Opel Zafira Specs, Engines & Dimensions (2011–2016)

Opel Zafira Engines and Transmissions

You will find Opel Zafira engine options aimed at everyday family driving rather than outright pace. Selected examples include a 1.6 AT gasoline automatic, a 1.4 AT gasoline automatic, and a 1.6 MT LPG manual, all with front-wheel drive. Those powertrain and transmission pairings keep commuting straightforward.

Compact Van — Opel Zafira Engines and Transmissions

Compact Van Opel Zafira Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1364 cm³	140 hp	103 kW	200 N⋅m	Manual	FWD
1.6 AT	Gasoline	1598 cm³	170 hp	125 kW	280 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1796 cm³	140 hp	103 kW	175 N⋅m	Manual	FWD
1.4 MT	Gasoline	1364 cm³	120 hp	88 kW	175 N⋅m	Manual	FWD
1.6 MT	Gasoline	1598 cm³	170 hp	125 kW	260 N⋅m	Manual	FWD
1.6 MT	Gasoline	1598 cm³	200 hp	147 kW	300 N⋅m	Manual	FWD
1.8 MT	Gasoline	1796 cm³	115 hp	85 kW	175 N⋅m	Manual	FWD
2.0 AT	Diesel	1956 cm³	165 hp	120 kW	350 N⋅m	Automatic	FWD
1.6 MT	Diesel	1598 cm³	120 hp	88 kW	320 N⋅m	Manual	FWD
1.6 MT	Diesel	1598 cm³	136 hp	100 kW	320 N⋅m	Manual	FWD
2.0 MT	Diesel	1956 cm³	110 hp	81 kW	260 N⋅m	Manual	FWD
2.0 AT	Diesel	1956 cm³	130 hp	96 kW	300 N⋅m	Automatic	FWD
2.0 MT	Diesel	1956 cm³	130 hp	96 kW	300 N⋅m	Manual	FWD
2.0 MT	Diesel	1956 cm³	165 hp	121 kW	350 N⋅m	Manual	FWD
2.0 MT	Diesel	1956 cm³	170 hp	125 kW	400 N⋅m	Manual	FWD
2.0 AT	Diesel	1956 cm³	170 hp	125 kW	400 N⋅m	Automatic	FWD
2.0 MT	Diesel	1956 cm³	195 hp	143 kW	400 N⋅m	Manual	FWD
1.6 MT	LPG	1598 cm³	150 hp	110 kW	210 N⋅m	Manual	FWD
1.4 AT	Gasoline	1364 cm³	140 hp	103 kW	200 N⋅m	Automatic	FWD

Opel Zafira Dimensions

Compact Van — Opel Zafira Dimensions

Compact Van Opel Zafira Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
1.6 AT	4658 mm	1928 mm	1685 mm	2760 mm	1664 kg	2385 kg	165 mm
1.8 MT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
1.4 MT	4658 mm	1928 mm	1685 mm	2760 mm	1733 kg	2425 kg	165 mm
1.6 MT	4658 mm	1928 mm	1685 mm	2760 mm	Not provided	Not provided	165 mm
1.6 MT	4658 mm	1928 mm	1685 mm	2760 mm	Not provided	Not provided	165 mm
1.8 MT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
2.0 AT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
1.6 MT	4658 mm	1928 mm	1685 mm	2760 mm	Not provided	Not provided	165 mm
1.6 MT	4658 mm	1928 mm	1685 mm	2760 mm	Not provided	Not provided	165 mm
2.0 MT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
2.0 AT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
2.0 MT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
2.0 MT	4658 mm	1928 mm	1685 mm	2760 mm	1733 kg	2425 kg	165 mm
2.0 MT	4658 mm	1928 mm	1685 mm	2760 mm	1748 kg	2455 kg	165 mm
2.0 AT	4658 mm	1928 mm	1685 mm	2760 mm	1803 kg	2470 kg	165 mm
2.0 MT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm
1.6 MT	4658 mm	1928 mm	1685 mm	2760 mm	1733 kg	2425 kg	165 mm
1.4 AT	4658 mm	1928 mm	1685 mm	2760 mm	1571 kg	2150 kg	165 mm

Opel Zafira Cargo Space

Compact Van — Opel Zafira Cargo Space

Compact Van Opel Zafira Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	710 l	1860 l
1.6 AT	710 l	1860 l
1.8 MT	710 l	1860 l
1.4 MT	710 l	1860 l
1.6 MT	710 l	1860 l
1.6 MT	710 l	1860 l
1.8 MT	710 l	1860 l
2.0 AT	710 l	1860 l
1.6 MT	710 l	1860 l
1.6 MT	710 l	1860 l
2.0 MT	710 l	1860 l
2.0 AT	710 l	1860 l
2.0 MT	710 l	1860 l
2.0 MT	710 l	1860 l
2.0 MT	710 l	1860 l
2.0 AT	710 l	1860 l
2.0 MT	710 l	1860 l
1.6 MT	710 l	1860 l
1.4 AT	710 l	1860 l

Opel Zafira Trims and Equipment

Opel Zafira trim levels add equipment on top of a chosen technical version. On the 1.6 AT compact van with gasoline automatic and front-wheel drive, you can specify Business Edition. That package tilts cabin convenience toward work use without changing the drivetrain.

Opel Zafira Trims and Equipment
Modification	Body	Equipment
1.4 MT	Compact Van	Cosmo
1.4 MT	Compact Van	Enjoy
1.6 AT	Compact Van	Business Edition
1.4 AT	Compact Van	Enjoy
