Mazda CX-5 Specs, Engines & Dimensions

Mazda CX-5 Engines and Transmissions

This generation’s Mazda CX-5 engine range includes a 2.0 gasoline with a manual gearbox and front-wheel drive, along with 2.0 diesels paired to automatics—one with all-wheel drive and one front-wheel drive. These options balance efficiency, response and everyday usability.

SUV 5-doors — Mazda CX-5 Engines and Transmissions

SUV 5-doors Mazda CX-5 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 AT	Gasoline	1998 cm³	150 hp	110 kW	210 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	150 hp	110 kW	210 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1998 cm³	150 hp	110 kW	210 N⋅m	Manual	FWD
2.0 AT	Diesel	2189 cm³	175 hp	128 kW	420 N⋅m	Automatic	FWD
2.0 AT	Diesel	2189 cm³	175 hp	128 kW	420 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1998 cm³	165 hp	121 kW	214 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	165 hp	121 kW	214 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2488 cm³	194 hp	142 kW	257 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2488 cm³	194 hp	142 kW	257 N⋅m	Automatic	FWD
2.5 AT Turbo	Gasoline	2488 cm³	227 hp	166 kW	420 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2488 cm³	187 hp	137 kW	252 N⋅m	Automatic	AWD

Mazda CX-5 Dimensions

SUV 5-doors — Mazda CX-5 Dimensions

SUV 5-doors Mazda CX-5 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 AT	4550 mm	1840 mm	1680 mm	2700 mm	1525 kg	Not provided	152 mm
2.0 AT	4550 mm	1840 mm	1680 mm	2700 mm	1575 kg	Not provided	152 mm
2.0 MT	4550 mm	1840 mm	1680 mm	2700 mm	1451 kg	Not provided	152 mm
2.0 AT	4550 mm	1840 mm	1680 mm	2700 mm	1600 kg	Not provided	152 mm
2.0 AT	4550 mm	1840 mm	1680 mm	2700 mm	1650 kg	Not provided	152 mm
2.0 AT	4550 mm	1840 mm	1680 mm	2700 mm	1665 kg	Not provided	152 mm
2.0 AT	4550 mm	1840 mm	1680 mm	2700 mm	1665 kg	Not provided	152 mm
2.5 AT	4550 mm	1840 mm	1680 mm	2700 mm	1598 kg	Not provided	152 mm
2.5 AT	4550 mm	1840 mm	1680 mm	2700 mm	Not provided	Not provided	152 mm
2.5 AT Turbo	4550 mm	1840 mm	1680 mm	2700 mm	1684 kg	2190 kg	193 mm
2.5 AT	4550 mm	1840 mm	1680 mm	2700 mm	Not provided	Not provided	152 mm

Mazda CX-5 Cargo Space

SUV 5-doors — Mazda CX-5 Cargo Space

SUV 5-doors Mazda CX-5 Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 AT	442 l	1342 l
2.0 AT	442 l	1342 l
2.0 MT	442 l	1342 l
2.0 AT	442 l	1342 l
2.0 AT	442 l	1342 l
2.0 AT	442 l	1342 l
2.0 AT	442 l	1342 l
2.5 AT	442 l	1342 l
2.5 AT	442 l	1342 l
2.5 AT Turbo	442 l	1342 l
2.5 AT	442 l	1342 l

Mazda CX-5 Trims and Equipment

Mazda CX-5 trim levels for the 2.5 AT gasoline automatic front-wheel-drive model include Executive and Pure Black. Executive focuses on premium comfort, while Pure Black adds distinctive styling accents. Check which equipment packages apply, as features vary across markets and configurations.

Mazda CX-5 Trims and Equipment
Modification	Body	Equipment
2.0 AT	SUV 5-doors	Comfort
2.0 AT	SUV 5-doors	Executive
2.0 AT	SUV 5-doors	Active
2.0 AT	SUV 5-doors	Pure Black
2.0 AT	SUV 5-doors	Premium Black
2.0 AT	SUV 5-doors	Executive Tech
2.0 AT	SUV 5-doors	Signature
2.5 AT	SUV 5-doors	Executive
2.5 AT	SUV 5-doors	Pure Black
2.5 AT	SUV 5-doors	Premium Black
2.5 AT	SUV 5-doors	Signature
2.5 AT	SUV 5-doors	Executive
2.5 AT	SUV 5-doors	Pure Black
2.5 AT	SUV 5-doors	Executive Tech
2.5 AT Turbo	SUV 5-doors	Executive
2.5 AT Turbo	SUV 5-doors	Pure Black
2.5 AT Turbo	SUV 5-doors	Premium Black
2.5 AT	SUV 5-doors	Comfort
2.5 AT	SUV 5-doors	Executive
