Nissan Patrol Specs, Engines & Dimensions (2004–2010)

Nissan Patrol Engines and Transmissions

The Nissan Patrol engine in this restyling is a 3.0-litre diesel, offered in three-door and five-door SUVs. You choose the transmission: a manual 3.0 MT or an automatic 3.0 AT. Both examples use all-wheel drive, so the powertrain is built for towing, trails, and long highway runs.

SUV 3-doors — Nissan Patrol Engines and Transmissions

SUV 3-doors Nissan Patrol Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 MT	Diesel	2953 cm³	160 hp	117 kW	380 N⋅m	Manual	AWD
3.0 AT	Diesel	2953 cm³	160 hp	117 kW	380 N⋅m	Automatic	AWD

SUV 5-doors — Nissan Patrol Engines and Transmissions

SUV 5-doors Nissan Patrol Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 MT	Diesel	2953 cm³	160 hp	117 kW	380 N⋅m	Manual	AWD
3.0 AT	Diesel	2953 cm³	160 hp	117 kW	380 N⋅m	Automatic	AWD

Nissan Patrol Dimensions

SUV 3-doors — Nissan Patrol Dimensions

SUV 3-doors Nissan Patrol Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.0 MT	4475 mm	1840 mm	1840 mm	2400 mm	2300 kg	2850 kg	220 mm
3.0 AT	4475 mm	1840 mm	1840 mm	2400 mm	2335 kg	2850 kg	220 mm

SUV 5-doors — Nissan Patrol Dimensions

SUV 5-doors Nissan Patrol Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.0 MT	5045 mm	1840 mm	1855 mm	2970 mm	2440 kg	3200 kg	220 mm
3.0 AT	5045 mm	1840 mm	1855 mm	2970 mm	2485 kg	3110 kg	220 mm

Nissan Patrol Cargo Space

SUV 3-doors — Nissan Patrol Cargo Space

SUV 3-doors Nissan Patrol Cargo Space
Modification	Trunk volume min	Trunk volume max
3.0 MT	308 l	1652 l
3.0 AT	308 l	1652 l

SUV 5-doors — Nissan Patrol Cargo Space

SUV 5-doors Nissan Patrol Cargo Space
Modification	Trunk volume min	Trunk volume max
3.0 MT	183 l	2226 l
3.0 AT	183 l	2226 l
