Opel Insignia OPC Specs, Engines & Dimensions (2013–2017)

Opel Insignia OPC Engines and Transmissions

Examples of Opel Insignia OPC powertrain choices include gasoline 2.8 AT and 2.8 MT liftbacks, both with all-wheel drive, plus a 2.8 AT sedan. The automatic reduces shifting work in traffic, while the manual gives you direct control over gear selection. All-wheel drive helps put power down when accelerating on slippery surfaces.

Liftback — Opel Insignia OPC Engines and Transmissions

Liftback Opel Insignia OPC Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.8 AT	Gasoline	2792 cm³	325 hp	239 kW	435 N⋅m	Automatic	AWD
2.8 MT	Gasoline	2792 cm³	325 hp	239 kW	435 N⋅m	Manual	AWD

Sedan — Opel Insignia OPC Engines and Transmissions

Sedan Opel Insignia OPC Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.8 AT	Gasoline	2792 cm³	325 hp	239 kW	435 N⋅m	Automatic	AWD
2.8 MT	Gasoline	2792 cm³	325 hp	239 kW	435 N⋅m	Manual	AWD

Estate 5-door — Opel Insignia OPC Engines and Transmissions

Estate 5-door Opel Insignia OPC Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.8 AT	Gasoline	2792 cm³	325 hp	239 kW	435 N⋅m	Automatic	AWD
2.8 MT	Gasoline	2792 cm³	325 hp	239 kW	435 N⋅m	Manual	AWD

Opel Insignia OPC Dimensions

Liftback — Opel Insignia OPC Dimensions

Liftback Opel Insignia OPC Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.8 AT	4842 mm	1858 mm	1498 mm	2737 mm	1825 kg	2330 kg	160 mm
2.8 MT	4842 mm	1858 mm	1498 mm	2737 mm	1825 kg	2330 kg	160 mm

Sedan — Opel Insignia OPC Dimensions

Sedan Opel Insignia OPC Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.8 AT	4842 mm	1856 mm	1498 mm	2737 mm	1810 kg	2315 kg	160 mm
2.8 MT	4842 mm	1856 mm	1498 mm	2737 mm	1810 kg	2315 kg	160 mm

Estate 5-door — Opel Insignia OPC Dimensions

Estate 5-door Opel Insignia OPC Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.8 AT	4908 mm	1856 mm	1520 mm	2737 mm	1930 kg	2465 kg	160 mm
2.8 MT	4908 mm	1856 mm	1520 mm	2737 mm	1930 kg	2465 kg	160 mm

Opel Insignia OPC Cargo Space

Liftback — Opel Insignia OPC Cargo Space

Liftback Opel Insignia OPC Cargo Space
Modification	Trunk volume min	Trunk volume max
2.8 AT	530 l	1470 l
2.8 MT	530 l	1470 l

Sedan — Opel Insignia OPC Cargo Space

Sedan Opel Insignia OPC Cargo Space
Modification	Trunk volume min
2.8 AT	500 l
2.8 MT	500 l

Estate 5-door — Opel Insignia OPC Cargo Space

Estate 5-door Opel Insignia OPC Cargo Space
Modification	Trunk volume min	Trunk volume max
2.8 AT	540 l	1530 l
2.8 MT	540 l	1530 l

Opel Insignia OPC Trims and Equipment

For the 2.8 AT liftback, OPC names the equipment configuration, while 2.8 AT identifies the engine and transmission version. When choosing a car, check its fitted equipment for the seating, infotainment and parking features you need. These details help you judge how well it will suit everyday use.

Opel Insignia OPC Trims and Equipment
Modification	Body	Equipment
2.8 AT	Liftback	OPC
2.8 MT	Liftback	OPC
2.8 AT	Sedan	OPC
2.8 MT	Sedan	OPC
2.8 AT	Estate 5-door	OPC
2.8 MT	Estate 5-door	OPC
