Catalog / Peugeot / 406 / 1 generation, restyling
Peugeot 406 Engines and Transmissions
You can match a Peugeot 406 engine to a manual or automatic, gasoline or diesel. Coupe examples include the gasoline 2.0 MT with a manual and the gasoline 2.0 AT automatic, both front-wheel drive. A Sedan example is the diesel 2.0 AT automatic, so powertrain and drivetrain character follow the version you pick.
Coupe — Peugeot 406 Engines and Transmissions
Coupe Peugeot 406 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1997 cm³ 135 hp 99 kW 190 N⋅m Manual FWD 2.0 AT Gasoline 1997 cm³ 135 hp 99 kW 190 N⋅m Automatic FWD 2.2 MT Gasoline 2231 cm³ 158 hp 116 kW 217 N⋅m Manual FWD 3.0 MT Gasoline 2946 cm³ 207 hp 152 kW 285 N⋅m Manual FWD 3.0 AT Gasoline 2946 cm³ 207 hp 152 kW 285 N⋅m Automatic FWD 2.2 MT Diesel 2179 cm³ 133 hp 98 kW 314 N⋅m Manual FWD
Sedan — Peugeot 406 Engines and Transmissions
Sedan Peugeot 406 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.8 MT Gasoline 1761 cm³ 90 hp 66 kW 147 N⋅m Manual FWD 2.0 MT Gasoline 1997 cm³ 136 hp 100 kW 190 N⋅m Manual FWD 2.0 AT Gasoline 1997 cm³ 140 hp 103 kW 192 N⋅m Automatic FWD 2.0 MT Gasoline 1997 cm³ 140 hp 103 kW 192 N⋅m Manual FWD 2.2 MT Gasoline 2231 cm³ 158 hp 116 kW 217 N⋅m Manual FWD 3.0 MT Gasoline 2946 cm³ 207 hp 152 kW 285 N⋅m Manual FWD 3.0 AT Gasoline 2946 cm³ 207 hp 152 kW 285 N⋅m Automatic FWD 2.0 MT Diesel 1997 cm³ 109 hp 80 kW 250 N⋅m Manual FWD 2.2 MT Diesel 2179 cm³ 133 hp 98 kW 314 N⋅m Manual FWD 1.8 AT Gasoline 1749 cm³ 116 hp 85 kW 163 N⋅m Automatic FWD 1.8 MT Gasoline 1749 cm³ 116 hp 85 kW 163 N⋅m Manual FWD 1.8 MT Gasoline 1761 cm³ 110 hp 81 kW 155 N⋅m Manual FWD 2.0 AT Gasoline 1997 cm³ 136 hp 100 kW 190 N⋅m Automatic FWD 2.0 MT Diesel 1997 cm³ 90 hp 66 kW 205 N⋅m Manual FWD 2.0 AT Diesel 1997 cm³ 109 hp 80 kW 250 N⋅m Automatic FWD
Estate 5-door — Peugeot 406 Engines and Transmissions
Estate 5-door Peugeot 406 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.8 MT Gasoline 1749 cm³ 116 hp 85 kW 163 N⋅m Manual FWD 1.8 MT Gasoline 1761 cm³ 90 hp 66 kW 147 N⋅m Manual FWD 2.0 MT Gasoline 1997 cm³ 135 hp 99 kW 190 N⋅m Manual FWD 2.0 MT Gasoline 1997 cm³ 140 hp 103 kW 192 N⋅m Manual FWD 2.2 MT Gasoline 2231 cm³ 158 hp 116 kW 217 N⋅m Manual FWD 3.0 AT Gasoline 2946 cm³ 207 hp 152 kW 285 N⋅m Automatic FWD 3.0 MT Gasoline 2946 cm³ 207 hp 152 kW 285 N⋅m Manual FWD 2.0 MT Diesel 1997 cm³ 109 hp 80 kW 250 N⋅m Manual FWD 2.0 AT Diesel 1997 cm³ 109 hp 80 kW 250 N⋅m Automatic FWD 2.2 MT Diesel 2179 cm³ 133 hp 98 kW 314 N⋅m Manual FWD 1.8 AT Gasoline 1749 cm³ 116 hp 85 kW 163 N⋅m Automatic FWD 2.0 AT Gasoline 1997 cm³ 135 hp 99 kW 190 N⋅m Automatic FWD 2.0 MT Diesel 1997 cm³ 90 hp 66 kW 205 N⋅m Manual FWD
Peugeot 406 Dimensions
Coupe — Peugeot 406 Dimensions
Coupe Peugeot 406 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4620 mm 1780 mm 1352 mm 2700 mm 1385 kg 1785 kg 120 mm 2.0 AT 4620 mm 1780 mm 1352 mm 2700 mm 1385 kg 1785 kg 120 mm 2.2 MT 4620 mm 1780 mm 1352 mm 2700 mm 1415 kg 1910 kg 120 mm 3.0 MT 4620 mm 1780 mm 1352 mm 2700 mm 1460 kg 1910 kg 120 mm 3.0 AT 4620 mm 1780 mm 1352 mm 2700 mm 1460 kg 1910 kg 120 mm 2.2 MT 4620 mm 1780 mm 1352 mm 2700 mm 1435 kg 1835 kg 120 mm
Sedan — Peugeot 406 Dimensions
Sedan Peugeot 406 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.8 MT 4598 mm 1765 mm 1412 mm 2700 mm 1250 kg 1770 kg 130 mm 2.0 MT 4598 mm 1765 mm 1412 mm 2700 mm 1290 kg 1915 kg 130 mm 2.0 AT 4598 mm 1765 mm 1412 mm 2700 mm 1345 kg 1880 kg 130 mm 2.0 MT 4598 mm 1765 mm 1412 mm 2700 mm 1340 kg 1880 kg 130 mm 2.2 MT 4598 mm 1765 mm 1412 mm 2700 mm 1370 kg 1910 kg 130 mm 3.0 MT 4598 mm 1765 mm 1412 mm 2700 mm 1455 kg 1995 kg 130 mm 3.0 AT 4598 mm 1765 mm 1412 mm 2700 mm Not provided 1995 kg 130 mm 2.0 MT 4598 mm 1765 mm 1412 mm 2700 mm Not provided Not provided 130 mm 2.2 MT 4598 mm 1765 mm 1412 mm 2700 mm 1410 kg 1950 kg 130 mm 1.8 AT 4598 mm 1765 mm 1412 mm 2700 mm 1315 kg 1880 kg 130 mm 1.8 MT 4598 mm 1765 mm 1412 mm 2700 mm 1290 kg 1855 kg 130 mm 1.8 MT 4598 mm 1765 mm 1412 mm 2700 mm 1225 kg 1770 kg 130 mm 2.0 AT 4598 mm 1765 mm 1412 mm 2700 mm 1330 kg 1955 kg 130 mm 2.0 MT 4598 mm 1765 mm 1412 mm 2700 mm 1330 kg 1870 kg 130 mm 2.0 AT 4598 mm 1765 mm 1412 mm 2700 mm 1375 kg Not provided 130 mm
Estate 5-door — Peugeot 406 Dimensions
Estate 5-door Peugeot 406 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.8 MT 4736 mm 1765 mm 1502 mm 2700 mm 1365 kg 2015 kg 130 mm 1.8 MT 4736 mm 1765 mm 1502 mm 2700 mm 1300 kg 1950 kg 130 mm 2.0 MT 4736 mm 1765 mm 1502 mm 2700 mm 1420 kg 2050 kg 130 mm 2.0 MT 4736 mm 1765 mm 1502 mm 2700 mm 1400 kg 2050 kg 130 mm 2.2 MT 4736 mm 1765 mm 1502 mm 2700 mm 1500 kg 2070 kg 130 mm 3.0 AT 4736 mm 1765 mm 1502 mm 2700 mm 1580 kg 2115 kg 130 mm 3.0 MT 4736 mm 1765 mm 1502 mm 2700 mm 1505 kg 2155 kg 130 mm 2.0 MT 4736 mm 1765 mm 1502 mm 2700 mm 1460 kg 2075 kg 130 mm 2.0 AT 4736 mm 1765 mm 1502 mm 2700 mm 1435 kg 2075 kg 130 mm 2.2 MT 4736 mm 1765 mm 1502 mm 2700 mm 1460 kg 2110 kg 130 mm 1.8 AT 4736 mm 1765 mm 1502 mm 2700 mm 1370 kg 2015 kg 130 mm 2.0 AT 4736 mm 1765 mm 1502 mm 2700 mm 1401 kg 2050 kg 130 mm 2.0 MT 4736 mm 1765 mm 1502 mm 2700 mm 1360 kg 1890 kg 130 mm
Peugeot 406 Cargo Space
Coupe — Peugeot 406 Cargo Space
Sedan — Peugeot 406 Cargo Space
Estate 5-door — Peugeot 406 Cargo Space
