Nissan Pathfinder Specs, Engines & Dimensions (1985–1995) — First Generation

The first-generation Nissan Pathfinder introduced a rugged, practical SUV with both three-door and five-door body styles. Its capable all-wheel-drive system and straightforward powertrains made it a versatile choice for families and adventurers.

← All Nissan models

Nissan Pathfinder Engines and Transmissions

The Nissan Pathfinder engine lineup offered a range of choices to suit different needs. A 2.4-liter gasoline unit paired with a manual transmission provided an efficient entry point, while a 3.0-liter gasoline engine with an automatic delivered stronger performance. For those prioritizing torque and towing, a 2.7-liter diesel automatic option was available.

SUV 5-doors — Nissan Pathfinder Engines and Transmissions

SUV 5-doors Nissan Pathfinder Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 MT	Gasoline	2389 cm³	103 hp	76 kW	182 N⋅m	Manual	AWD
2.4 AT	Gasoline	2389 cm³	103 hp	76 kW	182 N⋅m	Automatic	AWD
2.4 AT	Gasoline	2389 cm³	140 hp	103 kW	206 N⋅m	Automatic	AWD
2.4 MT	Gasoline	2389 cm³	140 hp	103 kW	206 N⋅m	Manual	AWD
3.0 AT	Gasoline	2960 cm³	140 hp	103 kW	226 N⋅m	Automatic	AWD
3.0 MT	Gasoline	2960 cm³	140 hp	103 kW	226 N⋅m	Manual	AWD
3.0 AT	Gasoline	2960 cm³	148 hp	109 kW	239 N⋅m	Automatic	AWD
3.0 MT	Gasoline	2960 cm³	148 hp	109 kW	239 N⋅m	Manual	AWD
3.0 AT	Gasoline	2960 cm³	153 hp	113 kW	247 N⋅m	Automatic	AWD
3.0 MT	Gasoline	2960 cm³	153 hp	113 kW	247 N⋅m	Manual	AWD
2.7 AT	Diesel	2663 cm³	85 hp	63 kW	177 N⋅m	Automatic	RWD
2.7 MT	Diesel	2663 cm³	85 hp	63 kW	177 N⋅m	Manual	RWD
2.7 AT	Diesel	2663 cm³	99 hp	73 kW	216 N⋅m	Automatic	AWD
2.7 MT	Diesel	2663 cm³	99 hp	73 kW	216 N⋅m	Manual	AWD
2.7 MT	Diesel	2663 cm³	100 hp	74 kW	221 N⋅m	Manual	RWD
2.7 AT	Diesel	2663 cm³	100 hp	74 kW	221 N⋅m	Automatic	RWD
2.7 AT	Diesel	2663 cm³	113 hp	83 kW	243 N⋅m	Automatic	AWD
2.7 MT	Diesel	2663 cm³	113 hp	83 kW	243 N⋅m	Manual	AWD

SUV 3-doors — Nissan Pathfinder Engines and Transmissions

SUV 3-doors Nissan Pathfinder Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 MT	Gasoline	2388 cm³	103 hp	76 kW	186 N⋅m	Manual	AWD
3.0 AT	Gasoline	2960 cm³	153 hp	114 kW	247 N⋅m	Automatic	AWD
3.0 MT	Gasoline	2960 cm³	153 hp	114 kW	247 N⋅m	Manual	AWD
2.7 AT	Diesel	2663 cm³	100 hp	74 kW	221 N⋅m	Automatic	AWD
2.7 MT	Diesel	2663 cm³	100 hp	74 kW	221 N⋅m	Manual	AWD

Nissan Pathfinder Dimensions

SUV 5-doors — Nissan Pathfinder Dimensions

SUV 5-doors Nissan Pathfinder Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 MT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.4 AT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.4 AT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.4 MT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
3.0 AT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
3.0 MT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
3.0 AT	4365 mm	1690 mm	1680 mm	2650 mm	1835 kg	2300 kg	210 mm
3.0 MT	4365 mm	1690 mm	1680 mm	2650 mm	1835 kg	2300 kg	210 mm
3.0 AT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
3.0 MT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.7 AT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.7 MT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.7 AT	4365 mm	1690 mm	1680 mm	2650 mm	1670 kg	2300 kg	210 mm
2.7 MT	4365 mm	1690 mm	1680 mm	2650 mm	1670 kg	2300 kg	210 mm
2.7 MT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.7 AT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.7 AT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm
2.7 MT	4365 mm	1690 mm	1680 mm	2650 mm	Not provided	Not provided	195 mm

SUV 3-doors — Nissan Pathfinder Dimensions

SUV 3-doors Nissan Pathfinder Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 MT	4365 mm	1690 mm	1680 mm	2650 mm	1540 kg	2250 kg	210 mm
3.0 AT	4365 mm	1690 mm	1680 mm	2650 mm	1835 kg	2300 kg	210 mm
3.0 MT	4365 mm	1690 mm	1680 mm	2650 mm	1835 kg	2300 kg	210 mm
2.7 AT	4365 mm	1690 mm	1680 mm	2650 mm	1670 kg	2300 kg	210 mm
2.7 MT	4365 mm	1690 mm	1680 mm	2650 mm	1670 kg	2300 kg	210 mm

Nissan Pathfinder Cargo Space

SUV 5-doors — Nissan Pathfinder Cargo Space

SUV 5-doors Nissan Pathfinder Cargo Space
Modification	Trunk volume min	Trunk volume max
2.4 MT	425 l	1550 l
2.4 AT	425 l	1550 l
2.4 AT	425 l	1550 l
2.4 MT	425 l	1550 l
3.0 AT	425 l	1550 l
3.0 MT	425 l	1550 l
3.0 AT	425 l	1550 l
3.0 MT	425 l	1550 l
3.0 AT	425 l	1550 l
3.0 MT	425 l	1550 l
2.7 AT	425 l	1550 l
2.7 MT	425 l	1550 l
2.7 AT	425 l	1550 l
2.7 MT	425 l	1550 l
2.7 MT	425 l	1550 l
2.7 AT	425 l	1550 l
2.7 AT	425 l	1550 l
2.7 MT	425 l	1550 l

SUV 3-doors — Nissan Pathfinder Cargo Space

SUV 3-doors Nissan Pathfinder Cargo Space
Modification	Trunk volume min	Trunk volume max
2.4 MT	425 l	1550 l
3.0 AT	425 l	1550 l
3.0 MT	425 l	1550 l
2.7 AT	425 l	1550 l
2.7 MT	425 l	1550 l
