Opel Signum Specs, Engines & Dimensions (2003–2005)

Opel Signum Engines and Transmissions

Opel Signum engine choices include the gasoline 1.8 MT and 2.0 MT manuals and the diesel 1.9 AT automatic, all with front-wheel drive. These examples illustrate different everyday priorities: manuals let you choose when to change gear, while an automatic reduces effort in traffic. Diesel generally makes more sense for regular longer journeys.

Hatchback 5-door — Opel Signum Engines and Transmissions

Hatchback 5-door Opel Signum Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1796 cm³	122 hp	90 kW	167 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	175 hp	129 kW	265 N⋅m	Manual	FWD
2.2 MT	Gasoline	2198 cm³	155 hp	114 kW	220 N⋅m	Manual	FWD
2.2 AT	Gasoline	2198 cm³	155 hp	114 kW	220 N⋅m	Automatic	FWD
3.2 MT	Gasoline	3175 cm³	211 hp	155 kW	300 N⋅m	Manual	FWD
3.2 AT	Gasoline	3175 cm³	211 hp	155 kW	300 N⋅m	Automatic	FWD
1.9 MT	Diesel	1910 cm³	120 hp	88 kW	280 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	150 hp	110 kW	320 N⋅m	Manual	FWD
1.9 AT	Diesel	1910 cm³	150 hp	110 kW	320 N⋅m	Automatic	FWD
2.0 MT	Diesel	1994 cm³	100 hp	74 kW	230 N⋅m	Manual	FWD
2.2 MT	Diesel	2171 cm³	125 hp	92 kW	280 N⋅m	Manual	FWD
2.2 AT	Diesel	2171 cm³	125 hp	92 kW	280 N⋅m	Automatic	FWD
3.0 MT	Diesel	2958 cm³	177 hp	130 kW	370 N⋅m	Manual	FWD
3.0 AT	Diesel	2958 cm³	177 hp	130 kW	370 N⋅m	Automatic	FWD

Opel Signum Dimensions

Hatchback 5-door — Opel Signum Dimensions

Hatchback 5-door Opel Signum Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4636 mm	1798 mm	1468 mm	2830 mm	1405 kg	1995 kg	Not provided
2.0 MT	4636 mm	1798 mm	1468 mm	2830 mm	1485 kg	2075 kg	Not provided
2.2 MT	4636 mm	1798 mm	1468 mm	2830 mm	1460 kg	2050 kg	Not provided
2.2 AT	4636 mm	1798 mm	1468 mm	2830 mm	1460 kg	2050 kg	Not provided
3.2 MT	4636 mm	1798 mm	1468 mm	2830 mm	1535 kg	2125 kg	Not provided
3.2 AT	4636 mm	1798 mm	1468 mm	2830 mm	1565 kg	2150 kg	Not provided
1.9 MT	4636 mm	1798 mm	1468 mm	2830 mm	1615 kg	2110 kg	Not provided
1.9 MT	4636 mm	1798 mm	1468 mm	2830 mm	1636 kg	2110 kg	Not provided
1.9 AT	4636 mm	1798 mm	1468 mm	2830 mm	Not provided	2130 kg	130 mm
2.0 MT	4636 mm	1798 mm	1468 mm	2830 mm	1520 kg	2110 kg	Not provided
2.2 MT	4636 mm	1798 mm	1468 mm	2830 mm	1465 kg	2050 kg	Not provided
2.2 AT	4636 mm	1798 mm	1468 mm	2830 mm	1545 kg	2125 kg	Not provided
3.0 MT	4636 mm	1798 mm	1468 mm	2830 mm	1595 kg	2185 kg	Not provided
3.0 AT	4636 mm	1798 mm	1468 mm	2830 mm	1625 kg	2210 kg	Not provided

Opel Signum Cargo Space

Hatchback 5-door — Opel Signum Cargo Space

Hatchback 5-door Opel Signum Cargo Space
Modification	Trunk volume min	Trunk volume max
1.8 MT	365 l	1410 l
2.0 MT	365 l	1410 l
2.2 MT	365 l	1410 l
2.2 AT	365 l	1410 l
3.2 MT	365 l	1410 l
3.2 AT	365 l	1410 l
1.9 MT	365 l	1410 l
1.9 MT	365 l	1410 l
1.9 AT	365 l	1410 l
2.0 MT	365 l	1410 l
2.2 MT	365 l	1410 l
2.2 AT	365 l	1410 l
3.0 MT	365 l	1410 l
3.0 AT	365 l	1410 l
