Catalog / Mazda / Protege / 3 generation
Mazda Protege Engines and Transmissions
The Mazda Protege engine lineup focuses on small, fuel-efficient gasoline units. A 1.3-liter four-cylinder is available with either a manual or automatic transmission, giving buyers a choice between direct control and relaxed daily driving. For more responsive performance, a larger 1.5-liter engine pairs with a manual gearbox. All configurations drive the front wheels, a typical setup for this class that offers predictable handling and good traction in most conditions.
Sedan — Mazda Protege Engines and Transmissions
Sedan Mazda Protege Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 MT Gasoline 1323 cm³ 85 hp 63 kW 110 N⋅m Manual FWD 1.3 AT Gasoline 1323 cm³ 85 hp 63 kW 110 N⋅m Automatic FWD 1.5 MT Gasoline 1498 cm³ 110 hp 81 kW 137 N⋅m Manual FWD 1.5 AT Gasoline 1498 cm³ 110 hp 81 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1598 cm³ 98 hp 72 kW 145 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 98 hp 72 kW 145 N⋅m Automatic FWD 1.6 MT Gasoline 1598 cm³ 106 hp 78 kW 145 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 106 hp 78 kW 145 N⋅m Automatic FWD 1.8 AT Gasoline 1839 cm³ 114 hp 84 kW 157 N⋅m Automatic FWD 1.8 MT Gasoline 1839 cm³ 114 hp 84 kW 157 N⋅m Manual FWD 2.0 MT Gasoline 1991 cm³ 130 hp 96 kW 183 N⋅m Manual FWD 2.0 AT Gasoline 1991 cm³ 130 hp 96 kW 183 N⋅m Automatic FWD
Hatchback 5-door — Mazda Protege Engines and Transmissions
Hatchback 5-door Mazda Protege Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 MT Gasoline 1498 cm³ 113 hp 83 kW 140 N⋅m Manual FWD 1.5 AT Gasoline 1498 cm³ 113 hp 83 kW 140 N⋅m Automatic FWD 1.9 MT Gasoline 1845 cm³ 135 hp 99 kW 157 N⋅m Manual FWD 1.9 AT Gasoline 1845 cm³ 135 hp 99 kW 157 N⋅m Automatic FWD 2.0 AT Gasoline 1989 cm³ 130 hp 96 kW 183 N⋅m Automatic FWD 2.0 MT Gasoline 1989 cm³ 130 hp 96 kW 183 N⋅m Manual FWD 2.0 MT Gasoline 1991 cm³ 165 hp 121 kW 178 N⋅m Manual FWD 2.0 AT Gasoline 1991 cm³ 165 hp 121 kW 178 N⋅m Automatic FWD
Mazda Protege Dimensions
Sedan — Mazda Protege Dimensions
Sedan Mazda Protege Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.3 MT 4315 mm 1695 mm 1410 mm 2610 mm 1020 kg Not provided 140 mm 1.3 AT 4315 mm 1695 mm 1410 mm 2610 mm Not provided Not provided 140 mm 1.5 MT 4315 mm 1695 mm 1410 mm 2610 mm 1020 kg Not provided 140 mm 1.5 AT 4315 mm 1695 mm 1410 mm 2610 mm Not provided Not provided 140 mm 1.6 MT 4315 mm 1695 mm 1410 mm 2610 mm 1170 kg 1625 kg 150 mm 1.6 AT 4315 mm 1695 mm 1410 mm 2610 mm 1125 kg 1655 kg 150 mm 1.6 MT 4315 mm 1695 mm 1410 mm 2610 mm 1104 kg Not provided 150 mm 1.6 AT 4315 mm 1695 mm 1410 mm 2610 mm 1115 kg Not provided 150 mm 1.8 AT 4315 mm 1695 mm 1410 mm 2610 mm Not provided Not provided 140 mm 1.8 MT 4315 mm 1695 mm 1410 mm 2610 mm Not provided Not provided 140 mm 2.0 MT 4315 mm 1695 mm 1410 mm 2610 mm 1195 kg Not provided 140 mm 2.0 AT 4315 mm 1695 mm 1410 mm 2610 mm Not provided Not provided 140 mm
Hatchback 5-door — Mazda Protege Dimensions
Hatchback 5-door Mazda Protege Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.5 MT 4200 mm 1695 mm 1420 mm 2610 mm Not provided 1170 kg 140 mm 1.5 AT 4200 mm 1695 mm 1420 mm 2610 mm Not provided 1170 kg 140 mm 1.9 MT 4200 mm 1695 mm 1420 mm 2610 mm Not provided 1170 kg 140 mm 1.9 AT 4200 mm 1695 mm 1420 mm 2610 mm Not provided 1170 kg 140 mm 2.0 AT 4200 mm 1695 mm 1420 mm 2610 mm 1247 kg Not provided 140 mm 2.0 MT 4200 mm 1695 mm 1420 mm 2610 mm 1247 kg Not provided 140 mm 2.0 MT 4200 mm 1695 mm 1420 mm 2610 mm Not provided 1170 kg 140 mm 2.0 AT 4200 mm 1695 mm 1420 mm 2610 mm Not provided 1170 kg 140 mm
Mazda Protege Cargo Space
Sedan — Mazda Protege Cargo Space
