Cabrio Peugeot 504 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4361 mm	1699 mm	1359 mm	2550 mm	Not provided	Not provided	165 mm
2.0 AT	4361 mm	1699 mm	1359 mm	2550 mm	Not provided	Not provided	165 mm
2.0 MT	4361 mm	1699 mm	1359 mm	2550 mm	Not provided	Not provided	165 mm
2.0 AT	4361 mm	1699 mm	1359 mm	2550 mm	Not provided	Not provided	165 mm
2.7 MT	4361 mm	1699 mm	1359 mm	2550 mm	1295 kg	1850 kg	Not provided

Coupe — Peugeot 504 Dimensions

Coupe Peugeot 504 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
2.0 MT	4361 mm	1699 mm	1349 mm	2550 mm	165 mm
2.0 AT	4361 mm	1699 mm	1349 mm	2550 mm	165 mm
2.7 MT	4361 mm	1699 mm	1349 mm	2550 mm	165 mm
2.0 MT	4361 mm	1699 mm	1349 mm	2550 mm	165 mm

Sedan — Peugeot 504 Dimensions

Sedan Peugeot 504 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
1.8 AT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
1.8 MT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
2.0 AT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
2.0 AT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
2.0 MT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
1.9 MT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
2.1 MT	4491 mm	1689 mm	1461 mm	2714 mm	1210 kg	1690 kg	Not provided
2.1 MT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm
2.3 MT	4491 mm	1689 mm	1461 mm	2714 mm	1210 kg	1690 kg	Not provided
1.8 MT	4491 mm	1689 mm	1461 mm	2714 mm	1081 kg	1640 kg	Not provided
2.0 MT	4491 mm	1689 mm	1461 mm	2714 mm	Not provided	Not provided	165 mm

Estate 5-door — Peugeot 504 Dimensions

Estate 5-door Peugeot 504 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
1.8 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm
2.0 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm
2.1 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm
2.3 MT	4800 mm	1694 mm	1550 mm	2900 mm	165 mm

Peugeot 504 Cargo Space

Cabrio — Peugeot 504 Cargo Space

Cabrio Peugeot 504 Cargo Space
Modification	Trunk volume min
2.0 MT	357 l
2.0 AT	357 l
2.0 MT	357 l
2.0 AT	357 l
2.7 MT	357 l

Coupe — Peugeot 504 Cargo Space

Coupe Peugeot 504 Cargo Space
Modification	Trunk volume min
2.0 MT	357 l
2.0 AT	357 l
2.7 MT	357 l
2.0 MT	357 l

Sedan — Peugeot 504 Cargo Space

Sedan Peugeot 504 Cargo Space
Modification	Trunk volume min
1.8 MT	459 l
1.8 AT	459 l
1.8 MT	459 l
2.0 AT	459 l
2.0 AT	459 l
2.0 MT	459 l
1.9 MT	459 l
2.1 MT	459 l
2.1 MT	459 l
2.3 MT	459 l
1.8 MT	459 l
2.0 MT	459 l
