Mitsuoka Ray Specs, Engines & Dimensions (1996–1999)

Mitsuoka Ray Engines and Transmissions

Every Mitsuoka Ray engine here is a small 0.7-litre gasoline unit sized for kei-class rules, so expect modest output, low running costs and easy city driving. Selected examples include a 0.7 AT with front-wheel drive and 0.7 MT versions in either front-wheel or all-wheel drive, the latter helping on snow and loose surfaces.

Mini 5-doors — Mitsuoka Ray Engines and Transmissions

Mini 5-doors Mitsuoka Ray Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
0.7 AT	Gasoline	657 cm³	52 hp	38 kW	56 N⋅m	Automatic	FWD
0.7 MT	Gasoline	657 cm³	52 hp	38 kW	56 N⋅m	Manual	FWD
0.7 MT	Gasoline	657 cm³	52 hp	38 kW	56 N⋅m	Manual	AWD
0.7 AT	Gasoline	657 cm³	55 hp	40 kW	60 N⋅m	Automatic	AWD

Mini 3-doors — Mitsuoka Ray Engines and Transmissions

Mini 3-doors Mitsuoka Ray Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
0.7 MT	Gasoline	657 cm³	52 hp	38 kW	56 N⋅m	Manual	FWD
0.7 AT	Gasoline	657 cm³	52 hp	38 kW	56 N⋅m	Automatic	FWD

Mitsuoka Ray Dimensions

Mini 5-doors — Mitsuoka Ray Dimensions

Mini 5-doors Mitsuoka Ray Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
0.7 AT	3350 mm	1395 mm	1420 mm	2335 mm	645 kg	150 mm
0.7 MT	3350 mm	1395 mm	1420 mm	2335 mm	635 kg	150 mm
0.7 MT	3350 mm	1395 mm	1420 mm	2335 mm	685 kg	150 mm
0.7 AT	3350 mm	1395 mm	1420 mm	2335 mm	695 kg	150 mm

Mini 3-doors — Mitsuoka Ray Dimensions

Mini 3-doors Mitsuoka Ray Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
0.7 MT	3350 mm	1395 mm	1420 mm	2335 mm	635 kg	160 mm
0.7 AT	3350 mm	1395 mm	1420 mm	2335 mm	Not provided	160 mm

Mitsuoka Ray Specs, Engines & Dimensions (1996–1999) — First Generation

Mitsuoka Ray

Mitsuoka Ray

Mitsuoka Ray

Mitsuoka Ray

Mitsuoka Ray

Mitsuoka Ray

Mitsuoka Ray Engines and Transmissions

Mini 5-doors — Mitsuoka Ray Engines and Transmissions

Mini 3-doors — Mitsuoka Ray Engines and Transmissions

Mitsuoka Ray Dimensions

Mini 5-doors — Mitsuoka Ray Dimensions

Mini 3-doors — Mitsuoka Ray Dimensions
