Mercedes Maybach S-Class Specs, Engines & Dimensions (2017–2020)

Mercedes Maybach S-Class Engines and Transmissions

The Mercedes Maybach S-Class engine lineup spans a range of outputs to suit different needs. For example, the S450 3.0 AT 4Matic in Sedan Long pairs a 3.0-liter engine with all-wheel drive for confident traction, while the S650 6.0 AT offers a larger 6.0-liter unit with rear-wheel drive in both Limousine and Cabrio forms. Each pairs with an automatic transmission, delivering smooth, effortless acceleration.

Limousine — Mercedes Maybach S-Class Engines and Transmissions

Limousine Mercedes Maybach S-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S650 6.0 AT	Gasoline	5980 cm³	630 hp	463 kW	1000 N⋅m	Automatic	RWD

Cabrio — Mercedes Maybach S-Class Engines and Transmissions

Cabrio Mercedes Maybach S-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S650 6.0 AT	Gasoline	5980 cm³	630 hp	463 kW	1000 N⋅m	Automatic	RWD

Sedan Long — Mercedes Maybach S-Class Engines and Transmissions

Sedan Long Mercedes Maybach S-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S450 3.0 AT 4Matic	Gasoline	2996 cm³	367 hp	270 kW	500 N⋅m	Automatic	AWD
S600 6.0 AT	Gasoline	5980 cm³	530 hp	390 kW	830 N⋅m	Automatic	RWD
S560 4.0 AT	Gasoline	3982 cm³	469 hp	344 kW	700 N⋅m	Automatic	RWD
S560 4.0 AT 4Matic	Gasoline	3982 cm³	469 hp	345 kW	700 N⋅m	Automatic	AWD
S650 6.0 AT	Gasoline	5980 cm³	630 hp	463 kW	1000 N⋅m	Automatic	RWD

Mercedes Maybach S-Class Dimensions

Limousine — Mercedes Maybach S-Class Dimensions

Limousine Mercedes Maybach S-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
S650 6.0 AT	6499 mm	1930 mm	1598 mm	4418 mm	3070 kg	3600 kg	131 mm

Cabrio — Mercedes Maybach S-Class Dimensions

Cabrio Mercedes Maybach S-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight
S650 6.0 AT	5027 mm	1899 mm	1417 mm	2945 mm	2300 kg

Sedan Long — Mercedes Maybach S-Class Dimensions

Sedan Long Mercedes Maybach S-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
S450 3.0 AT 4Matic	5462 mm	1899 mm	1498 mm	3365 mm	2255 kg	Not provided	Not provided
S600 6.0 AT	5462 mm	1899 mm	1498 mm	3365 mm	2335 kg	2815 kg	131 mm
S560 4.0 AT	5462 mm	1899 mm	1498 mm	3365 mm	2250 kg	2815 kg	131 mm
S560 4.0 AT 4Matic	5462 mm	1899 mm	1498 mm	3365 mm	2295 kg	2815 kg	131 mm
S650 6.0 AT	5462 mm	1899 mm	1498 mm	3365 mm	2285 kg	2820 kg	131 mm

Mercedes Maybach S-Class Cargo Space

Limousine — Mercedes Maybach S-Class Cargo Space

Limousine Mercedes Maybach S-Class Cargo Space
Modification	Trunk volume min
S650 6.0 AT	361 l

Cabrio — Mercedes Maybach S-Class Cargo Space

Cabrio Mercedes Maybach S-Class Cargo Space
Modification	Trunk volume min
S650 6.0 AT	350 l

Sedan Long — Mercedes Maybach S-Class Cargo Space

Sedan Long Mercedes Maybach S-Class Cargo Space
Modification	Trunk volume min
S450 3.0 AT 4Matic	500 l
S600 6.0 AT	500 l
S560 4.0 AT	500 l
S560 4.0 AT 4Matic	500 l
S650 6.0 AT	500 l

Mercedes Maybach S-Class Trims and Equipment

Mercedes Maybach S-Class trim levels are tailored to specific configurations. The S560 4.0 AT 4Matic Sedan Long, for instance, is offered with equipment packages named S560 4Matic and Ultimate. These trims build on the core luxury features, adding distinctive touches that enhance comfort and presence, reflecting the model's emphasis on personalization.

Mercedes Maybach S-Class Trims and Equipment
Modification	Body	Equipment
S450 3.0 AT 4Matic	Sedan Long	S560 4Matic
S600 6.0 AT	Sedan Long	S600 Guard
S560 4.0 AT 4Matic	Sedan Long	S560 4Matic
S560 4.0 AT 4Matic	Sedan Long	Ultimate
S650 6.0 AT	Sedan Long	Ultimate

Mercedes Maybach S-Class Specs, Engines & Dimensions (2017–2020) — First Generation Restyling
