Mazda Lantis Specs, Engines & Dimensions (1993–1997)

Mazda Lantis Engines and Transmissions

A Mazda Lantis engine in this generation is gasoline, with a front-wheel-drive drivetrain. Sedan examples include the 1.8 AT, 1.8 MT and 2.0 AT. You can pair the smaller engine with automatic or manual transmission, or take the larger automatic; those powertrain choices are examples, not the complete lineup.

Sedan — Mazda Lantis Engines and Transmissions

Sedan Mazda Lantis Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 AT	Gasoline	1840 cm³	131 hp	96 kW	152 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1840 cm³	131 hp	96 kW	152 N⋅m	Manual	FWD
2.0 AT	Gasoline	1995 cm³	170 hp	125 kW	180 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1995 cm³	170 hp	125 kW	180 N⋅m	Manual	FWD

Hatchback 5-door — Mazda Lantis Engines and Transmissions

Hatchback 5-door Mazda Lantis Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1839 cm³	131 hp	96 kW	152 N⋅m	Manual	FWD
1.8 AT	Gasoline	1839 cm³	131 hp	96 kW	152 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1995 cm³	170 hp	125 kW	179 N⋅m	Manual	FWD
2.0 AT	Gasoline	1995 cm³	170 hp	125 kW	179 N⋅m	Automatic	FWD

Mazda Lantis Dimensions

Sedan — Mazda Lantis Dimensions

Sedan Mazda Lantis Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 AT	4490 mm	1695 mm	1355 mm	2605 mm	Not provided	Not provided	150 mm
1.8 MT	4490 mm	1695 mm	1355 mm	2605 mm	1160 kg	1610 kg	150 mm
2.0 AT	4490 mm	1695 mm	1355 mm	2605 mm	Not provided	Not provided	150 mm
2.0 MT	4490 mm	1695 mm	1355 mm	2605 mm	1200 kg	1650 kg	150 mm

Hatchback 5-door — Mazda Lantis Dimensions

Hatchback 5-door Mazda Lantis Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
1.8 MT	4245 mm	1695 mm	1320 mm	2605 mm	1170 kg	150 mm
1.8 AT	4245 mm	1695 mm	1320 mm	2605 mm	1180 kg	150 mm
2.0 MT	4245 mm	1695 mm	1320 mm	2605 mm	1200 kg	150 mm
2.0 AT	4245 mm	1695 mm	1320 mm	2605 mm	1240 kg	150 mm
