Mercedes S-Class Specs, Engines & Dimensions (2013–2018) — Sixth Generation

The sixth-generation Mercedes S-Class brings flagship luxury to sedan and open-top forms. Coupe and long-wheelbase Sedan variants add breadth, while advanced powertrains and refined trims define this generation.

← All Mercedes models

Mercedes S-Class Engines and Transmissions

The Mercedes S-Class engine range is anchored by the S500's 4.7-liter gasoline V8, delivering strong acceleration paired with a smooth automatic gearbox and rear-wheel drive. For efficiency-focused drivers, the S300h pairs a 2.1-liter hybrid with automatic shifting, while the S350d offers a torque-rich 3.0-liter diesel. Each powertrain balances performance and refinement to suit different journeys.

Cabrio — Mercedes S-Class Engines and Transmissions

Cabrio Mercedes S-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S500 4.7 AT	Gasoline	4663 cm³	455 hp	335 kW	700 N⋅m	Automatic	RWD

Coupe — Mercedes S-Class Engines and Transmissions

Coupe Mercedes S-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S400 3.0 AT	Gasoline	2996 cm³	367 hp	270 kW	500 N⋅m	Automatic	AWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	335 kW	700 N⋅m	Automatic	AWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	335 kW	700 N⋅m	Automatic	RWD

Sedan — Mercedes S-Class Engines and Transmissions

Sedan Mercedes S-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S350d 3.0 AT	Diesel	2987 cm³	249 hp	183 kW	620 N⋅m	Automatic	AWD
S350d 3.0 AT	Diesel	2987 cm³	252 hp	185 kW	620 N⋅m	Automatic	AWD
S300h 2.1 AT	Hybrid	2143 cm³	204 hp	150 kW	500 N⋅m	Automatic	RWD
S400h 3.5 AT	Hybrid	3498 cm³	299 hp	219 kW	392 N⋅m	Automatic	RWD
S350d 3.0 AT	Diesel	2987 cm³	258 hp	190 kW	620 N⋅m	Automatic	RWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	335 kW	700 N⋅m	Automatic	AWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	335 kW	700 N⋅m	Automatic	RWD
S500e 3.0 AT	Plug-in	2996 cm³	436 hp	320 kW	650 N⋅m	Automatic	RWD
S350d 3.0 AT	Diesel	2987 cm³	258 hp	190 kW	620 N⋅m	Automatic	AWD
S400 3.0 AT	Gasoline	2996 cm³	333 hp	245 kW	480 N⋅m	Automatic	AWD

Sedan Long — Mercedes S-Class Engines and Transmissions

Sedan Long Mercedes S-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S400 3.0 AT	Gasoline	2996 cm³	333 hp	245 kW	480 N⋅m	Automatic	RWD
S300d 2.1 AT	Hybrid	2143 cm³	204 hp	150 kW	500 N⋅m	Automatic	RWD
S400 3.0 AT	Hybrid	2996 cm³	333 hp	245 kW	650 N⋅m	Automatic	RWD
S350d 3.0 AT	Diesel	2987 cm³	249 hp	183 kW	620 N⋅m	Automatic	AWD
S350d 3.0 AT	Diesel	2987 cm³	258 hp	190 kW	620 N⋅m	Automatic	RWD
S350d 3.0 AT	Diesel	2987 cm³	258 hp	190 kW	620 N⋅m	Automatic	AWD
S400 3.0 AT	Gasoline	2996 cm³	333 hp	245 kW	480 N⋅m	Automatic	AWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	335 kW	700 N⋅m	Automatic	AWD
S600 6.0 AT	Gasoline	5980 cm³	530 hp	390 kW	830 N⋅m	Automatic	RWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	335 kW	700 N⋅m	Automatic	RWD
S400 3.5 AT	Hybrid	3498 cm³	299 hp	219 kW	392 N⋅m	Automatic	RWD
S500e 3.0 AT	Plug-in	2996 cm³	436 hp	320 kW	650 N⋅m	Automatic	RWD
S400 3.5 AT	Hybrid	3498 cm³	333 hp	244 kW	3370 N⋅m	Automatic	RWD

Mercedes S-Class Dimensions

Cabrio — Mercedes S-Class Dimensions

Cabrio Mercedes S-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
S500 4.7 AT	5027 mm	1899 mm	1417 mm	2945 mm	2115 kg	2590 kg	140 mm

Coupe — Mercedes S-Class Dimensions

Coupe Mercedes S-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
S400 3.0 AT	5027 mm	1899 mm	1411 mm	2945 mm	2035 kg	2540 kg	140 mm
S500 4.7 AT	5027 mm	1899 mm	1411 mm	2945 mm	2090 kg	2595 kg	140 mm
S500 4.7 AT	5027 mm	1899 mm	1411 mm	2945 mm	2030 kg	2585 kg	140 mm

Sedan — Mercedes S-Class Dimensions

Sedan Mercedes S-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
S350d 3.0 AT	5116 mm	1899 mm	1496 mm	3035 mm	2045 kg	2750 kg	130 mm
S350d 3.0 AT	5116 mm	1899 mm	1496 mm	3035 mm	2025 kg	2715 kg	130 mm
S300h 2.1 AT	5116 mm	1899 mm	1496 mm	3035 mm	2035 kg	2750 kg	130 mm
S400h 3.5 AT	5116 mm	1899 mm	1496 mm	3035 mm	1925 kg	2595 kg	130 mm
S350d 3.0 AT	5116 mm	1899 mm	1496 mm	3035 mm	1955 kg	2655 kg	130 mm
S500 4.7 AT	5116 mm	1899 mm	1496 mm	3035 mm	2070 kg	2750 kg	130 mm
S500 4.7 AT	5116 mm	1899 mm	1496 mm	3035 mm	1955 kg	2695 kg	130 mm
S500e 3.0 AT	5116 mm	1899 mm	1496 mm	3035 mm	1945 kg	2630 kg	130 mm
S350d 3.0 AT	5116 mm	1899 mm	1496 mm	3035 mm	1950 kg	2715 kg	130 mm
S400 3.0 AT	5116 mm	1899 mm	1496 mm	3035 mm	1920 kg	2665 kg	130 mm

Sedan Long — Mercedes S-Class Dimensions

Sedan Long Mercedes S-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
S400 3.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	1945 kg	2630 kg	130 mm
S300d 2.1 AT	5246 mm	1899 mm	1496 mm	3165 mm	2035 kg	2750 kg	130 mm
S400 3.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	2215 kg	2825 kg	130 mm
S350d 3.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	2045 kg	2750 kg	130 mm
S350d 3.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	1975 kg	2690 kg	130 mm
S350d 3.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	2045 kg	2750 kg	130 mm
S400 3.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	1970 kg	2650 kg	130 mm
S500 4.7 AT	5246 mm	1899 mm	1496 mm	3165 mm	2070 kg	2750 kg	130 mm
S600 6.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	2185 kg	2740 kg	130 mm
S500 4.7 AT	5246 mm	1899 mm	1496 mm	3165 mm	2015 kg	2730 kg	130 mm
S400 3.5 AT	5246 mm	1899 mm	1496 mm	3165 mm	1945 kg	2630 kg	130 mm
S500e 3.0 AT	5246 mm	1899 mm	1496 mm	3165 mm	1945 kg	2630 kg	130 mm
S400 3.5 AT	5246 mm	1899 mm	1496 mm	3165 mm	1925 kg	2595 kg	130 mm

Mercedes S-Class Cargo Space

Cabrio — Mercedes S-Class Cargo Space

Cabrio Mercedes S-Class Cargo Space
Modification	Trunk volume min
S500 4.7 AT	350 l

Coupe — Mercedes S-Class Cargo Space

Coupe Mercedes S-Class Cargo Space
Modification	Trunk volume min
S400 3.0 AT	400 l
S500 4.7 AT	400 l
S500 4.7 AT	400 l

Sedan — Mercedes S-Class Cargo Space

Sedan Mercedes S-Class Cargo Space
Modification	Trunk volume min
S350d 3.0 AT	510 l
S350d 3.0 AT	510 l
S300h 2.1 AT	510 l
S400h 3.5 AT	510 l
S350d 3.0 AT	510 l
S500 4.7 AT	510 l
S500 4.7 AT	510 l
S500e 3.0 AT	510 l
S350d 3.0 AT	510 l
S400 3.0 AT	510 l

Sedan Long — Mercedes S-Class Cargo Space

Sedan Long Mercedes S-Class Cargo Space
Modification	Trunk volume min
S400 3.0 AT	510 l
S300d 2.1 AT	510 l
S400 3.0 AT	510 l
S350d 3.0 AT	510 l
S350d 3.0 AT	510 l
S350d 3.0 AT	510 l
S400 3.0 AT	510 l
S500 4.7 AT	510 l
S600 6.0 AT	510 l
S500 4.7 AT	510 l
S400 3.5 AT	510 l
S500e 3.0 AT	510 l
S400 3.5 AT	510 l

Mercedes S-Class Trims and Equipment

Mercedes S-Class trim levels tailor the experience to individual tastes. The S500 cabriolet can be specified with the standard S500 configuration, offering comprehensive luxury, or the Vision Cabrio trim, which adds unique styling and exclusive features. These equipment lines allow buyers to personalize comfort, technology, and design elements without altering the core driving character.

Mercedes S-Class Trims and Equipment
Modification	Body	Equipment
S500 4.7 AT	Cabrio	S500
S500 4.7 AT	Cabrio	Vision Cabrio
S500 4.7 AT	Cabrio	AMG Cabrio
S400 3.0 AT	Coupe	S400 4Matic
S400 3.0 AT	Coupe	Vision
S500 4.7 AT	Coupe	S500 4Matic
S500 4.7 AT	Coupe	Vision
S500 4.7 AT	Coupe	Vision
S500 4.7 AT	Coupe	AMG
S400h 3.5 AT	Sedan	Vision
S350d 3.0 AT	Sedan	Vision
S500 4.7 AT	Sedan	Vision
S400 3.0 AT	Sedan Long	Vision
S400 3.0 AT	Sedan Long	S500 4Matic
S350d 3.0 AT	Sedan Long	S500 4Matic
S350d 3.0 AT	Sedan Long	Vision
S400 3.0 AT	Sedan Long	S500 4Matic
S500 4.7 AT	Sedan Long	S500 4Matic
S600 6.0 AT	Sedan Long	Vision
S600 6.0 AT	Sedan Long	S600
S500 4.7 AT	Sedan Long	Vision
S400 3.5 AT	Sedan Long	Vision
S400 3.5 AT	Sedan Long	S500 4Matic
S400 3.5 AT	Sedan Long	Vision
