Catalog / Mercedes / G-Class / 2 generation, restyling 2
Mercedes G-Class Engines and Transmissions
The Mercedes G-Class engine lineup in this generation includes efficient diesel and powerful gasoline options. For example, a 3.0-liter diesel with automatic transmission and all-wheel drive suits long-distance cruising and off-road torque, while a 5.5-liter gasoline V8 delivers strong acceleration and smooth highway performance. All engines pair with an automatic gearbox and permanent all-wheel drive, making the G-Class capable in any condition.
SUV cabriolet — Mercedes G-Class Engines and Transmissions
SUV cabriolet Mercedes G-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
3.0 AT Diesel 2987 cm³ 224 hp 165 kW 540 N⋅m Automatic AWD 5.5 AT Gasoline 5461 cm³ 388 hp 285 kW 530 N⋅m Automatic AWD
SUV 5-doors — Mercedes G-Class Engines and Transmissions
SUV 5-doors Mercedes G-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
3.0 AT Diesel 2987 cm³ 224 hp 165 kW 540 N⋅m Automatic AWD 3.0 AT Diesel 2987 cm³ 183 hp 135 kW 400 N⋅m Automatic AWD 3.0 AT Diesel 2987 cm³ 211 hp 155 kW 540 N⋅m Automatic AWD 5.5 AT Gasoline 5461 cm³ 388 hp 285 kW 530 N⋅m Automatic AWD
SUV 3-doors — Mercedes G-Class Engines and Transmissions
SUV 3-doors Mercedes G-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
5.5 AT Gasoline 5461 cm³ 388 hp 285 kW 530 N⋅m Automatic AWD 3.0 AT Diesel 2987 cm³ 224 hp 165 kW 540 N⋅m Automatic AWD
Mercedes G-Class Dimensions
SUV cabriolet — Mercedes G-Class Dimensions
SUV cabriolet Mercedes G-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
3.0 AT 4257 mm 1760 mm 1941 mm 2400 mm 2260 kg 2850 kg 217 mm 5.5 AT 4257 mm 1760 mm 1941 mm 2400 mm 2230 kg 2850 kg 217 mm
SUV 5-doors — Mercedes G-Class Dimensions
SUV 5-doors Mercedes G-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
3.0 AT 4662 mm 1760 mm 1931 mm 2850 mm 2445 kg 3200 kg 217 mm 3.0 AT 4662 mm 1760 mm 1931 mm 2850 mm 2585 kg 3560 kg 217 mm 3.0 AT 4662 mm 1760 mm 1931 mm 2850 mm 2345 kg 3200 kg 220 mm 5.5 AT 4662 mm 1760 mm 1931 mm 2850 mm 2380 kg 3200 kg 217 mm
SUV 3-doors — Mercedes G-Class Dimensions
SUV 3-doors Mercedes G-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
5.5 AT 4212 mm 1760 mm 1931 mm 2400 mm 2245 kg 2850 kg 217 mm 3.0 AT 4212 mm 1760 mm 1931 mm 2400 mm 2275 kg 2850 kg 217 mm
Mercedes G-Class Cargo Space
SUV cabriolet — Mercedes G-Class Cargo Space
SUV cabriolet Mercedes G-Class Cargo Space Modification Trunk volume min Trunk volume max
3.0 AT 250 l 1580 l 5.5 AT 250 l 1580 l
SUV 5-doors — Mercedes G-Class Cargo Space
SUV 5-doors Mercedes G-Class Cargo Space Modification Trunk volume min Trunk volume max
3.0 AT 480 l 2250 l 3.0 AT 480 l 2250 l 3.0 AT 480 l 2250 l 5.5 AT 480 l 2250 l
SUV 3-doors — Mercedes G-Class Cargo Space
SUV 3-doors Mercedes G-Class Cargo Space Modification Trunk volume min Trunk volume max
5.5 AT 250 l 1580 l 3.0 AT 250 l 1580 l
Mercedes G-Class Trims and Equipment
Mercedes G-Class trim levels add luxury and technology to the rugged base. The G 350 CDI configuration, for instance, includes premium interior materials, advanced infotainment, and driver assistance systems. Even with a focus on comfort, the trims preserve practical features like durable upholstery and off-road driving modes, so the vehicle remains a true G-Class.
Mercedes G-Class Trims and Equipment Modification Body Equipment
3.0 AT SUV cabriolet G 350 CDI 3.0 AT SUV cabriolet G 350 CDI 5.5 AT SUV cabriolet G 500 5.5 AT SUV cabriolet G 500 3.0 AT SUV 5-doors G 350 CDI 5.5 AT SUV 3-doors G 500 3.0 AT SUV 3-doors G 350 CDI
