Catalog / Mercedes / A-Class / 4 generation, restyling
Mercedes A-Class Engines and Transmissions
The Mercedes A-Class engine range spans small turbocharged petrol units, diesels and a plug-in hybrid. The A180 1.3 DCT combines a gasoline engine with a dual-clutch robotic transmission and front-wheel drive, while the A180d 2.0 DCT trades revs for diesel torque and relaxed motorway cruising. The A250e 1.3 AT PHEV adds electric assistance to that powertrain.
Sedan — Mercedes A-Class Engines and Transmissions
Sedan Mercedes A-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
A180 1.3 DCT Gasoline 1332 cm³ 136 hp 100 kW 230 N⋅m Robotic FWD A200 1.3 DCT Gasoline 1332 cm³ 163 hp 119 kW 275 N⋅m Robotic FWD A220 2.0 DCT Gasoline 1991 cm³ 190 hp 139 kW 300 N⋅m Robotic AWD A250 2.0 DCT Gasoline 1991 cm³ 224 hp 164 kW 350 N⋅m Robotic AWD A180d 2.0 DCT Diesel 1950 cm³ 116 hp 85 kW 280 N⋅m Robotic FWD A200d 2.0 DCT Diesel 1950 cm³ 150 hp 110 kW 320 N⋅m Robotic FWD A220d 2.0 DCT Diesel 1950 cm³ 190 hp 139 kW 400 N⋅m Robotic FWD A250e 1.3 AT PHEV Plug-in 1332 cm³ 218 hp 160 kW 270 N⋅m Robotic FWD
Hatchback 5-door — Mercedes A-Class Engines and Transmissions
Hatchback 5-door Mercedes A-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
A200 1.3 DCT Gasoline 1332 cm³ 163 hp 119 kW 270 N⋅m Robotic FWD A220 2.0 DCT Gasoline 1991 cm³ 190 hp 139 kW 300 N⋅m Robotic AWD A250 2.0 DCT Gasoline 1991 cm³ 224 hp 164 kW 350 N⋅m Robotic AWD A200d 2.0 DCT Diesel 1950 cm³ 150 hp 110 kW 320 N⋅m Robotic FWD A220d 2.0 DCT Diesel 1950 cm³ 190 hp 139 kW 400 N⋅m Robotic FWD A250e 1.3 AT PHEV Plug-in 1332 cm³ 218 hp 160 kW 270 N⋅m Robotic FWD A180 1.3 DCT Gasoline 1332 cm³ 136 hp 100 kW 230 N⋅m Robotic FWD A180d 2.0 DCT Diesel 1950 cm³ 116 hp 85 kW 280 N⋅m Robotic FWD
Mercedes A-Class Dimensions
Sedan — Mercedes A-Class Dimensions
Sedan Mercedes A-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
A180 1.3 DCT 4549 mm 1796 mm 1446 mm 2729 mm 1290 kg 1890 kg 104 mm A200 1.3 DCT 4549 mm 1796 mm 1446 mm 2729 mm 1385 kg 1915 kg 104 mm A220 2.0 DCT 4549 mm 1796 mm 1446 mm 2729 mm 1520 kg 2050 kg 104 mm A250 2.0 DCT 4549 mm 1796 mm 1446 mm 2729 mm 1525 kg 2055 kg 104 mm A180d 2.0 DCT 4549 mm 1796 mm 1446 mm 2729 mm 1455 kg 1965 kg 104 mm A200d 2.0 DCT 4549 mm 1796 mm 1446 mm 2729 mm 1520 kg 2100 kg 104 mm A220d 2.0 DCT 4549 mm 1796 mm 1446 mm 2729 mm 1455 kg 1965 kg 104 mm A250e 1.3 AT PHEV 4549 mm 1796 mm 1446 mm 2729 mm 1700 kg 2175 kg 104 mm
Hatchback 5-door — Mercedes A-Class Dimensions
Hatchback 5-door Mercedes A-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
A200 1.3 DCT 4419 mm 1796 mm 1452 mm 2729 mm 1385 kg 1915 kg 104 mm A220 2.0 DCT 4419 mm 1796 mm 1452 mm 2729 mm 1520 kg 2050 kg 104 mm A250 2.0 DCT 4419 mm 1796 mm 1452 mm 2729 mm 1525 kg 2055 kg 104 mm A200d 2.0 DCT 4419 mm 1796 mm 1452 mm 2729 mm 1520 kg 2100 kg 104 mm A220d 2.0 DCT 4419 mm 1796 mm 1452 mm 2729 mm 1455 kg 1965 kg 104 mm A250e 1.3 AT PHEV 4419 mm 1796 mm 1452 mm 2729 mm 1700 kg 2170 kg 104 mm A180 1.3 DCT 4419 mm 1796 mm 1452 mm 2729 mm 1440 kg 1920 kg 104 mm A180d 2.0 DCT 4419 mm 1796 mm 1452 mm 2729 mm 1455 kg 1965 kg 104 mm
Mercedes A-Class Cargo Space
Sedan — Mercedes A-Class Cargo Space
Hatchback 5-door — Mercedes A-Class Cargo Space
Mercedes A-Class Trims and Equipment
Equipment configurations sit on top of a technical version rather than altering it. The A250e 1.3 AT PHEV Hatchback 5-door, for example, appears as Premium and Platinum: identical hybrid mechanicals, different levels of comfort, trim materials and convenience features. Because Mercedes A-Class trim levels vary by market and build year, always read the individual car's equipment list.
Mercedes A-Class Battery, Range, Charging
Mercedes A-Class battery capacity matters most in the A250e, where a lithium-ion pack covers short electric-only journeys such as commutes and school runs before the petrol engine steps in. Charging overnight at home keeps most daily driving electric; on longer trips the car simply behaves like an efficient hybrid.
Sedan — Mercedes A-Class Battery, Range, Charging
Sedan Mercedes A-Class Battery, Range, Charging Modification Battery power Battery type Driving range, maximum Full charge home Full public charging time
A250e 1.3 AT PHEV 15.6 kWh Lithium-ion batterie 82 km 330 min 25 min
Hatchback 5-door — Mercedes A-Class Battery, Range, Charging
Hatchback 5-door Mercedes A-Class Battery, Range, Charging Modification Battery power Battery type Driving range, maximum Full charge home Full public charging time
A250e 1.3 AT PHEV 15.6 kWh Lithium-ion batterie 70 km 330 min 25 min
