Opel Insignia Specs, Engines & Dimensions (from 2020)

Opel Insignia Engines and Transmissions

You will find Opel Insignia engine choices here as diesel powertrains with front-wheel drive, suited to commuting. The 1.5d MT uses a manual gearbox, while 2.0d MT and 2.0d AT give you a manual or automatic transmission. These examples show the mix, not the full lineup.

Liftback — Opel Insignia Engines and Transmissions

Liftback Opel Insignia Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.5d MT	Diesel	1496 cm³	122 hp	89 kW	300 N⋅m	Manual	FWD
2.0d MT	Diesel	1955 cm³	174 hp	127 kW	380 N⋅m	Manual	FWD
2.0 Direct Injection Turbo AT	Gasoline	1998 cm³	200 hp	147 kW	350 N⋅m	Automatic	FWD
2.0d AT	Diesel	1955 cm³	174 hp	127 kW	380 N⋅m	Automatic	FWD
2.0 Direct Injection Turbo AT	Gasoline	1998 cm³	170 hp	125 kW	350 N⋅m	Automatic	FWD
1.5d AT	Diesel	1496 cm³	122 hp	89 kW	300 N⋅m	Automatic	FWD

Estate 5-door — Opel Insignia Engines and Transmissions

Estate 5-door Opel Insignia Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.5d MT	Diesel	1496 cm³	122 hp	89 kW	300 N⋅m	Manual	FWD
2.0d MT	Diesel	1955 cm³	174 hp	127 kW	380 N⋅m	Manual	FWD
2.0d AT	Diesel	1955 cm³	174 hp	127 kW	380 N⋅m	Automatic	FWD
2.0 Direct Injection Turbo AT	Gasoline	1998 cm³	200 hp	147 kW	350 N⋅m	Automatic	FWD
2.0 Direct Injection Turbo AT	Gasoline	1998 cm³	170 hp	125 kW	350 N⋅m	Automatic	FWD
1.5d AT	Diesel	1496 cm³	122 hp	89 kW	300 N⋅m	Automatic	FWD

Opel Insignia Dimensions

Liftback — Opel Insignia Dimensions

Liftback Opel Insignia Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.5d MT	4897 mm	1863 mm	1455 mm	2829 mm	Not provided	Not provided	160 mm
2.0d MT	4897 mm	1863 mm	1455 mm	2829 mm	Not provided	Not provided	160 mm
2.0 Direct Injection Turbo AT	4897 mm	1863 mm	1455 mm	2829 mm	Not provided	Not provided	160 mm
2.0d AT	4897 mm	1863 mm	1455 mm	2829 mm	Not provided	Not provided	160 mm
2.0 Direct Injection Turbo AT	4897 mm	1863 mm	1455 mm	2829 mm	Not provided	Not provided	160 mm
1.5d AT	4897 mm	1863 mm	1455 mm	2829 mm	1595 kg	2140 kg	160 mm

Estate 5-door — Opel Insignia Dimensions

Estate 5-door Opel Insignia Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.5d MT	4986 mm	1863 mm	1455 mm	2829 mm	1505 kg	2110 kg	160 mm
2.0d MT	4986 mm	1863 mm	1455 mm	2829 mm	1590 kg	2160 kg	160 mm
2.0d AT	4986 mm	1863 mm	1455 mm	2829 mm	1615 kg	2200 kg	160 mm
2.0 Direct Injection Turbo AT	4986 mm	1863 mm	1455 mm	2829 mm	1615 kg	2215 kg	160 mm
2.0 Direct Injection Turbo AT	4986 mm	1863 mm	1455 mm	2829 mm	1615 kg	2215 kg	160 mm
1.5d AT	4986 mm	1863 mm	1455 mm	2829 mm	1610 kg	2200 kg	160 mm

Opel Insignia Cargo Space

Liftback — Opel Insignia Cargo Space

Liftback Opel Insignia Cargo Space
Modification	Trunk volume min	Trunk volume max
1.5d MT	490 l	1450 l
2.0d MT	490 l	1450 l
2.0 Direct Injection Turbo AT	490 l	1450 l
2.0d AT	490 l	1450 l
2.0 Direct Injection Turbo AT	490 l	1450 l
1.5d AT	490 l	1450 l

Estate 5-door — Opel Insignia Cargo Space

Estate 5-door Opel Insignia Cargo Space
Modification	Trunk volume min	Trunk volume max
1.5d MT	560 l	1665 l
2.0d MT	560 l	1665 l
2.0d AT	560 l	1665 l
2.0 Direct Injection Turbo AT	560 l	1665 l
2.0 Direct Injection Turbo AT	560 l	1665 l
1.5d AT	560 l	1665 l

Opel Insignia Trims and Equipment

On the 1.5d MT Liftback, Opel Insignia trim levels include Business and Business Elegance. You pick those packs for cabin comfort and convenience while the diesel-manual, front-wheel-drive hardware stays the same. Treat equipment names as how that technical version is dressed, not as a different powertrain.

Opel Insignia Trims and Equipment
Modification	Body	Equipment
1.5d MT	Liftback	Business
1.5d MT	Liftback	Business Elegance
1.5d MT	Liftback	Business Edition
1.5d MT	Liftback	GS Line
1.5d MT	Liftback	Edition
1.5d MT	Liftback	Elegance
1.5d MT	Liftback	Ultimate
2.0d MT	Liftback	Business
2.0d MT	Liftback	Business Elegance
2.0d MT	Liftback	Business Edition
2.0d MT	Liftback	GS Line
2.0d MT	Liftback	Edition
2.0d MT	Liftback	Elegance
2.0d MT	Liftback	Ultimate
2.0d AT	Liftback	Business
2.0d AT	Liftback	Business Elegance
2.0d AT	Liftback	Business Edition
2.0d AT	Liftback	GS Line
2.0d AT	Liftback	Edition
2.0d AT	Liftback	Elegance
2.0d AT	Liftback	Ultimate
1.5d AT	Liftback	Business
1.5d AT	Liftback	Business Elegance
1.5d AT	Liftback	Business Edition
1.5d AT	Liftback	GS Line
1.5d AT	Liftback	Edition
1.5d AT	Liftback	Elegance
1.5d AT	Liftback	Ultimate
