Nissan AD Specs, Engines & Dimensions (1990–1996) — First Generation
The first-generation Nissan AD is a compact estate for everyday errands and light work. You choose an Estate 3-door or Estate 5-door wagon, with straightforward petrol and diesel setups for simple front-wheel-drive driving.
Nissan AD Engines and Transmissions Nissan AD Dimensions ← All Nissan models
Nissan AD Engines and Transmissions
Among selected examples, a Nissan AD engine is a 1.5-litre petrol in the Estate 3-door, with a manual or automatic gearbox and front-wheel drive. An Estate 5-door pairing uses a 1.7-litre diesel automatic. You get a calm drivetrain for commuting and light loads, not sporty performance.
Estate 3-door — Nissan AD Engines and Transmissions
Estate 3-door Nissan AD Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 MT Gasoline 1497 cm³ 94 hp 69 kW 126 N⋅m Manual FWD 1.5 AT Gasoline 1497 cm³ 94 hp 69 kW 126 N⋅m Automatic FWD
Estate 5-door — Nissan AD Engines and Transmissions
Estate 5-door Nissan AD Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 AT Gasoline 1275 cm³ 79 hp 58 kW 104 N⋅m Automatic FWD 1.3 MT Gasoline 1275 cm³ 79 hp 58 kW 104 N⋅m Manual FWD 1.5 MT Gasoline 1497 cm³ 94 hp 69 kW 126 N⋅m Manual FWD 1.5 MT Gasoline 1497 cm³ 94 hp 69 kW 126 N⋅m Manual AWD 1.5 AT Gasoline 1497 cm³ 94 hp 69 kW 126 N⋅m Automatic FWD 1.5 AT Gasoline 1497 cm³ 94 hp 69 kW 126 N⋅m Automatic AWD 1.5 MT Gasoline 1498 cm³ 105 hp 77 kW 135 N⋅m Manual FWD 1.5 MT Gasoline 1498 cm³ 105 hp 77 kW 135 N⋅m Manual AWD 1.5 AT Gasoline 1498 cm³ 105 hp 77 kW 135 N⋅m Automatic FWD 1.5 AT Gasoline 1498 cm³ 105 hp 77 kW 135 N⋅m Automatic AWD 1.7 MT Diesel 1680 cm³ 55 hp 40 kW 104 N⋅m Manual FWD 1.7 AT Diesel 1680 cm³ 55 hp 40 kW 104 N⋅m Automatic FWD 2.0 MT Diesel 1973 cm³ 76 hp 56 kW 132 N⋅m Manual FWD 2.0 AT Diesel 1973 cm³ 76 hp 56 kW 132 N⋅m Automatic FWD
Nissan AD Dimensions
Estate 3-door — Nissan AD Dimensions
Estate 3-door Nissan AD Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 1.5 MT 4270 mm 1680 mm 1810 mm 2470 mm 1090 kg 145 mm 1.5 AT 4270 mm 1680 mm 1810 mm 2470 mm Not provided 145 mm
Estate 5-door — Nissan AD Dimensions
Estate 5-door Nissan AD Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 1.3 AT 4175 mm 1665 mm 1480 mm 2400 mm 960 kg 140 mm 1.3 MT 4175 mm 1665 mm 1480 mm 2400 mm 960 kg 140 mm 1.5 MT 4175 mm 1665 mm 1480 mm 2400 mm 970 kg 140 mm 1.5 MT 4175 mm 1665 mm 1480 mm 2400 mm 1120 kg 150 mm 1.5 AT 4175 mm 1665 mm 1480 mm 2400 mm Not provided 140 mm 1.5 AT 4175 mm 1665 mm 1480 mm 2400 mm Not provided 150 mm 1.5 MT 4175 mm 1665 mm 1480 mm 2400 mm 1010 kg 140 mm 1.5 MT 4175 mm 1665 mm 1480 mm 2400 mm 1140 kg 140 mm 1.5 AT 4175 mm 1665 mm 1480 mm 2400 mm Not provided 140 mm 1.5 AT 4175 mm 1665 mm 1480 mm 2400 mm Not provided 140 mm 1.7 MT 4175 mm 1665 mm 1480 mm 2400 mm 1030 kg 140 mm 1.7 AT 4175 mm 1665 mm 1480 mm 2400 mm Not provided 140 mm 2.0 MT 4175 mm 1665 mm 1480 mm 2400 mm 1070 kg 140 mm 2.0 AT 4175 mm 1665 mm 1480 mm 2400 mm Not provided 140 mm
