Catalog / Opel / Zafira / 3 generation
Opel Zafira Engines and Transmissions
You will find Opel Zafira engine options aimed at everyday family driving rather than outright pace. Selected examples include a 1.6 AT gasoline automatic, a 1.4 AT gasoline automatic, and a 1.6 MT LPG manual, all with front-wheel drive. Those powertrain and transmission pairings keep commuting straightforward.
Compact Van — Opel Zafira Engines and Transmissions
Compact Van Opel Zafira Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.4 MT Gasoline 1364 cm³ 140 hp 103 kW 200 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 170 hp 125 kW 280 N⋅m Automatic FWD 1.8 MT Gasoline 1796 cm³ 140 hp 103 kW 175 N⋅m Manual FWD 1.4 MT Gasoline 1364 cm³ 120 hp 88 kW 175 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 170 hp 125 kW 260 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 200 hp 147 kW 300 N⋅m Manual FWD 1.8 MT Gasoline 1796 cm³ 115 hp 85 kW 175 N⋅m Manual FWD 2.0 AT Diesel 1956 cm³ 165 hp 120 kW 350 N⋅m Automatic FWD 1.6 MT Diesel 1598 cm³ 120 hp 88 kW 320 N⋅m Manual FWD 1.6 MT Diesel 1598 cm³ 136 hp 100 kW 320 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 110 hp 81 kW 260 N⋅m Manual FWD 2.0 AT Diesel 1956 cm³ 130 hp 96 kW 300 N⋅m Automatic FWD 2.0 MT Diesel 1956 cm³ 130 hp 96 kW 300 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 165 hp 121 kW 350 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Manual FWD 2.0 AT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Automatic FWD 2.0 MT Diesel 1956 cm³ 195 hp 143 kW 400 N⋅m Manual FWD 1.6 MT LPG 1598 cm³ 150 hp 110 kW 210 N⋅m Manual FWD 1.4 AT Gasoline 1364 cm³ 140 hp 103 kW 200 N⋅m Automatic FWD
Opel Zafira Dimensions
Compact Van — Opel Zafira Dimensions
Compact Van Opel Zafira Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.4 MT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 1.6 AT 4658 mm 1928 mm 1685 mm 2760 mm 1664 kg 2385 kg 165 mm 1.8 MT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 1.4 MT 4658 mm 1928 mm 1685 mm 2760 mm 1733 kg 2425 kg 165 mm 1.6 MT 4658 mm 1928 mm 1685 mm 2760 mm Not provided Not provided 165 mm 1.6 MT 4658 mm 1928 mm 1685 mm 2760 mm Not provided Not provided 165 mm 1.8 MT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 2.0 AT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 1.6 MT 4658 mm 1928 mm 1685 mm 2760 mm Not provided Not provided 165 mm 1.6 MT 4658 mm 1928 mm 1685 mm 2760 mm Not provided Not provided 165 mm 2.0 MT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 2.0 AT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 2.0 MT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 2.0 MT 4658 mm 1928 mm 1685 mm 2760 mm 1733 kg 2425 kg 165 mm 2.0 MT 4658 mm 1928 mm 1685 mm 2760 mm 1748 kg 2455 kg 165 mm 2.0 AT 4658 mm 1928 mm 1685 mm 2760 mm 1803 kg 2470 kg 165 mm 2.0 MT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm 1.6 MT 4658 mm 1928 mm 1685 mm 2760 mm 1733 kg 2425 kg 165 mm 1.4 AT 4658 mm 1928 mm 1685 mm 2760 mm 1571 kg 2150 kg 165 mm
Opel Zafira Cargo Space
Compact Van — Opel Zafira Cargo Space
Opel Zafira Trims and Equipment
Opel Zafira trim levels add equipment on top of a chosen technical version. On the 1.6 AT compact van with gasoline automatic and front-wheel drive, you can specify Business Edition. That package tilts cabin convenience toward work use without changing the drivetrain.
Opel Zafira Trims and Equipment Modification Body Equipment
1.4 MT Compact Van Cosmo 1.4 MT Compact Van Enjoy 1.6 AT Compact Van Business Edition 1.4 AT Compact Van Enjoy
