Catalog / MG / ZS UK / 1 generation
MG ZS UK Engines and Transmissions
The MG ZS UK engine range is built around straightforward petrol units paired with either a manual or continuously variable transmission. Front-wheel drive keeps the package simple and accessible for everyday use. The 1.8 MT provides direct manual control, while the 1.8 CVT suits those who prefer smoother, gear-free acceleration.
Sedan — MG ZS UK Engines and Transmissions
Sedan MG ZS UK Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 CVT Gasoline 1795 cm³ 117 hp 86 kW 160 N⋅m Variable FWD 1.8 MT Gasoline 1796 cm³ 117 hp 86 kW 160 N⋅m Manual FWD 2.5 MT Gasoline 2497 cm³ 177 hp 130 kW 240 N⋅m Manual FWD
Hatchback 5-door — MG ZS UK Engines and Transmissions
Hatchback 5-door MG ZS UK Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 CVT Gasoline 1795 cm³ 117 hp 86 kW 160 N⋅m Variable FWD 1.8 MT Gasoline 1796 cm³ 117 hp 86 kW 160 N⋅m Manual FWD 2.5 MT Gasoline 2497 cm³ 177 hp 130 kW 240 N⋅m Manual FWD 2.0 MT Diesel 1994 cm³ 101 hp 74 kW 240 N⋅m Manual FWD 2.0 MT Diesel 1994 cm³ 113 hp 83 kW 260 N⋅m Manual FWD
MG ZS UK Dimensions
Sedan — MG ZS UK Dimensions
Sedan MG ZS UK Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 CVT 4522 mm 1696 mm 1386 mm 2622 mm Not provided 1640 kg 150 mm 1.8 MT 4522 mm 1696 mm 1386 mm 2622 mm 1125 kg 1640 kg Not provided 2.5 MT 4522 mm 1696 mm 1386 mm 2622 mm 1235 kg 1720 kg Not provided
Hatchback 5-door — MG ZS UK Dimensions
Hatchback 5-door MG ZS UK Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 CVT 4377 mm 1696 mm 1386 mm 2622 mm Not provided 1640 kg 150 mm 1.8 MT 4377 mm 1696 mm 1386 mm 2622 mm 1130 kg 1640 kg Not provided 2.5 MT 4377 mm 1696 mm 1386 mm 2622 mm 1240 kg 1720 kg Not provided 2.0 MT 4377 mm 1696 mm 1386 mm 2622 mm 1230 kg 1720 kg 150 mm 2.0 MT 4377 mm 1696 mm 1386 mm 2622 mm 1230 kg 1720 kg 150 mm
MG ZS UK Cargo Space
Sedan — MG ZS UK Cargo Space
Sedan MG ZS UK Cargo Space Modification Trunk volume min Trunk volume max
1.8 CVT 470 l 810 l 1.8 MT 470 l 810 l 2.5 MT 470 l 810 l
Hatchback 5-door — MG ZS UK Cargo Space
Hatchback 5-door MG ZS UK Cargo Space Modification Trunk volume min Trunk volume max
1.8 CVT 370 l 720 l 1.8 MT 370 l 720 l 2.5 MT 370 l 720 l 2.0 MT 370 l 720 l 2.0 MT 370 l 720 l
